Summary of Contents for Brune B 300

  • Page 2 Module lowing: The B 300 draws in the air through an air suction housing opening on the side of the power cable and pas- ses it through an air filter, which filters out the larger dust particles and fine particles.
  • Page 3 O p e ra t i n g t h e Hu m i d i fi e r B 3 0 0 power input; Make sure that electrical parts do not come The operating display of the B 300 informs you into contact with water; about the current condition of the unit. You can...
  • Page 4 It is switched on and/or deactivated by The B 300 is switched on or off by pressing the simultaneous pressing of the 3 keys (AIR KEY AIR-button twice. By repeatedly depressing the and the two HUMIDITY keys) for 3 seconds.
  • Page 5 To guarantee an optimal functioning and a long must take place via a specialist, e.g. a certified lifetime of your B 300 unit, repair and mainten- plumber. (Please comply with the regulations of ance are inevitable. Depending on the conditions the local water supply company).
  • Page 6 Now you can snap the lock clips. Make sure that all lock clips are locked securely. Attention: When mounting the casing half, it is important that the orientation is followed correctly. See the recess for the power cable. C h a n g i n g t h e F i l t e r s Vapor Filter Air cleaning filter To change the air-cleaning filter, the casing has...
  • Page 7 To remove lime residues please use the out to the rear. Pull the defective lamp from its lime remover of the brand Brune (Art. No. 9016) socket and insert the new UVC lamp (Art. No.: or a commercial lime remover. All cleaning agent 6210).
  • Page 8 Air filter, check and if necessary change (only use original parts of the Brune brand). The filter should be changed no later than 20 weeks after initial operation. Vapor filter, check and if necessary change, (only use original parts of the Brune brand).
  • Page 9 E r r o r C o r r e c t i o n Error Cause Solution Not functioning at all Unit not connected to Check power input (no standby indicator) power supply Fine-fuse of the circuit Replace fine-fuse of the board blown circuit board No Function...
  • Page 11 In addition, we point out that the contents of these operating instructions are not part of an earlier or existing agreement, promise, or a legal relation or amendment of the original. All obligations of Brune Luftbefeuchtung Proklima GmbH are as specified in the respective sales contract, which also contains the complete and solely valid warranty conditions.
  • Page 12 Lu f t b e f e u c h t u n g P ro k l i m a G m b H Luftbefeuchtung Proklima GmbH · Schwarzacher Str. 13 · D-74858 Aglasterhausen Telefon ++49 (0) 62 62 - 54 54 · Telefax ++49 (0) 62 62 - 32 55 w w w.
