FLIR MPX ME313L Quick Start Manual

Contents
1 x 720p IR Eyeball Dome
4 x Mounting Screws
4 x Drywall Anchors
1 x Mounting Template
1 x Allen Key
Features
• 1/2.9" Megapixel Sensor*
• True Day/Night with Mechanical ICR
• Outstanding Image Clarity in Low Light Conditions
• Advanced 2D Digital Noise Reduction (2D-DNR)
• 90ft (28m) Smart IR Night Vision**
• 3.6mm Wide Angle Lens
• IP66 Weatherproof Rating***
• Cold Climate Capability (Minimum Operating
Temperature –22°F / –30°C)
• 3-Axis Design for Wall / Ceiling Mounting
• 12V DC Operation
* Compatible with FLIR MPX recorders only.
** IR Illumination range under ideal conditions. Objects at or beyond
this range may be partially or completely obscured, depending on the
camera application.
*** Not recommended for submersion in water.
Safety Precautions
• Use an appropriate low voltage power cable to prevent
fire or electrical shock.
• Make sure to install the camera in an area that can
support the camera weight.
• There are no user serviceable parts inside the camera.
Please do not disassemble the camera.
• Do not clean the lens cover with an abrasive cleaning
material. Please use a soft cloth to clean the lens cover.
ME313L_SERIES_TRIFOLDQSG_EN_R2.indd 1
IT'S ALL ON THE WEB!
Product Information Specification Sheets
User Manuals Quick Start Guides
Latest News Video Tutorials
VISIT
www.flirsecurity.com/pro
FLIR Systems, Inc.
Copyright © 2014
As our products are subject to continuous improvement, FLIR Systems
Inc. reserves the right to modify product design, specifications and
prices, without notice and without incurring any obligation. E&OE
720 MPX IR EYEBALL DOME p
MODEL: ME313L
QUICK START GUIDE
English Version 2.0
www.flirsecurity.com/pro
