Ravas iForks Service Manual page 13

36 Number of linefeeds com2
37 Handshake com2
38 Print twice
** 39 2.18: Protocol com2.2 only
40 Level sensor
41 Delay trigger time level sensor
43 Compensation factor correction factor
44 Compensation factor X-direction
45 Compensation factor Y-direction
46 T compensation factor zero
48 T compensation factor span
49 Underload % of FS
60 Battery used
61 Low Bat switch-off time
62 Auto shut-off time indicator
63 Auto shut-off time BLT forks
64 Delay time sleep mode BLT master
65 Auto shut-off time backlight
66 Backlight brightness
67 Low bat switch off time forks
68 Buzzer function active
69 Disable keys 2, 3 and 4 (only if P16= active)
70 Tare clear
80 Digital corner calibration active
81 Compensation factor digital corner A
82 Compensation factor digital corner B
83 Compensation factor digital corner C
84 Compensation factor digital corner D
85 Matching Bluetooth forks
90 Recover factory default settings only, based on
actual P01 setting
91 ≤2.15: Default settings with changing calibration
2.18: Recover initial parameter settings +
calibration from backup (by P94)
92 ≤2.15: Recall stored settings calibration
2.18: Recover last (re-)calibration only. And
convert calibration to the actual startup unit
93 ≤2.15: Read out last 10 error messages
2.18: Read out last 50 error messages with
timestamp
94 2.18: Backup initial parameter settings +
calibration
95 Factory used only
96 Printout parameter setup
97 Key test function (buzzer and nr)
98 Scale id number
99 Software version
*
parameters not active for iForks, because Dual Bluetooth installed on COM1.
** Sequence when COM2.1&COM2.2 are both activated, first printing (COM2.1) and then communication with Bluetooth to PDA
(COM2.2).
Leave the parameter-menu and store all entries by pressing 2 times shortly on the CLR key.
with ack/nack);7 (mobile barcode printer); 8
(scanner serial prot.)
4 4 0-9
soft soft soft (Xon/Xoff)/hard (CTS)
0 0 0=print only once; 1=print twice
None None None; 0 (PC bi-directional)
Notes:
if P35 and P39 are set to 0 both, then P35 is
changed to None automatically
If P35 is set to 2, then P39 is changed to None
automatically.
If P35 is set to 8, then P39 is changed to None
automatically
no no no/ls nc/ls no/cs fa/cs ra/cs ls
3 3 0 -1 0 sec
1.0 1.0 0.1-10.0
1.0 1.0 0.1-10.0
1.0 1.0 0.1-10.0
0 0 Not active
0 0 Not active
002 002 0-100%
6v 6v 6V /12V
2 2 0 = never off;1-99 min
2 2 0 = never off;1-99 min
3 3 0 = never off; 1 = 30min;2 = 1h;3 = 2h
0 0 Not active
20 20 off/20/40/80/160/320 sec
100 100 100%/ 75%/ 50%/ 25%/ 0% (off)
10 10 0 = never off;1-99 min
no no Yes/no
0 0 0(keys enabled); 1(disable Tare function);
2(disable Tare and SUM function); 3(disable Tare,
SUM and Entry (key 4) function)
no no no: tare remains in memory after new weight has
been picked
yes: tare is cleared after new weight is picked
(default if P13 =OIML)
0 0 0 (enabled); 1 (disabled)
1.000 1.000 Do not change value after digital corner calibration
1.000 1.000 Do not change value after digital corner calibration
1.000 1.000 Do not change value after digital corner calibration
1.000 1.000 Do not change value after digital corner calibration
Only enter this parameter to establish a complete
new Bluetooth connection! Enter last 6 characters
of MAC-address of fork1 and 2 or cancel by
pressing CE
Note: for an actual registration of the 50 error
messages with timestamp the date and time must
be set first!
00000 00000 Note: Password protected
This backup should be executed in the workshop.
00000 00000
Pr-C1 Pr-C1 Pr-C1; Pr-C2
1 1 0 - 9999
2xx 2xx
