Manage Amplifier Output Zones; View System Status Screen; Use Master Volume - Control 4 AVM-16A1-B Installation And User Manual

Manage Amplifier Output Zones

View System Status Screen

To view the System Status Screen:
1.
Ensure your Multi Channel Amplifier is powered up
and that the Output to Input screen is displaying in
the front display.
-----placeholder table and text------
The screen consists of 16 output zones and any
assigned input source. When an input source is
highlighted (as Input 1 in this example), the
highlighting indicates that a signal is present.
The buttons on the front panel provide access to
these menu options:

Use Master Volume

Use the Selection Dial to control the volume (0-100).
12
Output to Input
1- 1 5-
2- 6-3
3- 4 7-
4- 8-
OUT/IN NETWORK
Out/In:
Displays an Output-specific screen. The
most recent screen accessed is displayed by
default, but you can choose to view a different
output's setting by changing the Output number.
Network:
Displays a Network screen. This is
essentially view-only information.
Display:
Displays the Display Configuration
Screen.
9- 13-
10- 14-
11- 15-
12- 16-
DISPLAY
