INTRODUCTION

Congratulations on your purchase of Extech's 38394 AC/DC Clamp Meter. This clamp meter
measures AC/DC Current to 600A, DC/AC Voltage, Resistance, Frequency, and Continuity.
Proper use and care of this meter will yield years of reliable service.

SAFETY

Safety Symbols

This symbol, adjacent to another symbol or terminal, indicates the user must
refer to the manual for further information.
This symbol, adjacent to a terminal, indicates that, under normal use, hazardous
voltages may be present
Double insulation
WARNING: This indicates that a potentially hazardous condition which, if not avoided,
could result in death or serious injury.
CAUTION: This indicates that a potentially hazardous condition which, if not avoided,
could result in injury or damage to the meter.

Safety Precautions

WARNING: Improper use of this meter can cause damage, shock, injury or death. Read and
understand this user's manual before operating the meter.
1. Always remove the test leads before making current measurements.
2. Always remove the test leads before replacing the batteries.
3. Inspect the condition of the jaws, test leads and the meter for any damage before
operating the meter. Repair any damage or replace meter before use.
4. Do not exceed the maximum rated input limits.
5. Use great care when making measurements, especially when the voltages are
greater than 25VAC rms or 35VDC. These voltages are considered a shock hazard.
6. Always discharge capacitors and remove power from the dut before performing
Resistance or Continuity tests.
7. Remove the batteries from the meter if the meter is to be stored for long periods.
8. Ensure that the selected meter function matches the measurement to be taken
9. If the measured current is higher than the range selected for long periods,
overheating may occur compromising the safety and the operation of the meter's
internal circuits
10. To avoid discharge risks and erroneous readings, do not measure current on high
voltage conductors (>600V)
