evr-green
™
Level 1 / Level 2 Combination
Network Charging Station For Public Applications
Installation Guide
Bollard Mount
Pole Mount
Wall Mount
C
US
Listed

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the evr-green and is the answer not in the manual?

Questions and answers

Related Manuals for Leviton evr-green

Summary of Contents for Leviton evr-green

  • Page 1 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Installation Guide Bollard Mount Pole Mount Wall Mount Listed...

  • Page 2: Important Safety Instructions

    Reasonable effort was made to ensure that the specifications and other information in this manual are accurate and complete time without prior notice. Warranty information and disclaimer intended to be used or modified will void the limited warranty. Other than any such limited warranty, the Leviton products are Limitation of liability Copyright and Trademarks and other countries.

  • Page 3: Table Of Contents

    ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Table of Contents 1 Introduction Before installing stations .............................................................. 2 Installing a Bollard Mount Before you start................................... Overview of steps................................................
  • Page 4 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Table of Contents 5 Installing the holster and cable assembly Before you start................................. Overview of steps............................................................................... 6 Installing the head assembly Before you start..................

  • Page 5: Introduction

    Before Installing Stations The charging station is divided in to 3 Sections: 2.) Cable Assembly which installs second dimensional details. To download the bulletin, go to www.leviton.com/evrgreen. Detailed mounting instructions are provided for each mounting method: Before installing stations The instructions provided in this guide assume that the appropriate wiring, circuit protection, and metering is in place at the installation location.
  • Page 6 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Specifications Electrical input WARNING: Electrical output NOTE: Functional interfaces Ground Fault detection Plug-Out detection specification Safety and operational ratings supplemental surge protection at the service panel is recommended.
  • Page 7 ™ ™ Level 1 / Level 2 Combination Level 1 / Level 2 Combination Network Charging Station For Public Applications Network Charging Station For Public Applications Wiring information ,=9.YLLU 3L]LS 3L]LS  *VTIPUH[PVU :[H[PVU 40A, 2 POLE BREAKER MAY...

  • Page 8: Installing A Bollard Mount

    ™ Installing a Bollard Mount Level 1 / Level 2 Combination Network Charging Station For Public Applications Before you start You will need: with local codes Portal Instructions Overview of steps These steps are detailed in the remainder of this chapter.
  • Page 9 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 1 - Check box for correct contents Bollard Mount Assembly Bollard Mounting Template ANCHOR BOLT PATTERN 0.50 05.87 (12.7) (149.2) 02.00 BOLLARD OUTSIDE ENVELOPE (50.8)
  • Page 10 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 2 - Remove front panel To remove the front panel: loosen the 2 screws that fasten the panel to the body. panel upward to remove.
  • Page 11 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 3 - Remove mounting pole and base plate from body To remove the body: Loosen the four set screws to remove the pole.
  • Page 12 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 4 - Install J-Bolts and conduit Conduit must extend plate template to ensure correct above the concrete (check local codes) alignment. IMPORTANT: extend at least...
  • Page 13 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 5 - Mount base plate/pole assembly Pull all five wires up through the conduit and the mounting pole. Place the base plate/mounting pole assembly over the wiring conduit and washers as shown.
  • Page 14 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 6 - Install body pole and base plate. Ensure the body is level. pole by tightening the four set screws using the supplied allen wrench.
  • Page 15 TIP: To make it easier to connect the wires, you can remove and replace the terminal block. To do so, simply loosen the two mounting screws holding the For use in Evr-Green Level 1/Level 2 Combination Station terminal block to the body a few turns.
  • Page 16 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 8 - Replace front panel Tighten both set screws to secure the front panel supplied allen wrench to tighten the two set screws. onto its tab.

  • Page 17: Installing A Pole Mount

    ™ Installing a Pole Mount Level 1 / Level 2 Combination Network Charging Station For Public Applications Before you start You will need: Overview of steps body assembly involves a few simple steps: These steps are detailed in the remainder of this chapter.
  • Page 18 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 1 - Check box for correct contents 2 boxes (CTMER and CTMPR) containing: CTMPR Pole Bracket CTMER External Shell...
  • Page 19 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 2 - Drill hole in pole The maximum height above the surface maximum height...
  • Page 20 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 3 - Mount bracket to pole Align the bracket to the pole, ensuring the coupler opening in the bracket is centered over the hole in the pole.
  • Page 21 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 4 - Prepare body assembly for mounting Attach the pole conduit coupler to the body assembly as shown.
  • Page 22 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 5 - Mount body to bracket Insert the coupler into the hole and hold the body assembly to the pole bracket using the four supplied screws and washers.
  • Page 23 To do so, simply loosen the two mounting screws holding the For use in EVR-Green Level 1/Level 2 terminal block to the body a few turns Combination Station Input: 120 VAC, 60 Hz, 16 A...

  • Page 24: Installing A Wall Mount

    Installing a ™ Wall Mount Level 1 / Level 2 Combination Network Charging Station For Public Applications Before you start You will need: to drill into masonry Overview of steps Mounting Assembly involves a few simple steps:...
  • Page 25 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 1 - Check box for correct contents Mounting assembly ships in 2 boxes CTMWR Wall Mount Bracket CTMER External Shell Wall Mounting Template...
  • Page 26 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 2 - Attach bracket to wall correct alignment. NOTE: the holes on the left to a stud using and use wall anchors for the holes on the right.
  • Page 27 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 2 cont’d type of wall material (see previous page), fasten the wall bracket to the wall. fasten to stud...
  • Page 28 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 3 - Remove terminal block from main body Loosen the two fastening screws enough to slide the terminal block upward and remove. Loosen these 2 screws...
  • Page 29 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 4 - Drill holes in body assembly mounting holes in the back of the body assembly. These holes are partially mounting holes...
  • Page 30 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 5 - Attach body assembly to wall bracket Attach the body assembly to the wall and washers.
  • Page 31 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 6 - Attach coupler and connect conduit coupler to the body assembly, as shown, and connect the conduit.
  • Page 32 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 7 - Re-attach terminal block to main body two fastening screws then tighten the screws. TIP: You may find it easier to connect the wiring to the terminal block (as described...
  • Page 33 IMPORTANT: storms, add surge protection at the service panel for all circuits. For use in Evr-Green Level 1/Level 2 Combination Station Input: 120 VAC, 60 Hz, 16 A 208/240 VAC, 60 Hz, 30 A Use copper conductors only.

  • Page 34: Installing The Holster And Cable Assembly

    Installing the evr-green ™ Holster & Cable Assembly Level 1 / Level 2 Combination Network Charging Station For Public Applications Before you start You will need: In addition, the installation of the body assembly must be completed following the procedure described in a previous chapter.
  • Page 35 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 1 - Check box for correct contents Holster and cable assembly holster and cable assembly ships in a box Holster WARNING: head has been assembled and the unit has been provisioned.
  • Page 36 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 2 - Attach holster to body assembly Attach the holster to the body assembly using the four supplied bolts and washers. TIP: wrench in case you need to replace...
  • Page 37 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 3 - Install the cable assembly all the way until it is flush with the top of the front panel. Note: assembly is used for illustration purposes.
  • Page 38 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 3 - Install the cable assembly cont’d Plug the cable assembly’s rectangular connector into the body assembly’s terminal block. You have now finished installing the...

  • Page 39: Installing The Head Assembly

    ™ Installing the Head Assembly Level 1 / Level 2 Combination Network Charging Station For Public Applications Before you start You will need: In addition, the installation of the body assembly must be completed following the procedure described in a previous chapter.
  • Page 40 Step 1 - Check box for correct contents Head assembly retain this label for provisioning. Critical information will be needed such as MAC 76.20mm 3.000in Leviton Mfg. Co. Inc. Made in USA Patents Pending Model No: CTHxy PASSWORD AND Serial No: YYWWSSnnnnnn 25.40mm...
  • Page 41 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 2 - Slide head assembly into body enough to connect the wiring, then: terminal block, ensuring it is fully seated. If the circuit is live, the head assembly...
  • Page 42 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 3 - Verify that the station operates correctly Before securing the head assembly, follow these instructions to ensure that the charging station is fully operational: is live and the head assembly’s wiring...
  • Page 43 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 4 - Secure head assembly If necessary, open the door using a ChargePass card. IMPORTANT: push firmly into place using the Allen wrench until they are flush with the surrounding surface.
  • Page 44 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Step 5 - Provisioning & Testing the Head You will need: installation coordinator. complete the provisioning process.

  • Page 45: Troubleshooting

    Troubleshooting Understanding the station's display and the current state of each of its ports. The following example shows how a The top line displays the current state of the station’s charging port(s). This line includes a port number prefix and the state of each port is displayed sequentially. #1: AVAILABLE TAP CARD NEAR LOCK The bottom line displays more information about the current status and, if applicable, instructions...
  • Page 46 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Understanding error messages information about the type of error that has occurred. NOTE: In the messages shown on the following pages, the port number prefix is included only if the error applies only to a specific charging port.
  • Page 47 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Ground fault errors The following ground fault errors can occur during charging, or when attempting to begin a charging session: Cause/Other Symptoms: The station detected a ground fault during a charging session. The left or...
  • Page 48 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications User errors The following errors occur as a result of an inappropriate action that was performed by a person using the charging station. Cause/Other Symptoms: can occur if the vehicle did not start charging (i.e. the vehicle is not communicating with the charging station), or a cord was not connected to the vehicle within two minutes of opening the charging door.
  • Page 49 ™ Level 1 / Level 2 Combination Network Charging Station For Public Applications Other errors The following errors occur as a result of a potential equipment failure or utility failure. Cause/Other Symptoms: therefore you can not charge a vehicle. On a Level 2 charging port, you may also notice that the holster will remain locked and you can not release the charge connector.
