Kwikset Smartcode 910 Installation And User Manual page 2

3 Install the exterior keypad
A
Insert cylinder into keypad.
F
B
What is the diameter of the hole in the door?
Diameter is 2 1/8"
(54 mm)
or
2 1/8"
54 mm
"D" is required for installation. "D" is not needed for
Install "D" on "F". installation. Discard "D".
F
D
4 Install the interior assembly
A
Remove battery cover.
M
L
D
Connect cable. Ensure tight cable
connection.
L
5 Install the batteries and perform the door handing process
This step will teach your lock the orientation of your door and is crucial to lock operation.
A
Install 4 AA batteries in battery pack.
K
Ensure correct polarity.
For best results, use
new, non-rechargeable
Alkaline batteries only.
C
Install exterior keypad and mounting plate.
a
Locate screws
and keep them
W
within reach.
Diameter is 1 1/2"
T
(38 mm)
d
1 1/2"
38 mm
D
screws evenly.
B
Remove battery pack.
K
E
Lay cable lat against the interior
housing.
B
Press and HOLD the Lock button
while installing battery pack.
Hold button until the latch bolt
starts moving on its own.
2 / 4
actual
size
c Support exterior assembly
b
during mounting plate installation.
F
Cable goes
underneath latch.
e
Keep parallel to
edge of door.
T
T (2x)
Tighten
C
Make sure the turnpiece is in the vertical position.
Do not install
batteries
until step 5.
F G
Push turnpiece shaft onto
torque blade.
torque turnpiece
blade shaft
C
Did the latch bolt retract and extend on its
own when the battery pack was installed?
YES
Door handing process
was successful! Proceed
to next step after latch
bolt stops moving.
T
G
Route cable through
center hole, then push
cable into side hole.
E
Insert key and
test latch. If latch
does not extend or
retract smoothly,
adjust screws (T).
Remove key when
inished and make
sure the latch bolt
is fully extended.
actual
size
U
L
vertical
Secure interior assembly with
supplied screws.
U (2x)
Note: Turnpiece
may not rotate
smoothly until
after step 5.
NO
or
Remove battery
pack, wait 15 seconds,
then attempt the
process again.
