Winmate IH32 User Manual

3.5” sbc with intel 4th / 5th generation dual core i5 processors, hdmi, lvds, vga, dual giga ethernet, and mini-pcie interface
Hide thumbs Also See for IH32:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
IH32 Motherboard
th
th
3.5" SBC with Intel ® 4
/ 5
Generation Dual Core i5 Processors,
HDMI, LVDS, VGA, Dual Giga Ethernet, and Mini-PCIe Interface
V100

User Manual

Version 1.2
Manual Number: 9171111I101X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IH32 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate IH32

Summary of Contents for Winmate IH32

  • Page 1: User Manual

    IH32 Motherboard 3.5” SBC with Intel ® 4 Generation Dual Core i5 Processors, HDMI, LVDS, VGA, Dual Giga Ethernet, and Mini-PCIe Interface V100 User Manual Version 1.2 Manual Number: 9171111I101X...

  • Page 2: Copyright Notice

    IH32 Motherboard User Manual Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
  • Page 3 IH32 Motherboard User Manual Packing List Before using this Motherboard, please make sure that all the items listed below are present in your package:  IH32 Motherboard  User Manual & Driver CD Optional Accessories:  Power Cord If any of these items are missing or damaged, contact your distributor or sales representative immediately.
  • Page 4 IH32 Motherboard User Manual CAUTION A Caution alert indicates potential damage to hardware and explains how to avoid the potential problem. WARNING! An Electrical Shock Warning indicates the potential harm from electrical hazards and how to avoid the potential problem.

  • Page 5: Revision History

    IH32 Motherboard User Manual over the power cord. All cautions and warnings on the equipment should be noted. 10. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient over-voltage.

  • Page 6: Table Of Contents

    IH32 Motherboard User Manual Contents PREFACE CHAPTER 1 GENERAL INFORMATION ............2 1.1 I .................... 2 NTRODUCTION 1.2 F ....................2 EATURES 1.3 M ..............3 OTHERBOARD PECIFICATIONS 1.3.1 Hardware and Software Description ..............3 1.3.2 Function block (V100) ................... 5 1.3.3 Board dimensions (V100) ..................
  • Page 7 IH32 Motherboard User Manual 3.2.2.13 PCH- IO Configuration ..................53 3.2.3 Boot Menu ......................58 3.2.4 Security Menu ..................... 59 3.2.5 Save & Exit ......................60 3.3 U ..........62 SING ECOVERY IZARD TO ESTORE OMPUTER CHAPTER 4 DRIVER INSTALLATION............65 4.1 C...

  • Page 9: Chapter 1 General Information

    IH32 Motherboard User Manual General Information This chapter includes the IH32 Motherboard background information. Sections include: 1.1 Introduction 1.2 Features 1.3 Motherboard Specifications...
  • Page 10 IH32 Motherboard User Manual Chapter 1 General Information Introduction Thank you for choosing the IH 32 motherboard. This motherboard can be integrated with Intel® Core i5-4200U Dual Core 1.6GHz (up to 2.6GHz) or Intel® Core i5-5200U Dual Core 2.2GHz (up to 2.7GHz) which offers a high performance computing platform with low power consumption.

  • Page 11: Motherboard Specifications

    IH32 Motherboard User Manual Motherboard Specifications 1.3.1 Hardware and Software Description Hardware: Supports Intel® 4th Generation Core i5 4200U 1.6GHz Processor (up to 2.6GHz) CPU Type Supports Intel® 5th Generation Core i5 5200U 2.2GHz Processor (up to 2.7GHz) Chipset Intel® SoC Integrated...
  • Page 12 IH32 Motherboard User Manual Chipset Driver Graphics Driver Audio Driver Driver Ethernet Driver Finket COM Port Driver Intel® Management Engine Software USB 3.0 Driver (Windows 7) Digital I/O Watchdog...

  • Page 13: Function Block (V100)

    IH32 Motherboard User Manual 1.3.2 Function block (V100)

  • Page 14: Board Dimensions (V100)

    IH32 Motherboard User Manual 1.3.3 Board dimensions (V100)

  • Page 15: Chapter 2 Hardware Installation

    IH32 Motherboard User Manual Hardware Installation This chapter provides information on how to use jumpers and connectors on the IH32 Motherboard. Be cautious while working with these modules. Please carefully read the content of this chapter in order to avoid any damages.
  • Page 16 IH32 Motherboard User Manual Chapter 2 Hardware Installation 2.1 Memory Module (SO-DIMM) Installation The IH32 Motherboard has two 204-pin SODIMM slot. The socket supports up to 16GB DDR3L 1333/1600 SDRAM. When installing the memory unit, please follow the steps below: Steps 1 Firmly insert the SO-DIMM at an angle of about 30-degree into the slot.

  • Page 17: I/O Equipment Installation

    IH32 Motherboard User Manual 2.2 I/O Equipment Installation 2.2.1 12V DC-IN The Motherboard allows plugging in 12V DC-IN jack on the board without another power module converter under power consumption by Intel® 4 Generation Core i5 4200U/ 5200U Processor. 2.2.2 Serial COM ports Three RS-232 connectors build-in the rear I/O.

  • Page 18: Audio Function

    IH32 Motherboard User Manual 2.2.6 Audio function The Audio 7.1 channel capabilities are provided by a Realtek ALC886 chipset supporting digital audio outputs. The audio interface includes three jacks: line-in, line-out and mic-in.

  • Page 19: Jumpers And Connectors

    IH32 Motherboard User Manual 2.3 Jumpers and Connectors 2.3.1 Component Side...

  • Page 20: Solder Side

    IH32 Motherboard User Manual 2.3.2 Solder Side 2.3.3 I/O Side...

  • Page 21: Jumper Settings

    IH32 Motherboard User Manual 2.4 Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. NOTE: A pair of needle nose pliers may be helpful when working with jumpers. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes.

  • Page 22: Setting Jumpers

    IH32 Motherboard User Manual 2.4.2 Setting Jumpers 2.4.2.1 JP1: Backlight Power Selector Setting Function 1-3* 2-4* +12V *Default 2.4.2.2 JP2: Panel Power Select Setting Function 1-2* +3.3V +12V *Default 2.4.2.3 JP3: PWM/DC Mode Control Selector Setting Function 1-3* PWM Mode...
  • Page 23 IH32 Motherboard User Manual 2.4.2.4 JP4: VR/Chipset Control Selector Setting Function 1-3* VR Control 2-4* Chipset *Default 2.4.2.5 SW0: Clear CMOS Please follow the instructions below to change CMOS settings. Step 1: To set the jumper to “clear” position, switch 1 to 0, 2 to N.

  • Page 24: Connectors And Pin Assignment

    IH32 Motherboard User Manual 2.5 Connectors and Pin Assignment 2.5.1 Front Side Setting Description The table below shows the function of each of the board’s connectors. Label Function Note AUDIO1 AUDIO 2x6 wafer, pitch 2.0mm RTC Battery 2P wafer, pitch 1.25 mm Serial port (RS232) 2x5 header, pitch 2.0mm...
  • Page 25 IH32 Motherboard User Manual DC In 1x4P wafer, pitch 2.0mm Panel 1 OSD membrane control 2x5 wafer, pitch 2.0mm SATA1 SATA SATA connector SATA2 SATA SATA connector USB3 Internal USB2.0 2x4 wafer, pitch 2.0mm VGA1 VGA Signal 2x5 wafer, pitch 2.0mm AUDIO1: Audio Pin №...
  • Page 26 IH32 Motherboard User Manual CN5, CN6, CN27, CN10 Serial ports (RS232) Pin № Name Pin № Name IO_PWR Note: IO_PWR: default is 5V option to 3.3V...
  • Page 27 IH32 Motherboard User Manual CN7: Mini-PCIE Pin № Name Pin № Name PCIE_WAKE# +3.3V Bluetooth_ENABLE +1.5V CLK_OE# USIM_PWR USIM_DATA PCIE_CLKM USIM_CLOCK PCIE_CLKP USIM_RESET USIM_VPP Wireless_ENABLE PCIE_RESET PCIE_RXM +3.3V PCIE_RXP +1.5V SMB_CLK PCIE_TXM SMB_DATA PCIE_TXP USB_D- USB_D+ +3.3V +3.3V +1.5V +3.3V...
  • Page 28 IH32 Motherboard User Manual CN12: GPI0 Pin № Name Pin № Name DOUT3 DOUT1 DOUT2 DOUT0 DINT3 DINT1 DINT2 DINT0 CN14: SATA Power Pin № Name Pin № Name +12V +12V...
  • Page 29 IH32 Motherboard User Manual CN15: mSATA Pin № Name Pin № Name +3.3V +1.5V SATA_RXP +3.3V SATA_RXN +1.5V SATA_TXN SATA_TXP +3.3V +3.3V +1.5V SSD_LED +3.3V...
  • Page 30 IH32 Motherboard User Manual CN16: 12V Output Pin № Name +12V CN17: 5V Output Pin № Name CN18: 3.3V output Pin № Name +3.3V...
  • Page 31 IH32 Motherboard User Manual CN19: Backlight Control VR Pin № Name Pin № Name Black Light Control CN20: Backlight Pin № Name Pin № Name Backlight Power Backlight Power Backlight Power Brightness Adjust Backlight Enable Note: Please refer to Setting to select Power Rating...
  • Page 32 IH32 Motherboard User Manual CN21: USB 2.0 Pin № Name Pin № Name USB3_P3_RX - USB3_P3_RX + USB3_P4_RX- USB3_P4_RX+ USB3_P3_TX- USB3_P3_TX+ USB3_P4_TX- USB3_P4_TX+ USB_P3_D- USB_P3_D+ USB_P4_D- USB_P4_D+ CN22: DC-In 2.5 Pin № Name Pin № Name DC_IN *Not visible for user...
  • Page 33 IH32 Motherboard User Manual CON1: LVDS Pin № Name Pin № Name LCDVDD LVDS0_TX0_N LCDVDD LVDS0_TX0_P LCDVDD LVDS0_TX1_N LVDS0_TX1_P LVDS0_TX2_N LVDS0_TX2_P LVDS0_CLK_N LVDS0_CLK_P LVDS0_TX3_N LVDS0_TX3_P LVDS1_TX0_N LVDS1_TX0_P LVDS1_TX1_N LVDS1_TX1_P LVDS1_TX2_N LVDS1_TX2_P LVDS1_CLK_N LVDS1_CLK_P LVDS1_TX3_N LVDS1_TX3_P Note: Please refer to CON1...
  • Page 34 IH32 Motherboard User Manual CPU_FAN1: CPU FAN Pin № Name Pin № Name +12V RPM_SENSE DIMM1: DDR3L J5: R-Speaker Out Pin № Name ROUT+ ROUT-...
  • Page 35 IH32 Motherboard User Manual J6: L-Speaker Out Pin № Name LOUT+ LOUT- J8: DC-In Pin № Name Pin № Name +12V +12V Panel1: OSD Membrane Control Pin № Name Pin № Name +3.3V SATA_LED# PWRBTN# Backlight_ADJ+ FP_RST_N Backlight_ADJ- NOTE: Backlight_ADJ+ / Backlight_ADJ- are optinal functions...
  • Page 36 IH32 Motherboard User Manual SATA1, SATA2: SATA Pin № Name Pin № Name SATA_TXP SATA_TXN SATA_RXN SATA_RXP Two USB3: Internal USB2.0 Pin № Name Pin № Name USB_D- USB_D- USB_D+ USB_D+...
  • Page 37 IH32 Motherboard User Manual VGA1: VGA Signal Pin № Name Pin № Name DDC_DATA DDC_CLOCK Horizontal Sync GREEN Vertical Sync BULE...

  • Page 38: I/O Settings Description

    IH32 Motherboard User Manual 2.5.2 I/O Settings Description The table below lists each of I/O side board connectors and PIN assignment. Label Function Note COM1 Serial port (RS232/422/485) D-Sub9 (Male) DCJACK DC JACK 2.5 DC Jack HDMI HDMI Signal HDMI Type A...
  • Page 39 IH32 Motherboard User Manual DCJACK: 2.5’ DC Jack Pin № Name Pin № Name DC_IN HDMI: HDMI Type A Pin № Name Pin № Name HDMI_DET HDMI_D2P HDMI_D2M HDMI_D1P HDMI_D1M HDMI_D0P HDMI_D0M HDMI_CLKP HDMI_CLKM HDMI_CEC_OUT DDC_CLOCK DDC_DATA...

  • Page 40: Two Usb 3.0 (Compliable With Usb 2.0)

    IH32 Motherboard User Manual LAN1/ LAN2: Gigabit Ethernet Pin № Name Pin № Name TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+ TX4- Two USB 3.0 (Compliable with USB 2.0) Pin № Name Pin № Name USB_D- USB_D+ STDA_SSRX- STDA_SSRX+ GND_DRAIN...

  • Page 41: Chapter 3 Ami Bios Setup

    IH32 Motherboard User Manual AMI BIOS Setup This chapter contains BIOS Configuration and OS Recovery information. 3.1 Instructions 3.2 BIOS Functions 3.3 Using Recovery Wizard to Restore Computer...

  • Page 42: How And When To Use Bios Setup

    IH32 Motherboard User Manual Chapter 3 AMI BIOS SETUP 3.1 How and When to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press Del key when the prompt appears on the screen during start up. The prompt screen shows only few seconds so need press Del key quickly.

  • Page 43: Bios Functions

    USB keyboard to your computer. 3.2 BIOS Functions The IH32 motherboard has AMI BIOS built-in and a CMOS SETUP utility that allow users to configure required settings or to activate certain system features. The follwoing sections describe the configuration options found in the menu items.
  • Page 44 IH32 Motherboard User Manual BIOS Setting Description Setting Option Effect System Displays the system Adjustment of the Set the language in Language language. [English] is language other language. The set up by default. language in this device is English. System...

  • Page 45: Advanced Settings

    IH32 Motherboard User Manual 3.2.2 Advanced Settings Select the Advanced Tab from the IH32 setup menu to enter the advanced BIOS setup screen. You can select any of the items on the left frame of the screen to go to the sub menu for the item, such as CPU Configuration.
  • Page 46 IH32 Motherboard User Manual BIOS Setting Description Setting Effect Option ACPI Settings Configures ACPI settings Enter Opens submenu RTC Wake Settings Configures RTC Wake Enter Opens submenu parameters Trusted Computing Configures Trusted Enter Opens submenu Computing parameters CPU Configuration Configures CPU settings...
  • Page 47 IH32 Motherboard User Manual 3.2.2.1 ACPI Settings BIOS Setting Description Setting Option Effect Enable ACPI BIOS ACPI Auto Enable/ Disable Enables or Auto Configuration Disables this Configuration function Enable Control hibernation Enable/ Disable Enables or Hibernation Disables this function...
  • Page 48 IH32 Motherboard User Manual 3.2.2.2 RTC Wake BIOS Setting Description Setting Option Effect Wake system with System awake on Enabled/ System will Fixed Time alarm events. Disabled awake at the hr: min: sec specified Wake system with S set the system to...
  • Page 49 IH32 Motherboard User Manual 3.2.2.3 Trusted Computing BIOS Setting Description Setting Option Effect Security Device Enable or disable BIOS Enabled/Disabled Set desirable Support support for security device configuration TPM State Enable or disable TPM Enabled/Disabled Set desirable state. configuration...
  • Page 50 IH32 Motherboard User Manual 3.2.2.4 CPU Configuration CPU Configuration allows you to change CPU settings. Use key arrows to navigate through the menu.
  • Page 51 IH32 Motherboard User Manual 3.2.2.5 SATA Configuration BIOS Setting Description Setting Option Effect SATA Controller (s) Allows users to enable Enabled/ Set desirable or disable the SATA Disabled configuration controller (s) SATA Mode Allows users to select Enabled/ Set desirable...
  • Page 52 IH32 Motherboard User Manual 3.2.2.6 Intel® Rapid Start Technology Allows users to enable or disable Intel rapid start technology.
  • Page 53 IH32 Motherboard User Manual 3.2.2.7 PCH (FW) Configuration...
  • Page 54 IH32 Motherboard User Manual 3.2.2.8 USB Configuration BIOS Setting Description Setting Option Effect Legacy USB User can enable or Disabled Will keep USB devices Support disable USB port. available only for EFI applications. Enabled Enable all the USB devices XHCI Hand‐off...
  • Page 55 IH32 Motherboard User Manual time‐ out control, bulk, and 5 Sec value interrupt transfers. 10 Sec 20 Sec Device Reset USB mass storage 10 Sec Depends on the time‐out time‐ out device start unit 20 Sec value command time‐ out.
  • Page 56 IH32 Motherboard User Manual 3.2.2.9 F81866 H/W Monitor BIOS Setting Description Setting Option Effect Enable or Smart Fan Set parameters of Enabled/ disable this Function smart fan function Disabled function Smart Fan Mode Configure smart fan mode settings Configuration...
  • Page 57 IH32 Motherboard User Manual 3.2.2.10 F81866 Super IO Configuration BIOS Setting Description Setting Option Effect Setting Serial Port User can Enable/Disable Enable/Disable Enable or Parameters the serial port and select Disable Serial optimal settings for the Default: Port (COM). Super IO Device.
  • Page 58 IH32 Motherboard User Manual Pin 3~ Pin 10 Control Settings.
  • Page 59 IH32 Motherboard User Manual 3.2.2.11 Serial Port RS232/RS422/RS485 Settings BIOS Setting Description Setting Option Effect Serial Port Select Serial Port RS232 / RS422 Choose Serial RS485 (Rx)/ Port Settings RS485(Tx) Change Settings Allow Change Serial [AUTO] Port Settings UART Mode...
  • Page 60 IH32 Motherboard User Manual 3.2.2.12 Chipset Menu...

  • Page 61: Pch- Io Configuration

    IH32 Motherboard User Manual 3.2.2.13 PCH- IO Configuration BIOS Setting Description Setting Option Effect PCI Express Detail of PCI Express Set desirable Configuration items. parameters Set desirable Details of USB items Configuration parameters PCH LAN Enables or disables the Enabled/...
  • Page 62 IH32 Motherboard User Manual 3.2.2.14 PCI Express Configuration BIOS Setting Description Setting Option Effect DMI Link ASPM Allows users to enable or Enabled/ Set desirable Control disable the DMI Link ASPM Disabled parameters Control DMI Link Allows users to configure...
  • Page 63 IH32 Motherboard User Manual 3.2.2.15 USB Configuration BIOS Setting Description Setting Option Effect Allows user to enable or Enabled/ Set desirable Precondition disable USB precondition Disabled parameters XHCI Mode Allows user to enable or [Smart Auto] Set desirable disable XHCI mode.
  • Page 64 IH32 Motherboard User Manual 3.2.2.16 System Agent (SA) Configuration Allows users to enable or disable VT-d.
  • Page 65 IH32 Motherboard User Manual 3.2.2.17 Graphics Configuration BIOS Setting Description Graphics Turbo IMON Allows users to select which Graphics Turbo IMON Current Current Internal Graphics Allows users to enable or disable IGD Aperture Size This item allows users to select aperture size...

  • Page 66: Boot Menu

    IH32 Motherboard User Manual 3.2.3 Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS use to look for a boot device from which to load the operating system.

  • Page 67: Security Menu

    IH32 Motherboard User Manual Fast Boot Enables or disables Fast Boot to Disabled Disables this shorten the OS boot process. function (Default: Disabled). Enabled Enables this function Boot Option Specifies the overall boot order Ex: Boot Hard drive as Priorities...

  • Page 68: Save & Exit

    IH32 Motherboard User Manual BIOS Setting Description Setting Effect Option Administrator Displays whether or not an Enter Enter password Password administrator password has been set. User Password Display whether or not a user Enter Enter password Password has been set.
  • Page 69 IH32 Motherboard User Manual Save Changes Reset the system after saving Enter <YES> Saves the and Reset the changes. changes Enter <NO> Return to the BIOS Setup Main Menu Discard Reset system setup without Enter <YES> Saves the Changes and...

  • Page 70: Using Recovery Wizard To Restore Computer

    Main Menu 3.3 Using Recovery Wizard to Restore Computer IH32 motherboard has a dedicate recovery partition stored on the hard drive of the PC to enable quick one-key recovery process. This partition occupies about 11GB of the storage space, and comes built-in to each IH32 series PC.
  • Page 71 IH32 Motherboard User Manual A warning message about data loss will show up. Make sure the data is backed up before recovery, and click “Yes” to continue. Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process complete. The...

  • Page 72: Chapter 4 Driver Installation

    IH32 Motherboard User Manual Driver Installation This chapter offers information on the chipset software installations utilities. Sections include: 4.1 Chipset Driver 4.2 Graphic Driver 4.3 Audio Driver 4.4 Ethernet Driver 4.5 Fintek COM Port Driver 4.6 Intel® Management Engine Software...
  • Page 73 IH32 Motherboard User Manual Chapter 4 Driver Installation 4.1 Chipset Driver The Intel Chipset Drivers should be installed first before the software drivers enable Plug & Play INF support for Intel chipset components. Follow the instructions below to complete the installation.
  • Page 74 IH32 Motherboard User Manual Step 2 Click “Next” to start the installation. Step 3 Click “Next” to continue the installation.
  • Page 75 IH32 Motherboard User Manual Step 4 Click “Yes, I want to restart this computer now” to finish installation.

  • Page 76: Graphics Driver

    IH32 Motherboard User Manual 4.2 Graphics Driver IH32 Motherboard comes with Intel mobile Core i5 Dual Core CPU and integrated graphic controller. You need to install the Graphic driver to enable the function. Intel Graphic supports versatile display options and 32-bit 3D graphics engine. Triple independent display, enhanced display modes for widescreen flat panels for extend, twin, and clone display mode.
  • Page 77 IH32 Motherboard User Manual Step 2 Click “Next” to install the driver. Step 3 Click “Yes” to agree with the license terms.
  • Page 78 IH32 Motherboard User Manual Step 4 Click “Next” to install the driver. Step 5 Click “Yes, I want to restart this computer now” to finish installation.

  • Page 79: Audio Driver

    Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technology. The user must confirm which operating system is running on the IH32 Motherboard before installing the Audio drivers. Follow the steps below to complete the installation of the Realtek ALC886 Audio drivers.
  • Page 80 IH32 Motherboard User Manual Step 2 Click “Next” to start the installation. Step 3 Click “Yes, I want to restart my computer now” to finish the installation.

  • Page 81: Ethernet Driver

    IH32 Motherboard User Manual 4.3 Ethernet Driver The users must confirm which operating system is used on the IH32 Motherboard before installing the Ethernet drivers. Follow the steps below to complete the installation of the Intel® I210IT Gigabit-LAN Controller + I218LM Gigabit-LAN drivers.
  • Page 82 IH32 Motherboard User Manual Step 2 Extract the “PROWinX64_19.0” file and click “Next” to install the driver. Step3 Click “Next” to agree with the license terms.
  • Page 83 IH32 Motherboard User Manual Step 4 Click “Next” to install the driver. Step 5 Click “Finish” to complete the driver installation.

  • Page 84: Fintek Com Port Driver

    IH32 Motherboard User Manual 4.5 Fintek COM Port Driver Step 1 If your system is WIN7, please first close UAC (refer to the following “Disabling User Account”) Control (UAC) in Windows 7” Step 2 Extract the Patch_0408.zip to a folder.
  • Page 85 IH32 Motherboard User Manual Step 5 Restart the computer to complete driver installation. Type in this command from the Run menu: C:\Windows\System32\UserAccountControlSettings.exe or UAC To turn off UAC move the slider to the Never notify position, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation.
  • Page 86 IH32 Motherboard User Manual To turn UAC back on, move the slider to choose when you want to be notified, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation. You will need to restart your computer for UAC to be turned off.

  • Page 87: Intel® Management Engine Software

    IH32 Motherboard User Manual 4.6 Intel® Management Engine Software This installation program installs the Intel® ME software components required for the platform on which you are installing, and installs only those components that match your platform’s capabilities. Step 1 Insert the driver CD and select the “Intel ME 9.0” folder and click “Setup.exe”...
  • Page 88 IH32 Motherboard User Manual Step 2 Click “Next” to continue the installation. Step 3 Click “Yes” to agree with the License terms.
  • Page 89 IH32 Motherboard User Manual Step 4 Choose “I accept the terms of the license agreement”, and click “Next” to continue. Step 5 Click “Finish” to complete the software installation.

  • Page 90: Usb 3.0 Driver Installation (Windows 7)

    IH32 Motherboard User Manual 4.7 USB 3.0 Driver Installation (Windows 7) NOTE: If the operating system of the device is Windows Embedded 8.1 Industry or Windows Embedded 8 Standard, users can skip this installation. Step 1 Locate the hard drive directory where the driver files are stored with the browser or the explore feature of Windows*.
  • Page 91 IH32 Motherboard User Manual Step 4 Read the License Agreement and click “Yes” to proceed. Step 5 Review Readme File Information and click “Next” to proceed Step 6 When the Setup Progress is complete click “Next” to proceed.
  • Page 92 IH32 Motherboard User Manual...
  • Page 93 IH32 Motherboard User Manual Step 7 Click “Yes, I want to restart this computer now” to finish and then restart your computer.

  • Page 94: Chapter 5 Technical Support Documents

    IH32 Motherboard User Manual Technical Support Documents This chapter includes SDK list for this user manual. 5.1 Digital I/O SDK 5.2 Watchdog SDK...
  • Page 95 You can download SDK from our download center, please click the link below. https://www.dropbox.com/s/l3lklrmiqy2lip6/SDK.rar?dl=0 5.1 Digital I/O SDK To find the Digital I/O Sample code, please refer to the IH32 driver CD SDK or contact us. 5.2 Watchdog SDK To find the Watchdog Sample code, please refer to the IH32 driver CD SDK...
