Quickstart
Manual
890SD (Standalone) Drive
Frames B, C & D
HA471071U000 Issue 3 (ISO A4)
HA471071U001 Issue 3 (American Quarto)
© Copyright 2007 Parker SSD Drives, a division of Parker Hannifin Ltd.
All rights strictly reserved. No part of this document may be stored in a retrieval system, or transmitted in any
form or by any means to persons not employed by a Parker SSD Drives company without written permission
from Parker SSD Drives, a division of Parker Hannifin Ltd . Although every effort has been taken to ensure the
accuracy of this document it may be necessary, without notice, to make amendments or correct omissions.
Parker SSD Drives cannot accept responsibility for damage, injury, or expenses resulting therefrom.
Parker SSD Drives warrants the goods against defects in design, materials and workmanship for the
period of 12 months from the date of delivery on the terms detailed in Parker SSD Drives Standard
Parker SSD Drives reserves the right to change the content and product specification without notice.
890
WARRANTY
Conditions of Sale IA058393C.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Parker 890
Summary of Contents for Parker 890
- Page 1 Parker SSD Drives company without written permission from Parker SSD Drives, a division of Parker Hannifin Ltd . Although every effort has been taken to ensure the accuracy of this document it may be necessary, without notice, to make amendments or correct omissions.
-
Page 2: Table Of Contents
WWW.SDS.LTD.UK | 0117 9381800 C o n t e n t s Page Safety..................................3 Hazards to Personnel Application Risk • Risk Assessment • Accessibility • Protective Insulation • RCDs Introduction................................5 About this QuickStart Installation................................6 Dimensions • Ventilation •... -
Page 3: Safety
The specifications, processes and circuitry described herein are for guidance only and may need to be adapted to the user's specific application. Parker SSD Drives does not guarantee the suitability of the equipment described in the Manual for individual applications. -
Page 4: Risk Assessment
WWW.SDS.LTD.UK | 0117 9381800 Risk Assessment Under fault conditions, power loss or other operating conditions not intended, the equipment may not operate as specified. In particular: • The motor speed may not be controlled • The direction of rotation of the motor may not be controlled •... -
Page 5: Introduction
Show you how to Autotune the drive and start the motor. Because the 890 is a system product and we have no knowledge of your application, we detail the quickest way to power-up the drive using a simple earthing scheme with minimal control wiring. -
Page 6: Installation
WWW.SDS.LTD.UK | 0117 9381800 Installation A simplified installation is shown below. This installation is not EMC compliant. For European installations and countries with EMC legislation refer to the 890 Engineering Reference Manual, Appendix C. Back-plate Cubicle Supply 890 Installation Kit... -
Page 7: Dimensions
: Control Bracket) The units must be installed in a cubicle. Mount the drive using the keyholes and slots or on a 35mm DIN rail using the 890 Installation Kit supplied. Ventilation The drives can be mounted side-by-side with no clearance. A minimum of 150mm (6 inches) free-air space must be allowed at the top and bottom of each drive. -
Page 8: Overview
WWW.SDS.LTD.UK | 0117 9381800 Overview Earth/Ground 3-Phase Line Input Dynamic Braking USB Port Status LED Option Card A Analog I/O Feedback Option F Auxiliary 24V Option Card B Digital I/O Mechanical Brake 3-Phase Motor Output Motor Thermistor Earth/Ground DC Link Page 8... -
Page 9: 3-Phase Connections
WWW.SDS.LTD.UK | 0117 9381800 3-Phase Connections • Connect the earth/ground wire to • Connect 3-phase power in any order to L1, L2, L3. the top ground bracket. Maximum wire sizes: Maximum wire sizes: Frame B: 6mm /10AWG - 0.5Nm Frame B: 6mm /10AWG Frame C: 10mm /8AWG - 1.2Nm... -
Page 10: Motor Connections
WWW.SDS.LTD.UK | 0117 9381800 Motor Connections • Connect motor leads to M1, M2, M3. Maximum wire sizes: Frame B: 4mm /12AWG Frame C: 10mm /8AWG Frame D: 16mm /4AWG • Connect the earth/ground wire from the terminal box of the motor directly to the bottom ground bracket. -
Page 11: 890Sd Control Connections
WWW.SDS.LTD.UK | 0117 9381800 890SD Control Connections The control terminals will accept a Speed Reference single wire of size 1.5mm /16AWG. For two wires per terminal, use smaller • Connect a 10kΩ potentiometer at gauge wire such as 0.5mm /22AWG. terminal block X12 (Analog I/P 3) High (CW): terminal X12/08... -
Page 12: 890Sd Feedback Connections
Option F Using other types of encoders requires the DSE Configuration Tool and the the setting of other parameters. Refer to the 890 Engineering Reference Manual for details of these parameters. OPTION F Terminal Block Shield Supply –... - Page 13 WWW.SDS.LTD.UK | 0117 9381800 Drive Start-up Before Applying Power : • Read the Safety section at the front of the QuickStart. • Ensure that all local electric codes are met. • Check for damage to equipment. • Check for loose ends, clippings, filings, drilling swarf etc. lodged in the drive and system.
-
Page 14: Drive Set-Up
WWW.SDS.LTD.UK | 0117 9381800 Drive Set-up Refer to Appendix A if using the 6511 keypad supplied with the drive. Appendix B contains information about the 6901 keypad that displays menu and parameter names in English. Motor Data Before attempting to set up the drive, you will need some motor information. This is found on the motor nameplate. -
Page 15: Autotune
Quick Setup to desired level. If the drive trips on Overvoltage, extend the RAMP DECEL TIME or connect a braking resistor. Refer to the 890 Engineering Reference Manual. Go to SYS::SAVE::APP and UP arrow to save your settings. Values are stored during power-down. -
Page 16: Running In Remote
Quick Setup to desired level. If the drive trips on Overvoltage, extend the RAMP DECEL TIME or connect a braking resistor. Refer to the 890 Engineering Reference Manual.. Go to SYS::SAVE::APP and UP arrow to save your settings. Values are stored during power-down. -
Page 17: Appendix A: Using The 6511 Keypad
Appendix A: Using the 6511 Keypad The 6511 is the keypad that comes as standard with any 890 product. It is a one-line backlit LCD with units and symbols for different functions. It can be used to setup and configure the 890. It can also be used to operate the drive in Local mode from its Start and Stop buttons. -
Page 18: The Menu Structure
WWW.SDS.LTD.UK | 0117 9381800 The Menu Structure The main menus are shown below. Each menu contains parameters. This is the power-up welcome screen. If a different screen appears, press E a few times to return to this screen time -out Press the M key to get to OPERATOR menu DOWN arrow to get to the DIAGNOSTICS menu DOWN arrow to get to the QUICK SETUP menu... -
Page 19: Appendix B: Using The 6901 Keypad
WWW.SDS.LTD.UK | 0117 9381800 Appendix B: Using the 6901 Keypad The 6901 keypad can be plugged into any 890 product. It is a two- line backlit LCD display with units and symbols. It can be used to setup and configure the 890 in plain language. It can also be used to operate the drive in Local mode from its Start and Stop buttons, Jog and reverse. -
Page 20: The Menu Structure
WWW.SDS.LTD.UK | 0117 9381800 The Menu Structure The main menus are shown below. Each menu contains parameters. AC MOTOR DRIVE This is the power-up welcome screen. If a different screen 15kW 400V appears, press E a few times to return to this screen. OPERATOR Press the M key to get to the OPERATOR menu menu at level 1... -
Page 21: Appendix C: Analog And Digital I/O
WWW.SDS.LTD.UK | 0117 9381800 Appendix C: Analog and Digital I/O The terminal function names apply to the factory shipping configuration. These terminals may have different functions if the configuration has been modified using DSE. Programming Port AIN1 AIN1 AIN2 AIN3 - REMOTE SETPOINT Speed AIN4 - SPEED TRIM Potentiometer... - Page 22 WWW.SDS.LTD.UK | 0117 9381800 Page 22...
-
Page 23: 890Sd Control Terminals Appendix D: Electrical Ratings
WWW.SDS.LTD.UK | 0117 9381800 Page 23... - Page 24 WWW.SDS.LTD.UK | 0117 9381800 Page 24...
