  • Page 1 GENERAL INSTAL LATION GUIDE www.EverWarm.net...
  • Page 2 CHK-50-240, CHF-100, CHK-100-120, CHK-100-240, CHF-200, CHK-200-240, CHF-550 THE DOCUMENTATION PROVIDED HEREIN PERTAINS SOLEY TO THE USE AND INSTALLATION OF EverWarm Radiant Heat FILM, EverWarm RADIANT FLOORS, OEM ACCESSORIES, AND PRODUCTS PRODUCED BY CarbonicHeat CORPORATION. SUBJECT MATTER AND SPECIFICATIONS ARE SUBJECT TO CHANGE.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION 1: GENERAL NOTES AND INFORMATION .....4-10 SECTION 2: TOOLS REQUIRED FOR INSTALLATION ....11 SECTION 3: INSTALLATION GUIDELINES ......12-20 SUBFLOOR PREPARATIONS ..... 12 TILE ..........13-16 LAMINATE ..........17 WOOD FLOOR ........18 CARPET ..........19 LINOLEUM AND VINYL ......

  • Page 4: Section 1: General Notes And Information

    If a nail or staple is accidentally placed through this area, they must be removed and securely taped shut. S E C T I O N 1 EverWarm Radiant Heat PAGE 4...
  • Page 5 6.DO NOT install the Heating Film over pre-existing linoleum, PVC, or vinyl floor coverings. (All must be removed, including all pre-existing adhesive, prior to the installation of the Heating Film). S E C T I O N 1 EverWarm Radiant Floors PAGE 5...
  • Page 6 IX of the National Electric Code (NEC) ANSI/NFPA 70. “STATEMENT OF NATIONAL ELECTRIC CODE PRODUCT COMPLIANCE (NEC). This product from EverWarm Radiant Heat™ Corporation is compliant to Article 424, Part IX of the National Electric Code (NEC), “Electric Radiant Heating Sheets and Heating Sheet Sets”...
  • Page 7 UNDERSTANDING EverWarm Radiant Heat FILM Carbonic Heating Film is a revolutionary solution to today’s radiant floor heating applications. The Heating Film is manufactured to make radiant floor heating more readily available, far more adaptable for unique applications and designs, and far easier to install than many other radiant floor products.
  • Page 8 EXPECTED FLOOR TEMPERATURE Heating performance is never guaranteed. EverWarm Radiant Heat is designed to deliver 15 W/sq. ft., with an average attainable temperature between 75°F (23.9°C) and 104°F (40°C), depending upon the subfloor, the layers of materials included in the floor installation, and the type of flooring used.
  • Page 9 Jumpers can also be JUMPER used around cut outs for floor ports such as receptacles, registers, and floor ports. S E C T I O N 1 EverWarm Radiant Floors PAGE 9...
  • Page 10 OR GRAY AREA OF THE HEATING FILM THAT HAS BEEN CUT. THERMOSTATS EverWarm Radiant Heat offers a variety of direct line voltage thermostats in both programmable and non-programmable models. All EverWarm Radiant Heat thermostats in the United States are GFCI-protected (required by the NEC).

  • Page 11: Section 2: Tools Required For Installation

    TOOLS REQUIRED FOR INSTALLATION TOOLS NEEDED WHEN INSTALLING THE EverWarm Radiant Heat HEATING SYSTEM Digital Multi-Meter Wire Cutters Wire Stripper Wire Crimper Flex Heat Crimping Tool Scissors (Part# CHP-01) Broom/Dust Pan Tape Measure S E C T I O N 2...

  • Page 12: Section 3: Installation Guidelines

    5. Mop or sponge the floor with clean water to remove any traces of dust. 6. Make sure the floor is completely dry before installing EverWarm Radiant Heat Film. S E C T I O N 3...
  • Page 13 ANSI A118.1 to install ceramic and stone tile. (See notes). NOTE: EverWarm PRODUCTS, LLC DOES NOT RECOMMEND THE USE OF MODIFIED THIN-SET MORTARS TO SET TILE OVER THE HEATING FILM BECAUSE THESE MORTARS MUST AIR-DRY TO CURE PROPERLY. WHEN “SANDWICHED”...
  • Page 14 DAYS TO OVER 60 DAYS, DEPENDING ON GEOGRAPHIC LOCATION, AND THE CLIMATE CONDITIONS, SUCH AS HUMIDITY AND AMBIENT AIR TEMPERATURE. FLOOR SENSOR (INCLUDED WITH ALL THERMOSTATS) MUST BE PROPERLY INSTALLED. S E C T I O N 3 EverWarm Radiant Floors PAGE 14...
  • Page 15 4. Install the tile on top of the Heating Film using an unmodified thin-set mortar meeting the requirements of ANSI A118.1 to install ceramic and stone tile. (See notes) FLOOR SENSOR (INCLUDED WITH ALL THERMOSTATS) MUST BE PROPERLY INSTALLED. S E C T I O N 3 EverWarm Radiant Floors PAGE 15...

  • Page 16: Tile

    5. Install the tile on top of the Heating Film using an unmodified thin-set mortar meeting the requirements of ANSI A118.1 to install ceramic and stone tile. (See notes) FLOOR SENSOR (INCLUDED WITH ALL THERMOSTATS) MUST BE PROPERLY INSTALLED. S E C T I O N 3 EverWarm Radiant Floors PAGE 16...

  • Page 17: Laminate

    NOTE: CHECK WITH YOUR FLOORING MANUFACTURER FOR MAXIMUM TEMPERATURE RATINGS THAT ARE APPROPRIATE FOR YOUR FLOORING AND SET YOUR THERMOSTAT ACCORDINGLY. FLOOR SENSOR (INCLUDED WITH ALL THERMOSTATS) MUST BE PROPERLY INSTALLED. S E C T I O N 3 EverWarm Radiant Floors PAGE 17...

  • Page 18: Wood Floor

    FLOORING MANUFACTURER FOR MAXIMUM TEMPERATURE RATINGS THAT ARE APPROPRIATE FOR YOUR FLOORING AND SET YOUR THERMOSTAT ACCORDINGLY. FLOOR SENSOR (INCLUDED WITH ALL THERMOSTATS) MUST BE PROPERLY INSTALLED. S E C T I O N 3 EverWarm Radiant Floors PAGE 18...

  • Page 19: Carpet

    3. Install the carpet according to the manufacturer’s instructions. Be sure carpet is approved for installation over radiant floor heat products. FLOOR SENSOR (INCLUDED WITH ALL THERMOSTATS) MUST BE PROPERLY INSTALLED. S E C T I O N 3 EverWarm Radiant Floors PAGE 19...

  • Page 20: Linoleum And Vinyl

    NOTE: CHECK WITH THE FLOORING MANUFACTURER FOR MAXIMUM TEMPERATURE RATINGS THAT ARE APPROPRIATE FOR YOUR FLOORING AND SET THE THERMOSTAT ACCORDINGLY. FLOOR SENSOR (INCLUDED WITH ALL THERMOSTATS) MUST BE PROPERLY INSTALLED. S E C T I O N 3 EverWarm Radiant Floors PAGE 20...

  • Page 21: Section 4: Installing Heating Film

    INSTALLING EVERWARM KITS CHK-15-120, CHK-25-120 (Kit description: TYPE - SQUARE FOOTAGE- VOLTAGE, Example: EverWarm Kit-15 square feet-120 volt system.) The per-assembled radiant heat flooring system is designed with ease of installation in mind. These kits feature a per-attached Harness, sealed with our Edge Sealing Tape.
  • Page 22 CHK-50-120, CHK-50-240 (Kit description: TYPE - SQUARE FOOTAGE- VOLTAGE, Example: EverWarm Kit-50 square feet-120 volt system.) The per-assembled radiant heat flooring system is designed with ease of installation in mind. These kits feature an installation system that includes an attached Harness and Adder, completely sealed with our Edge Sealing Tape.
  • Page 23 CHK-100-120, CHK-100-240 (Kit description: TYPE - SQUARE FOOTAGE- VOLTAGE, Example: EverWarm Kit-120 square feet-120 volt system.) These kits are all supplied with the CarbonicHeat Film, a J-2 Harness, an A-2 Adder, and eight (8) pieces of Edge Sealing Tape. This will be enough material to complete an 80-100 square foot room.

  • Page 24: Section 5: General Installation Instructions

    GENERAL INSTALLATION INSTRUCTIONS LAYOUT The installation of EverWarm Film begins with planning a layout for the Heating Film. This helps the installer understand how much Heating Film will be needed, and which (and how many) Wiring Harnesses, Jumpers, Adders, and extra Edge Sealing Tape might be needed. Additionally, a pre-planned layout will determine thermostat (and possibly slave thermostat) locations.
  • Page 25 HARNESS HARNESS 100 SQ-FT SYSTEM. Qty 1 Thermostat Qty 2 J-120 Harness Qty 1 J2-120 Harness THERMOSTAT J2-120 HARNESS S E C T I O N 5 S E C T I O N 5 EverWarm Radiant Floors PAGE 25...

  • Page 26: Installing Heating Film

    5. IF A NAIL OR STAPLE IS ACCIDENTALLY PLACED THROUGH ANY OF THESE AREAS, THE PENETRATION MUST BE REMOVED, AND THE HOLE NEEDS TO BE TAPED ON BOTH SIDES WITH THE EDGE SEALING TAPE. S E C T I O N 5 EverWarm Radiant Floors PAGE 26...

  • Page 27: Attaching Harness

    When finished, the Crimping Terminal must lay flat against the Heating Film and the bayonets must protrude through to the female side of the Crimping Terminal to be properly crimped. S E C T I O N 5 EverWarm Radiant Floors PAGE 27...

  • Page 28: Heating Film; Measuring Ohm's

    1 linear foot of Heating Film = 3.38 square feet of Heating Film. The linear foot calculation uses the full width (40.6 inches) of EverWarm Film. If a sheet is cut in half (20.30 inches), along the center white strip cut line, then the “linear feet”...

  • Page 29: Ohm's Readiness Test

    Edge Sealing Tape (part #EST-4.8-42) to enable you to completely tape over and cover/seal any holes that have been cut into the Heating Film (for angles, sockets, islands, etc.). S E C T I O N 5 EverWarm Radiant Floors PAGE 29...
  • Page 30 NOTE: FAILURE TO PERFORM THIS STEP WILL RESULT IN CONDUCTION OF ELECTRICITY FROM THE OPEN ENDS OF THE COPPER BUS BARS WHEN EMBEDDED IN THINSET. DO NOT SUBSTITUTE TAPE. S E C T I O N 5 EverWarm Radiant Floors PAGE 30...

  • Page 31: Installing Floor Sensor

    NOTE: CHECK WITH YOUR FLOORING MANUFACTURER FOR MAXIMUM TEMPERATURE RATING THAT IS APPROPRIATE FOR YOUR FLOORING AND SET YOUR THERMOSTAT ACCORDINGLY. S E C T I O N 5 EverWarm Radiant Floors PAGE 31...

  • Page 32: Electrical Requirements

    Once the thermostat has been installed, complete the set-up programming and make sure to program the floor sensor temperature to the flooring manufacturer’s desired temperature. S E C T I O N 5 EverWarm Radiant Floors PAGE 32...

  • Page 33: Section 6: 120 Volt Configuration

    SINGLE SHEET SET UP THERMOSTAT POWER FLOOR SUPPLY LOAD HEAT CONNECTION (LOAD) FLOOR SENSOR BREAKER BOX WALL BOX FLOOR FLOOR HEAT SENSOR (LOAD) THERMOSTAT FLOOR HEAT (LOAD) 144” S E C T I O N 6 EverWarm Radiant Floors PAGE 33...
  • Page 34 MULTI SHEET SET UP THERMOSTAT POWER FLOOR SUPPLY LOAD HEAT CONNECTION (LOAD) FLOOR SENSOR BREAKER BOX WALL BOX FLOOR FLOOR HEAT SENSOR (LOAD) THERMOSTAT FLOOR HEAT (LOAD) 144” S E C T I O N 6 EverWarm Radiant Floors PAGE 34...

  • Page 35: Section 7: 240 Volt Configuration

    SINGLE SHEET SET UP THERMOSTAT POWER FLOOR SUPPLY LOAD HEAT CONNECTION (LOAD) FLOOR SENSOR BREAKER BOX WALL BOX FLOOR FLOOR HEAT SENSOR (LOAD) THERMOSTAT FLOOR HEAT (LOAD) 144” S E C T I O N 7 EverWarm Radiant Floors PAGE 35...
  • Page 36 MULTI SHEET SET UP THERMOSTAT POWER FLOOR SUPPLY LOAD HEAT CONNECTION (LOAD) FLOOR SENSOR BREAKER BOX WALL BOX FLOOR FLOOR HEAT SENSOR (LOAD) THERMOSTAT FLOOR HEAT (LOAD) 144” S E C T I O N 7 EverWarm Radiant Floors PAGE 36...

  • Page 37: Section 8: Multiple Zones

    MULTIPLE ZONES SLAVE UNIT POWER FLOOR LOAD SUPPLY HEAT CONNECTION (LOAD) FLOOR SENSOR ZONE 3 SLAVE 3 ZONE 2 BREAKER BOX SLAVE 2 ZONE 1 THERMOSTAT SLAVE 1 S E C T I O N 8 EverWarm Radiant Floors PAGE 37...

  • Page 38: Section 9: Troubleshooting

    ELECTRICIAN. ANY TROUBLESHOOTING WORK SHOULD BE DONE WITH THE POWER REMOVED FROM THE CIRCUIT UNLESS OTHERWISE INDICATED. IF YOUR PROBLEM CAN’T BE RESOLVED WITH THESE TIPS, CALL EverWarm CORPORATION AT (855)558.5200. THESE TIPS ARE PROVIDED TO ASSIST WITH TROUBLESHOOTING THE FLOOR WARMING SYSTEM.

  • Page 39: Section 10: Warranty

    EverWarm Corporation extends warranty protection for the Product for any commercial customer who has installed the heating system in a commercial property owned by that customer, for a period of five (5) years. EverWarm Corporation shall, at its sole expense, during the course of the effective...

  • Page 40: Section 11: Notes

    NOTES Sub-floor: Voltage: Square Footage: Calculated ohms reading: Floor Covering: Actual ohms reading: FOR 120 VOLT INSTALLATIONS, USE THIS FORMULA: Example: A typical 10’ X 10’ (100 sq-ft) room will have approximately three sheets, for a total of 30 linear feet of Heating Film. Divide 218 by 30, yielding a calculated ohms reading of 7.27.
