Table Of Contents - Ravas iForks Service Manual

Table of contents

1. Calibration
1.1 Zero calibration
1.2 Corner calibration
2.3 Weight calibration
2. Parameter settings
2.1 To backup initial parameter settings + calibration
2.2 Check the (last) stored calibration memory
2.3 To change US setting into EU or EU settings into US, recover calibration settings
2.4 To recover initial parameter settings + calibration
3. Indicator startup routine - software version 2.18
4. Indicator power supply from fork lift truck battery - connection
Warning:
Only trained and authorized personnel are allowed to calibrate the scale.
NOTE !!!
Before starting the calibration procedure be sure the jumper JP1 is
connected.
Version 2014 and earlier
Deactivate Correction sensor(Tilt sensor) parameter P40=no
After Calibration procedure activate correction sensor P40= CS_FA
Remove JP1 for calibration lock.
We would like to inform you about the fact that this RAVAS product is 100 % recyclable on the basis
that the parts are processed and disposed off in the right manner.
More information can be found on our website www.ravas.com.
Rev.20150617
Printing/typographical errors and model changes reserved
Version 2015
SERVICE MANUAL
page
3
3
4
8
12
14
14
14
14
15
15
2
-iForks
