- Page 1 BaiCells mBS1100 Base Station Installation Guide V1.0 All rights reserved © BaiCells Technologies Co., Ltd.
- Page 2 This document is a user guide for the hardware installation of the base station mBS1100. Copyright Notice BaiCells copyrights this specification. No part of this specification may be reproduced in any form or means, without the prior written consent of BaiCells. Disclaimer This specification is preliminary and is subject to change at any time without notice.
-
Page 3: Table Of Contents
Contents Out-of-Box Audit ....................... 1 Shipping List ......................1 Base Station Appearance ..................2 Base Station Accessories ..................2 Installation Preparation ....................5 Supporting Materials ....................5 Installation Tools ...................... 5 Installation Environment .................... 6 2.3.1 Locational Requirements ..................6 2.3.2 Environmental Requirements ................ - Page 4 Contents of Figure Figure 1-1 mBS1100 Base Station Appearance ............2 Figure 3-1 Schematic diagram for installing mBS1100 ..........7 Figure 3-2 Installation Procedure of mBS1100 ............8 Figure 3-3 Install the Mounting Bracket ............... 9 Figure 3-4 Install the Handle ..................9 Figure 3-5 Installation of Mounting Bracket and Handle Completed ......
- Page 5 Table 1-1 Shipping List ....................1 Table 1-2 Base Station Accessories ................2 Table 2-1 Supporting Materials for Installing Base Stations ........5 Table 2-2 Environmental Requirements of the Base Station ........6 Table 3-1 mBS1100 Indicator Description ..............21...
-
Page 6: Out-Of-Box Audit
Table 1-1. Table 1-1 Shipping List Number Item Quantity Description mBS1100 base Check the device’s tag to see if it is station consistent with the requirement Power supply 100V ~ 277V AC to 48V DC adaptor... -
Page 7: Base Station Appearance
Figure 1-1 mBS1100 Base Station Appearance Size: 330mm (length) x 220mm (width) x 105mm (height) Weight: about 5kg Base Station Accessories Table 1-2 shows the accessories of the base station mBS1100. Table 1-2 Base Station Accessories Accessory Name GPS antenna... - Page 8 Accessory Name GPS antenna lightning protector Antenna lightning protector Loop ring Power adaptor Mounting bracket Handle Water-proof tape and daub GPS mounting bracket...
-
Page 10: Installation Preparation
2. Installation Preparation Supporting Materials Prepare accordingly the following supporting materials, given as Table 2-1. Table 2-1 Supporting Materials for Installing Base Stations Item Description Power line < AWG16，e.g., AWG14 Shorter than 350m (1150 feet) Antenna feeder 50 ohm feeder Cable CAT5, CAT5e Antenna... -
Page 11: Installation Environment
(large radar station, transmitting station, transformer substation) are not suitable for the operation of mBS1100, and thus should be avoided. Places prone to have impounded water, soaking, leakage, or condensation, should also be avoided. -
Page 12: Base Station Installation
3. Base Station Installation Installation Schematic Diagram Figure 3-1 is the schematic diagram for the installation of a base station. Figure 3-1 Schematic diagram for installing mBS1100 Antenna antenna Ground wire Surge Feeder Feeder protective device mBS1100 base station Ground wire... -
Page 13: Installation Procedure
The installation procedure of mBS1100 is given in Figure 3-2. Figure 3-2 Installation Procedure of mBS1100 Installation Steps 3.3.1 Install Mounting Bracket and Handle Use the M6*12 socket head screw to fix the bracket on both sides of the mBS1100, as shown in Figure 3-3. -
Page 14: Figure 3-3 Install The Mounting Bracket
Figure 3-3 Install the Mounting Bracket Use the M6*12 socket head screw to fix the handle on right side of the mBS1100, as shown in Figure 3-4. Figure 3-4 Install the Handle Figure 3-5 shows what it looks like when the installation of rack and handle is done. -
Page 15: Optional) Install Gps Antenna
GPS antenna feeder lightning protector is required before connecting to the base station. Prepare items for the GPS antenna installation Install GPS rack Install the GPS antenna in the upper right of the mBS1100 base station. Vertical installation is required. -
Page 16: Install Antenna Feeder System
GPS antenna feeder lightning protector. Then, connect one end of the other wire jumper to the GPS antenna feeder lightning protector and the other end to the mBS1100 base station’s GPS port. Ground the antenna feeder lightning protector. -
Page 17: Figure 3-6 Omnidirectional Antenna Installation (1)
3.3.3.1 Install Omnidirectional Antennas One should pay attention to the followings in the process of installing omnidirectional outdoor antenna: The diameter of the pole for omnidirectional outdoor antennas is required to be 35mm ~ 50mm. A typical case is to use the 50mm-diameter round-steel-made pole (with details depending on the specific antenna type). -
Page 18: Figure 3-7 Omnidirectional Antenna Installation (2)
Figure 3-7 Omnidirectional Antenna Installation (2) 3.3.3.2 Install Directional Antennas First, assemble the antennas, as shown in Figure 3-8. Figure 3-8 Assembling Procedure of Directional Antennas To install it on the iron tower’s role, use pulley to transport the antenna assembled to the platform at the iron tower, as shown in Figure 3-9. -
Page 19: Figure 3-9 Transportation Of The Antenna In The Height
Connect all cables and wires and fix them, when the base station has been installed in a proper position A lightning protector is mandatory in the connection between the mBS1100 base station and the antenna feeder. The N-type male connector of the lightning protector... -
Page 20: Figure 3-11 Installation Of The Antenna Feeder Lightning Protector
Figure 3-11 Installation of the Antenna Feeder Lightning Protector Ground the antenna feeder lightning protector. Note: The antenna feeder lightning protector must be grounded. Do testing, and seal all the connections for waterproof protection after the testing is passed. 3.3.3.3 Waterproof Protection Wrap the connections to protect with waterproof tapes and waterproof daub, as shown in Figure 3-12. -
Page 21: Figure 3-12 Antenna Waterproofing
Figure 3-12 Antenna Waterproofing Be aware that at least three layers of tapes are needed, and make sure that the wrapping direction of the last layer is from the bottom up. The last layer should be in suitable tightness to keep it from cracking and also for good looking. The overall appearance after the waterproof processing is shown in Figure 3-13 . -
Page 22: Install Base Station On Pole
3.3.4 Install Base Station on Pole Required diameter of the pole: 30mm ~ 125mm. Put the loop ring through the installation bracket on the base station, with one loop ring for each of the two brackets. Two persons required. Lift the base station, fix it to the pole using the loop rings, adjust the rings to a suitable position, and tighten the rings using the L-shape socket head screw wrench. -
Page 23: Install On Wall
3.3.5 Install on Wall Put the base station on the wall to install, and mark the drilling locations. Drill four holes in the wall of the size 4mm in diameter by following the locations marked. Check the up/down direction of the installation rack, and then fix the base station to the wall using M6 expansion screws. -
Page 24: Wire Connection
Wire Connection 3.4.1 Install Feeder After the mBS1100 is installed, connect the antenna and the base station’s ANT1 and ANT2 ports with feeders. 3.4.2 Install Ethernet Connector Waterproof connector is adopted for cables. Put the cable through the waterproof connector from the behind. A click sound should be heard. -
Page 25: Install Power Connector
protector are connected via an M6 screw. If connected to an outdoor ground via another M6 screw, the connection needs to be tin-soldered. The connection of ground terminals and ground bar is need to be tightness and reliable. And the rustproof processing is needed, such as rust preventing paint, anti-oxidation coatings, grease, and so on. -
Page 26: Base Station Power On
The connector needs to be tightened and correctly connected; otherwise, it would cause damage. Base Station Power On Power on the mBS1100, and the indicators will light up, as shown in Figure 3-16. Figure 3-16 LED Indicators The explanation of the indicator signal is given in Table 3-1.
