Further information

www.sick.com
1.4

Symbols and document conventions

Instructions to action
LED symbols
Sender and receiver
Warnings
8014276/2014-02-18 | SICK
Subject to change without notice
The following information is available on the Internet:
– Other language versions
– Data sheets and application examples
– CAD data of drawings and dimensional drawings
– Certificates (e.g. EC declaration of conformity)
– Guidelines for safe machines (accident prevention with opto-electronic protective de‐
vices)
The following symbols are used in these operating instructions:
b The arrow denotes instructions to action. Read carefully and follow the instructions
for action.
These symbols indicate the status of an LED:
The LED is off.

The LED is flashing.

The LED is illuminated continuously.

These symbols indicate the sender and receiver of the safety light curtain:
The symbol indicates the sender.
The symbol indicates the receiver.
A warning indicates an actual or potential risk or dangers. It is designed to help you to
prevent accidents. Read carefully and follow the warnings!
The following warning types are used in these operating instructions:
CAUTION
Alerts you to a dangerous situation, which can result in a mild to moderate injury if not
avoided.
WARNING
Alerts you to a dangerous situation, which can cause serious injury or death if not avoi‐
ded.
DANGER
Alerts you to a dangerous situation, which will cause serious injury or death if not avoi‐
ded.
NOTE
The "i" symbol denotes information and alerts you to possible damage and other impor‐
tant information.
