2. Parameter settings

To enter the parameter menu by:
- Switch on the indicator and HOLD the ON/OFF key for at least 30 seconds.
- After 30 seconds the indicator shows automatically:
Par. Function
01 Calibration and start-up units (and print units)
02 Smallest graduation step for multirange
03 Biggest graduation step for multirange
04 Number of divisions for every range
05 Weighing capacity system (full scale)
06 Motion tolerance for stable
07 Filter size
08 Auto zero range (zero track)
09 Zero range positive (+)
10 Zero range negative (-)
11 Test function (display service mode)
Power on – automatic zero
12
13 Approved / non-approved version
14 Sampling quantity
15 Units switch mode active
16 Setpoint function
17 Number of wires per loadcell (sence active)
18 Gravity value working area
19 Print format date/time
20 Baudrate com1
21 Setting com1
24 End character com1
25 Protocol com1
26 Number of linefeeds com1
27 Handshake com1
28 Printout format for com1 and com2
29 Header lines added
30 Baudrate com2
31 Setting com2
34 End character com2
35 Protocol com2
36 Number of linefeeds com2
37 Handshake com2
40 Level sensor
41 Delay trigger time level sensor
43 Compensation factor correction factor
44 Compensation factor X-direction
45 Compensation factor Y-direction
60 Battery used
61 Low Bat switch-off time
62 Auto shut-off time indicator
63 Auto shut-off time forks
64 Sleep time indicator if used
65 Auto shut-off time backlight
66 Backlight brightness
67 Low bat switch off time forks
68 Buzzer function active
80 Digital corner calibration active
81 Compensation factor digital corner A
P_ _ 00.
Default settings
Settings
EU US
kg lb kg;lb
1 2 0.1/0.2/0.5/1/2/5/10/20/50
2 5 0.1/0.2/0.5/1/2/5/10/20/50
1000 1000 0000 - 9999 divisions
2500 5000 0-99999
2 2 off/0.5/1/2/4/8/16/32 grad./sec
8 8 off; 1-12 (1 light filtering, 12 high filtering)
0.5 0.5 off/0.5/1/3 grad./sec
10 10 0-100 % of span
10 10 0-100 % of span
basic basic basic/count/res10
no no Yes/no
no no No/ntep/oiml
10 10 1/2/5/10/20/50/95
yes yes no/yes
0 0 0 (not used); 1 (gross overload); 2 (net overload); 3 (fill
manual tare); 4 (fill auto tare); 5 (gross overload not
authorize to change gross setting); 6 (net overload not
authorize to change net setting); 7(gross overload
delayed); 8 (net overload delayed); 9 (gross overload
delay not authorize to change gross setting); 10 (net
overload delay not authorize to change net setting)
4 4 4/6
9.812 9.797 9.750-9.850
EU US EU (dd/mm/yy);US (mm/dd/yy)
9600 9600 600/1200/2400/4800/9600/19200
8_n_1 8_n_1 8_n_1; 8_n_2; 7_n_1; 7_n_2
cr cr cr;lf;crlf
5 5 0(PC bi-directional NU); 1(PC Excel format on print
command); 2 (remote display); 3 (printer protocol with
power control); 4 (printer protocol without power
control); 5 (Bluetooth master)
4 4 0-9
soft soft soft (Xon/Xoff)/hard (CTS)
stnd stnd stnd;total;confi
0 0 0 - 3
9600 9600 600/1200/2400/4800/9600/19200
8_n_1 8_n_1 8_n_1; 8_n_2; 7_n_1; 7_n_2
cr cr cr/lf/crlf
0 0 0(PC bi-directional NU); 1(PC Excel format on print
command); 2 (remote display); 3 (printer protocol with
power control); 4 (printer protocol without power
control); 5 (Bluetooth master)
4 4 0-9
soft soft soft (Xon/Xoff)/hard (CTS)
no no no/ls nc/ls no/cs fa/cs ra
3 3 0 -1 0 sec
1 1 0.1-10.0
1 1 0.1-10.0
1 1 0.1-10.0
6 6 6V /12V
2 2 0 = never off; 1-99 min
2 2 0 = never off; 1-99 min
3 3 0 = never off; 1 = 30min; 2 = 1h; 3 = 2h
0 0 0 = not used; 1 to 99 min
20 20 off/20/40/80/160/320 sec
100 100 100%/ 75%/ 50%/ 25%/ 0% (off)
10 10 0 = never off; 1-99 min
off off off/ on (direct); on (2 sec. delay)
0 0 0 (enabled); 1 (disabled)
1.000 1.000 Do not change value after digital corner calibration
