2
C H A P T E R
This chapter describes, in general terms, how to set up
the physical connections required for Multi Channel
Amplifier and all of the devices associated with it. You
should also refer to any installation documentation
available for the devices you plan to connect for additional
guidelines.
In order to use the multi-channel amplifier as designed,
you must complete the following tasks:

1.Plan Your Physical Layout

2.Connect Physical Components
3.Set Up Logical Connections
NOTE:
trained installers must use the Control4 Composer Pro
software. For instructions, refer to the Composer Pro
User Guide.
Plan Your Physical Layout
This section explains physical and logical connections
and can help you plan your physical connections.
Use a worksheet to plan your amplifier connections: Using
the worksheet provided in Table 2-1 on page 8, identify
the connection you will use for all planned connections.
Install the Multi Channel
Amplifier
To set up the logical connections required,
7
