Back View - Control 4 AVM-16A1-B Installation And User Manual

2.
3.
4.
5.

Back View

1
1.
2.
3.
4.
—Provides the user-input method for
Buttons
options displayed in the front panel user
interface.
—For reading IR signals from
IR Window
devices such as a remote control.
—For scrolling through menus
Select Dial
and media lists displayed in the LCD.
—Troubleshooting option
Reset Button
behind the door to refresh the system.
2
3
—RJ-45 for a 10/100 Baset
Ethernet Port
Ethernet connection.
—RCA jacks for 16 mono
Audio Inputs 1-16
or 8 stereo analog sources and their
supporting light emitting diodes (LEDs) for
EZ ID™ during setup.
Amplifier Outputs 1-16
for 16 mono or 8 stereo class D amplified
channels (at 100 watts per channel) and their
supporting LEDs for EZ ID™ during setup.
—For supplied power cord
Power Plug Port
only.
4
—5-way binding post
5
