Quick Start Guide
FreeStyle 31/21 LED
Select 30/20 LED
Part No. 3100100 Rev A
08-30-2017

Advertisement

loading
Need help?

Need help?

Do you have a question about the FreeStyle 31 LED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kino Flo FreeStyle 31 LED

  • Page 1 Quick Start Guide FreeStyle 31/21 LED Select 30/20 LED Part No. 3100100 Rev A 08-30-2017...
  • Page 2 FreeStyle 31 & 21 LED Systems SYS-F31-120U FreeStyle 31 LED DMX System, Univ 120U SYS-F31-230U FreeStyle 31 LED DMX System, Univ 230U SYS-F21-120U FreeStyle 21 LED DMX System, Univ 120U SYS-F21-230U FreeStyle 21 LED DMX System, Univ 230U For available Kits & contents, see www.kinoflo.com...
  • Page 3 Select 30 & 20 LED Systems Select 30 LED DMX System, Univ 120U SYS-S30-120U Select 30 LED DMX System, Univ 230U SYS-S30-230U Select 20 LED DMX System, Univ 120U SYS-S20-120U Select 20 LED DMX System, Univ 230U SYS-S20-230U For available Kits & contents, see www.kinoflo.com Each Select LED System consists of: 1 LED Fixture 1 Mounting Plate...
  • Page 4 Power AC Input The Select 150 LED DMX Controller is powered AC and includes an IEC connection. It also includes a 12ft power cord with a locking IEC connector. The Select 150 LED DMX Controller has a built-in power supply with universal input from 100-240VAC.
  • Page 5 FreeStyle Fixture Assembly The FreeStyle LED Fixture is comprised of a removable Fixture Shell, LED panel and Louver. The Louver is held in place with Velcro fasteners. To remove the LED panel from the fixture housing, press the locking pin and turn thumbscrew to release LED panel.
  • Page 6 Removable Mount Align the center pin of the mounting plate to the center hole on the mating plate. Rotate plate clockwise until the four shoulder rivets drop into the receptacle. A locking pin will snap into place when the plate is properly seated. The yellow wire loop provides an attachment point for a safety chain.
  • Page 7 Control Panel - White Mode A) On /Off: On = Green light displayed. Off = Red light displayed. The display and all menu settings can be operated while the power button is in the Off position, as long as power is applied to the controller. The On /Off button only controls the light source.
  • Page 8: Color Mode

    Control Panel - Color & RGB Mode Color Mode A) Menu: Provides access to menu options such as General settings (Color Mode), Reset, DMX and DMX Wireless settings. Tip: While on control screen, press and hold for 3 seconds to switch through menus (White, Gels & Hue, RGB). B) Kelvin, G/M (Green/Magenta) Gel, Hue &...
  • Page 9 FreeStyle LED Fixture Specifications CFX-F31 FreeStyle 31 LED Fixture Weight: 15 lb (7kg) Dimensions: 40.5 x 3.5 x 11” w/ 6.5” barndoors (103 x 9 x 28cm w/ 16.5cm barndoors) FreeStyle 31 LED CFX-F21 FreeStyle 21 LED Fixture Weight: 11.5 lb (5kg) Dimensions: 26.5 x 3.5 x 13”...
  • Page 10 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. KINO FLO, INC Select 30, Select 20, FreeStyle 31, FreeStyle 21 ID: XRSCRMXTIMO101 IC: 8879A-CRMXT101 For full operation manual, see www.kinoflo.com...
  • Page 12 This product is made of recyclable materials and should be disposed of in accordance with governmental regulations. Kino Flo, Inc. 2840 N. Hollywood Way, Burbank, CA 91505, USA Tel: 818 767-6528 website: www.kinoflo.com...
