  • Page 1 Operation Manual FreeStyle 31/21 LED Part No. 3100104 Rev A 07-30-2017...
  • Page 2 FreeStyle 31 & 21 LED Systems SYS-F31-120U FreeStyle 31 LED DMX System, Univ 120U SYS-F31-230U FreeStyle 31 LED DMX System, Univ 230U SYS-F21-120U FreeStyle 21 LED DMX System, Univ 120U SYS-F21-230U FreeStyle 21 LED DMX System, Univ 230U Each FreeStyle LED System consists of:...
  • Page 3 FreeStyle 31 LED DMX Kits KIT-F31B-120U FreeStyle 31 LED DMX Kit, Univ 120U w/ Soft Case KIT-F31B-230U FreeStyle 31 LED DMX Kit, Univ 230U w/ Soft Case Kit Contents: Dimensions: FreeStyle 31 LED 1 FreeStyle 31 LED Fixture 42.5 x 7.5 x 16.5”...
  • Page 4 FreeStyle 21 LED DMX Kits KIT-F21B-120U FreeStyle 21 LED DMX Kit, Univ 120U w/ Soft Case KIT-F21B-230U FreeStyle 21 LED DMX Kit, Univ 230U w/ Soft Case Kit Contents: Dimensions: FreeStyle 21 LED 1 FreeStyle 21 LED Fixture 31 x 7.5 x 18” DMX Kit w/ Soft Case 1 Select 150 LED DMX Controller (79 x 19 x 46cm)
  • Page 5 FreeStyle Fixture Assembly The FreeStyle LED Fixture is comprised of a removable Fixture Shell, LED panel and Louver. The Louver is held in place with Velcro fasteners. To remove the LED panel from the fixture housing, press the locking pin and turn thumbscrew to release LED panel.
  • Page 6 Removable Mount Align the center pin of the mounting plate to the center hole on the mating plate. Rotate plate clockwise until the four shoulder rivets drop into the receptacle. A locking pin will snap into place when the plate is properly seated. The yellow wire loop provides an attachment point for a safety chain.

  • Page 7: Mounting The Controller

    Mounting the Controller Insert the 4 rubber feet of the controller into the 4 holes in the fixture. Secure the Controller to the fixture with the Velcro fastening strap. Connect the harness to the Controller. Align the key ways on the harness connector with the circular receptacle on the ballast.
  • Page 8 SnapBag & SnapGrid The SnapBag accessory (DFS-FS31-S & DFS-FS21-S) is a lightweight fabric tailor-made for the FreeStyle LED. It slips over the fixture and is attached with straps. The reflective material intensifies the soft light. The removable grid cloth attaches to the inside with Velcro. The SnapGrid accessory (LVR-FS340-S &...
  • Page 9 Power AC Input The Select 150 LED DMX Controller is powered AC and includes an IEC connection. It also includes a 12ft power cord with a locking IEC connector. The Select 150 LED DMX Controller has a built-in power supply with universal input from 100-240VAC.
  • Page 10 Control Panel - White Mode A) On /Off: On = Green light displayed. Off = Red light displayed. The display and all menu settings can be operated while the power button is in the Off position, as long as power is applied to the controller. The On /Off button only controls the light source.

  • Page 11: Rgb Mode

    Control Panel - Color & RGB Mode Color Mode A) Menu: Provides access to menu options such as General settings (Color Mode), Reset, DMX and DMX Wireless settings. Tip: While on control screen, press and hold for 3 seconds to switch through menus (White, Gels & Hue, RGB). B) Kelvin, G/M (Green/Magenta) Gel, Hue &...
  • Page 12 Accessories DFS-SL30-H Select 30/31 Flozier, Half DFS-SL20-H Select 20/21 Flozier, Half DFS-FS31-S FreeStyle 31 SnapBag w/ 2 x Diffusion DFS-FS21-S FreeStyle 21 SnapBag w/ 2 x Diffusion LVR-FS340-S Select 30/31 SnapGrid 40 ° LVR-FS240-S Select 20/21 SnapGrid 40 ° LVR-SL390-P Select 30/31 Louver/HP 90°...
  • Page 13 Cases BAG-SL30 Select 30/31 Soft Case BAG-SL20 Select 20/21 Soft Case KAS-DL30 Select 30/31 Flight Case KAS-DL20 Select 20/21 Flight Case KAS-SL32 Gaffer 30/31 Ship Case (2) KAS-SL22 Interview 20/21 Ship Case (2) KAS-SL33 Select 30/31 Fixture Ship Case (3) KAS-SL23 Select 20/21 Fixture Ship Case (3)
  • Page 14 FreeStyle LED Fixture Specifications CFX-F31 FreeStyle 31 LED Fixture Weight: 15 lb (7kg) Dimensions: 40.5 x 3.5 x 10.5” w/ 6.5” barndoors (103 x 9 x 27cm w/ 16.5cm barndoors) FreeStyle 31 Panel only: 37.5 x 2.5 x 9.5” FreeStyle 31 LED (95 x 6.5 x 24cm)
  • Page 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. KINO FLO, INC FreeStyle 31, FreeStyle 21 ID: XRSCRMXTIMO101...
  • Page 16 This product is made of recyclable materials and should be disposed of in accordance with governmental regulations. Kino Flo, Inc. 2840 N. Hollywood Way, Burbank, CA 91505, USA Tel: 818 767-6528 website: www.kinoflo.com...
