2. Parameter settings

Note: indicator software version 2.18 has the following new functionalities:
1. Possibility to install a new combined RS232/Bluetooth option board on the COM2 socket position:
- The RS232 can be set by the parameter setting for com2.1: 1
- The Bluetooth can be set by the parameter settings for com2.2: 2
- It is possible to have the RS232 and Bluetooth (for PDA) activated both.
2. Possibility to safe the initial parameter settings and calibration, as set in the workshop, in a
separate backup memory. These 'initial workshop settings' can always be restored once the scale
is in the field.
Enter the parameter menu by:
-Switch on the indicator and HOLD the ON/OFF key for at least 30 seconds.
-After 30 seconds the indicator shows automatically:
Par.
Function
01 Calibration and start-up units (and print units)
02 Smallest graduation step for multirange
03 Biggest graduation step for multirange
04 Number of divisions for every range
05 Weighing capacity system (full scale)
06 Motion tolerance for stable
07 Filter size
08 Auto zero range (zero track)
09 Zero range positive (+)
10 Zero range negative (-)
11 Test function (display service mode)
Power on – automatic zero
12
13 Approved / non-approved version
14 Sampling quantity (piece counting)
15 Units switch mode active
16 Setpoint function
* 17 Number of wires per loadcell (sence active)
18 Gravity value working area
19 Print format date/time
* 20 Baudrate com1
* 21 Setting com1
* 24 End character com1
* 25 Protocol com1
* 26 Number of linefeeds com1
* 27 Handshake com1
28 Printout format for com2.1
29 Header lines added
30 ≤2.15: Baudrate com2
2.18: Baudrate com2.1 & 2.2
31 ≤2.15: Setting com2
2.18: Setting com2.1 & 2.2
32 2.18: End character com2.2 only
34 End character com2
35 Protocol com2
P_ _ 00.
Default settings
Settings
EU US
1 2 1 = kg; 2 = lb
1 2 0.1/0.2/0.5/1/2/5/10/20/50
2 5 0.1/0.2/0.5/1/2/5/10/20/50
1000 1000 0000 - 9999 divisions
2500 5000 0-99999
1 1 off/0.5/1/2/4/8/16/32 grad./sec
8 8 off; 1-12 (1 light filtering, 12 high filtering)
0.5 0.5 off/0.5/1/3 grad./sec
10 10 0-100 % of span
10 10 0-100 % of span
basic basic basic/Adcount/10res
no no Yes/no
none none None/ntep/oiml/ntepC
10 10 1/2/5/10/20/50/95
yes yes no/yes
0 0 0 (not used); 1 (gross overload); 2 (net overload); 3
(fill manual tare); 4 (fill auto tare); 5 (gross overload
not authorize to change gross setting); 6 (net
overload not authorize to change net setting);
7(gross overload delayed); 8 (net overload
delayed); 9 (gross overload delay not authorize to
change gross setting); 10 (net overload delay not
authorize to change net setting);11(gross
overload+errors);12(gross overload+err,no
changes allowed);13(gross overload+err,delayed);
14(gross overload+err,delayed,no changes
allowed)
4 4 Fixed
9.812 9.797 9.750-9.850
EURO USA EU (dd/mm/yy);US (mm/dd/yy)
9600 9600 Fixed
8_n_1 8_n_1 Fixed
cr cr Fixed
5 5 Fixed (5=Bluetooth master)
4 4 Fixed
soft soft Fixed
stand stand stand;total;conf.
0 0 0 - 3
9600 9600 600/1200/2400/4800/9600/19200
8_n_1 8_n_1 8_n_1; 8_n_2; 7_n_1; 7_n_2
cr cr cr/lf/crlf
cr cr cr/lf/crlf
0 0 0(PC bi-directional);1(PC Excel format on print
command);2 (remote display);3 (printer protocol
with power control);4 (printer protocol without
power control);5 (not used);6 (PC Excel Format
SERVICE MANUAL
st
functionality.
nd
functionality.
