Result codes
Result codes
■
Numerical
Text display
display
0 OK
1 CONNECT
2 RING
3 NO CARRIER
4 ERROR
6 NO DIAL TONE No dial tone detected.
7 BUSY
8 NO ANSWER
100 RESTRICTION
101 DELAYED
Extended result codes
■
Numerical
Text display
display
5 CONNECT
1200
10 CONNECT
2400
11 CONNECT
4800
13 CONNECT
7200
12 CONNECT
9600
15 CONNECT
14400
16 CONNECT
19200
17 CONNECT
38400
18 CONNECT
57600
19 CONNECT
115200
20 CONNECT
230400
21 CONNECT
460800
When n=1 is set for the ATV<n> command
(nP. 32), result codes are displayed as text (default
setting). When set to n=0, they are displayed as
numerical values.
Transmission speed is displayed to maintain
compatibility with conventional modems connected
by RS-232C. However, since the FOMA terminal is
connected to the PC using FOMA USB Cable with
Charge Function 02 (sold separately) or Bluetooth
function, the displayed speed will differ from the
actual speed of connection.
When [RESTRICTION] (Number: 100) appears, the
transmission network is congested. Try connecting
again later.
Meaning
Successfully executed.
Connected to number
dialed.
Call detected.
Line disconnected.
Command not accepted.
Detecting busy tone.
Connection completed.
The server connection
timed out.
Network restricted.
Redial restricted.
Meaning
FOMA terminal and PC
connected at 1,200 bps.
FOMA terminal and PC
connected at 2,400 bps.
FOMA terminal and PC
connected at 4,800 bps.
FOMA terminal and PC
connected at 7,200 bps.
FOMA terminal and PC
connected at 9,600 bps.
FOMA terminal and PC
connected at 14,400 bps.
FOMA terminal and PC
connected at 19,200 bps.
FOMA terminal and PC
connected at 38,400 bps.
FOMA terminal and PC
connected at 57,600 bps.
FOMA terminal and PC
connected at 115,200 bps.
FOMA terminal and PC
connected at 230,400 bps.
FOMA terminal and PC
connected at 460,800 bps.
Communication protocol result codes
Numerical
Text display
display
1 PPPoverUD
5 PACKET
Result code display examples
When ATX0 is set
The CONNECT display appears only when
connection is completed, regardless of the
AT¥V<n> command (nP. 33) setting.
Text display example:
ATD
CONNECT
Numerical display example:
ATD
1
When ATX1 is set
When ATX1 and AT¥V0 are set (initial
value)
When connection is completed, CONNECT
<speed between FOMA terminal and PC>
appears in the syntax.
Text display example:
ATD
CONNECT 460800
Numerical display example:
ATD
1 21
When ATX1 and AT¥V1 are set*
When connection is completed, the information
below appears in the syntax.
CONNECT <speed between FOMA terminal and
PC> PACKET <host (APN)>/<maximum uplink
speed (FOMA terminal to mobile network base
station)>/<maximum downlink speed (mobile
network base station to FOMA terminal)>
Text display example:
ATD
CONNECT 460800 PACKET
mopera.ne.jp/384/7232
(Indicates terminal connected to
mopera.ne.jp, at maximum uplink
speed of 384 kbps and maximum
downlink speed of 7,232 kbps)
Numerical display example:
ATD
1 21 5
* Dial-up connection may not be processed correctly
when ATX1 and AT¥V1 are simultaneously set. Using
only AT¥V0 is recommended.
37
Meaning
Connected with 64K data
communication
Connected with packet
transmission
* ***
