View Network Settings - Control 4 AVM-16A1-B Installation And User Manual

1c.
1d.
2.
Rotate the Select Dial to highlight a setting.
3.
Press the Select Dial to enter Edit mode.
4.
Rotate the dial to change the setting; then press the
dial to Save the new setting and exit the Edit mode
OR, to exit without saving, use the front panel button
indicated to choose the Cancel option.
5.
Press the Inputs button to go to the Input Signal
Sensing screen, OR press the Exit button to return to
the Output to Input screen.

View Network Settings

To view network settings, access the Network settings
screen. These are view-only fields: MAC Address, DHCP,
IP Address, Subnet Mask, and Default Gateway
Configuration. By default, the system uses DHCP.
14
Treble:
Supported range: -10 to +10 dB
(default: 0 dB)
Bass:
Supported range: -10 to +10 dB
(default: 0 dB)
If you want to toggle to view Input Signal
Sensing information, choose the
If you want to Exit the screen, choose the
button.
Inputs
button.
Exit
