SPECIFICATIONS

Function
AC/DC Current
AC Voltage
DC Voltage
Resistance
Frequency (≥ 5V)
Continuity
Input Limits
Conductor Size:
Battery type:
Range Selection:
Display:
Overload Indication:
Low Battery Indication:
Environmental conditions
Operating Temperature/Humidity
Storage Temperature/Humidity
Dimensions
Weight
Zero Adjust
Diode
Sample Time
Input Impedance
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
FAX 781.665.0780 - TestEquipmentDepot.com
Range
240.0A
600A
2.400V, 24.00V, 240.0V, 600.0V
240.0mV
2.400V, 24.00V, 240.0V, 600V
240.0Ω, 2.400kΩ 24.00kΩ, 240.0kΩ
2.400MΩ
24.00MΩ
50.00Hz, 500.0Hz, 5.000kHz, 50.00kHz,
100.0kHz
Audible tone <40Ω approximately
Maximum
Function Input
V DC/AC 600V DC or
AC Peak
A DC/AC 600A DC/AC,
fused
Function
Frequency
Resistance
1.18" (30mm) maximum
2 x 1.5V AA
Automatic ranging
5000 Count LCD
"OL"
Battery icon
Installation Category II, Pollution degree 2,
Altitude: 2000 meters, Indoor use only
o
32º to 122ºF (0 C to 50
o
14º to 140ºF (-10 C to 60
7.0x4.2x1.3" (178x64x33mm)
8.3 oz. (230g)
Uses REL (Relative) push button
Short/Open, Good/Defect Test
0.35 sec approximately.
10MΩ for ACV & DCV
Accuracy
±(2% rdg + 5d)
(AC @ 50/60Hz)
±(2% rdg + 8d)
±(1.2% rdg + 5d)
(AC @ 50/60Hz)
±(0.5% rdg +2d)
±(1.0% rdg + 2d)
±(1% rdg + 5d)
±(2% rdg + 2d)
±(3.5% rdg + 5d)
±(1% rdg + 5d)
Maximum
Input
250V DC or AC peak
400V DC or AC peak
(<10 seconds)
o
C) / <80% RH
o
C) / <80% RH
