Regency liberty LRI6E Owners & Installation Manual

Gas insert

Hide thumbs Also See for liberty LRI6E:

Owners & installation manual (56 pages)

Owners & installation manual (72 pages)

Table Of Contents

Table of Contents

Quick Links

Liberty

LRI6E / Regency Horizon

MODELS: LRI6E-NG Natural Gas

HRI6E-NG Natural Gas

WARNING

FIRE OR EXPLOSION HAZARD

Failure to follow safety warnings exactly could result in serious

injury, death, or property damage.

appliance.

- WHAT TO DO IF YOU SMELL GAS

•

Do not try to light any appliance.

• Do not touch any electrical switch: do not use any phone in your building.

Leave the building immediately.

• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's

instructions.

Tested by:

919-382c

FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4

Gas Insert

LRI6E-LP Propane

HRI6E-LP Propane

Installer: Please complete the details on the back cover

and leave this manual with the homeowner.

Homeowner: Please keep these instructions for future reference.

HRI6E

Installation Manual

Owners &

05.02.17

Table of Contents

Need help?

Do you have a question about the liberty LRI6E and is the answer not in the manual?

Questions and answers

Summary of Contents for Regency liberty LRI6E

Page 1 Liberty LRI6E / Regency Horizon HRI6E Owners & ® ® Installation Manual Gas Insert MODELS: LRI6E-NG Natural Gas LRI6E-LP Propane HRI6E-NG Natural Gas HRI6E-LP Propane WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
Page 2 Congratulations! You are the owner of a state-of-the-art Gas Insert by Regency. The Regency Gas Insert Series of hand crafted appliances has been designed to provide you with all the provide you with economy, comfort and security for many trouble free years to follow.
Page 3: Table Of Contents
table of contents Dimensions Glass door removal / installation .........31 Vignette faceplate with Safety Screen installation ..32 Unit dimensions with Vignette faceplate ......4 Inlay installation ............33 Unit dimensions with Vignette faceplate + small 3 sided 4 sided faceplate with safety screen installation..34 backing plate ..............
Page 4: Dimensions
dimensions UNIT DIMENSIONS WITH VIGNETTE FACEPLATE UNIT DIMENSIONS WITH VIGNETTE FACEPLATE + SMALL 3 SIDED BACKING PLATE LRI6E / HRI6E Direct Vent Gas Insert...
Page 5: Unit Dimensions With Vignette Faceplate + Small Backing Plate + Spacer
dimensions UNIT DIMENSIONS WITH VIGNETTE FACEPLATE + SMALL BACKING PLATE + SPACER (1156mm) (94mm) (425mm) (1229mm) (262mm) (789mm) (770mm) (600mm) Not shown: Regular backing plate - 47-3/8" W. x 30-1/2" H. Oversize backing plate - 48-3/8" W. x 33" H. VIGNETTE FACEPLATE AND SPACER ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY.
Page 6: Unit Dimensions With 4 Sided Vignette Faceplate + Backing Plate
dimensions UNIT DIMENSIONS WITH 4 SIDED VIGNETTE FACEPLATE + BACKING PLATE LRI6E / HRI6E Direct Vent Gas Insert...
Page 7: Installation
This is a copy of the labels that accompany each HRI6E Gas Insert. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
Page 8: Ma Code - Co Detector
requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...
Page 9: Important Message
CAN/CGA B149 (in Canada) or the National AND OTHERS MAY BE SUSCEPTIBLE Fuel Gas Code ANSI Z223.1 in the U.S.A. This The Regency Gas Insert must be installed in TO ACCIDENTAL CONTACT BURNS. A appliance should be installed by a qualiﬁed gas accordance with these instructions.
Page 10: For Your Safety
installation FACTORY-BUILT (METAL) WOOD- GAS PRESSURE FOR YOUR SAFETY BURNING FIREPLACE TESTING REQUIREMENTS This appliance requires air for proper combustion. Always provide adequate combustion and The appliance must be isolated from the gas sup- ventilation air. Follow instructions and information ply piping system by closing its individual manual NOTE: Any parts that are removed must be removed in CAN/CGA B149 (in Canada) or the National Fuel...
Page 11: Installation Checklist
MINIMUM FIREPLACE DIMENSIONS sections "Minimum Fireplace Dimensions and Clearances to Combustibles) The minimum ﬁreplace clearances & dimensions for the Regency gas insert are shown in the following 2) Make the gas connection. (Refer to section "Gas diagrams: Connection") Gas connection is on the left side of the appliance.
Page 12: Minimum Clearances To Combustibles
Min. Hearth requirements - An R value of 1.75 is required to meet the requirements of the hearth in front of this appliance. 1" of Calcium Silicate board available from Regency, part number (296-936) plus 3/8" tile or equivalent would meet this requirement.
Page 13: Gas Connection
installation GAS CONNECTION The Air Intake and exhaust pipes must be attached to the inlet and exhaust collars of the termination cap with a minimum of three screws per pipe. GAS CONNECTION WARNING: Only persons licensed to work Part # Description with gas piping may make the 948-305...
Page 14: Flue / Vent Installation
installation FLUE / VENT INSTALLATION 4) Use the Flue Connector Slide Tool to slowly pull the Flue Connector NOTE: Flue Plate Connector Gasket Intake Liner Plate forward as you move the Insert rearward into the Fireplace Chase. must not be damaged or removed. Exhaust Liner Care must be taken to ensure that this Gear Clamps...
Page 15: Levelling Leg Adjustment
installation LEVELLING LEG ADJUSTMENT The LRI6E / HRI6E inserts are equipped with 2 rear levelling legs that are accessible while the appliance is in its ﬁnal installation position. The unit can be adjusted up to 5/16" (16mm). Remove left and right side ﬁller pieces. The rear levelling bolts are located in the back corners of the ﬁrebox and can be adjusted using a 7/16" wrench. Rotate the bolts clockwise to raise the rear of the ﬁrebox.
Page 16: Air Shutter Adjustment
NOT covered under warranty. Push to close - Pull to open Note: Aeration Adjustment should only be performed by an authorized Regency Installer at the time of installation or service. 16 | LRI6E / HRI6E Direct Vent Gas Insert...
Page 17: High Elevation
(11.14 kW) 5) Pilot Outlet Pilot Ignitor 6) Main Gas Outlet 7) Main Gas Inlet LRI6E-LP / HRI6E-LP SYSTEM DATA contact your Regency dealer for further ® Min. Supply Pressure 11" WC (2.73 kpa) instructions. Manifold Pressure 10" WC (2.49 kpa) Incorrect ﬂame pattern will have small, probably...
Page 18: Conversion From Ng To Lp
installation L540E / HZI540E CONVERSION FROM NG TO LP CONVERSION FROM NG TO LP LRI6E/HRI6E using SIT 885 NOVA Gas Valve L540E/HZI540E using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! WARNING This conversion kit shall be installed by a qualiﬁed service agency in ac- cordance with the manufacturer’s instructions and all applicable codes and...
Page 19 L540E / HZI540E installation 6) Re-attach the Pressure Regulator wire, and re-situate the Gas Valve, se- 10) Unscrew the pilot oriﬁce with the allen key; then replace with the LPG pilot cure the screws that fasten the Gas Valve Mounting Brackets. oriﬁce and the pilot cap, provided in the kit.
Page 20: (Lri6E / Hri6E)
installation PROFLAME REMOTE SYSTEM GTMF WITH FAN (LRI6E / HRI6E) WIRING DIAGRAM Proflame System Configuration 886 GTMF Wire Diagram SureFire™ Switch 0.584.907 Ground Black Neutral Green Live Fan Thermodisc Ground 120V AC 60 Hz (normally open) Black Black Black GTMF REMOTE SYSTEM - IMPORTANT: The 120V fan control module serves as the power source for this unit. The AA batteries in the receiver only serve as a backup in case 120 volt power lost within the home.
Page 21: Glass Crystal / Optional Stone Installation
installation GLASS CRYSTAL / OPTIONAL STONE INSTALLATION Spread the Glass Crystals or Stones evenly over the burner. Ensure the crystals/stones do not overlap excessively as this will affect the ﬂame pattern. IMPORTANT NOTE: Only the supplied approved Glass Crystals and Stones are to be used with these ﬁreplaces. Use of any other type of glass crystals or stones can alter the unit's performance, any damage caused by the use of any unapproved glass or stones will not be covered under warranty.
Page 22 HZI540EB ADDENDUM installation CAUTION DO NOT place spa stones or volcanic stones over pilot and burner ports. No spa stones in this area. No volcanic stones in this area. 22 | LRI6E / HRI6E Direct Vent Gas Insert 09/28/11...
Page 23: Hri6E Optional Log Set Installation
HRI6E / HRI4E installation HRI6E OPTIONAL LOG SET INSTALLATION OPTIONAL LOG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs and glass crystals may create carbon build-up and can alter the unit's performance which is not cov- ered under warranty.
Page 24 HRI6E / HRI4E installation 5. Place Log 3, rest on Log 2, match pin locator on Log 3 with landing 3. Place Log 1 on Rear Log Bracket in front of tabs, ensure Log is pin on Log 1. Angle the longest point on Log 3 is approximately 1/4' centered.
Page 25 HRI6E / HRI4E installation 8. Place Log 6 - rest on Log 3 as shown below. Position Log 6 9. Place Log 7 on the glass as shown below. Position Log 7 10. Place embers and Lava rocks on the glass as shown below. Note: Properly positioned, Logs 3 &...
Page 26: Lri6E Log Set Installation
LRI6E installation LRI6E LOG SET INSTALLATION LOG INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. *For Touch Ups: Satin Black paint is included for burner, and Dark Brown Paint is included for log set, Rear Centre Log Left Side Log...
Page 27: Log Installation
LRI6E installation LOG INSTALLATION Log 3 in position Log 5 in position 6. Place Log 4 on the burner in the location shown below. 8. Line locator at top of Log 6 with provision on Log 1 - the locator at the bottom of Log 6 should line up with the provision on Log 5.
Page 28: Standing Pilot And Heat Exchange Return
installation STANDING PILOT AND HEAT EXCHANGE RETURN ADDING THE HEAT EXCHANGER RETURN The LRI6E / HRI6E use a heat exchanger and efﬁcient combustion technol- ogy to provide extreme heating efﬁciencies. The more efﬁcient an appliance 1) Remove the panels if they are already installed. Remove one screw becomes, the lower the ﬂue gas temperatures becomes.
Page 29: Brick Panel Installation
installation BRICK PANEL INSTALLATION BRICK PANEL INSTALLATION Brick panels are soft and fragile. Use caution when handling the panels, Exhaust Baffle being careful not to jar them or scratch the painted surfaces. Firebox Liner Rear Firebox Liner Right Firebox Liner Left Firebox Liner Left Upper Left of Firebox Diagram 1...
Page 30: Enamel Panel Installation
HRI6E / HRI4E installation ENAMEL/STEEL PANEL INSTALLATION ENAMEL PANEL INSTALLATION 1. Remove ﬁller sections from right and left sides of the burner and discard Before you Start: - see below. Black Enamel Panels • Black Enamel panels must be inspected for scratches and dimples prior to installation.
Page 31: Glass Door Removal / Installation
installation GLASS DOOR REMOVAL / INSTALLATION WARNING: Do not operate the appliance with the glass panels removed, cracked or broken. Replacement of the glass panels service person. 1) Insert the door tool into the lower door latch. Window Clip (x4) Door Frame Glass Gasket Retainer Window Glass Gasket...
Page 32: Vignette Faceplate With Safety Screen Installation
installation VIGNETTE FACEPLATE VIGNETTE FACEPLATE WITH SAFETY SCREEN INSTALLATION VIGNETTE FACEPLATE W/ SAFETY SCREEN INSTALLATION Black Chrome Handling Instructions MUST Failure to do this will result in burn stains on panels which you will be unable to remove. 3. Install the Vignette faceplate by hooking the ﬂange over the hanger 1.
Page 33: Inlay Installation
installation INLAY INSTALLATION INLAY INSTALLATION 1. Remove Vignette faceplate from unit and lay on a soft surface. 3. Position the inlay face down on the back of the Vignette faceplate and reinstall the safety screen assembly (reverse Step 2). 4. Reinstall the Vignette faceplate with inlay onto unit—reverse Step 1. 2.
Page 34: Sided Faceplate With Safety Screen Installation
installation 4 SIDED FACEPLATE WITH SAFETY SCREEN INSTALLATION 1. Install the outer faceplate and secure with 5 screws as shown. 2. Install the outer faceplate by hooking the ﬂange over the hanger as shown. 34 | LRI6E / HRI6E Direct Vent Gas Insert...
Page 35: Spacer Installation
installation 4E/6E SPACER INSTALLATION SPACER INSTALLATION 1. Remove Vignette faceplate from unit and lay on a soft surface. 4. Place the spacer on a soft cloth on the ﬂoor. Lay the outer faceplate over the spacer and line up the 7 holes. Attach the 3 piece spacer to the back of the outer faceplate from the front with 7 screws (3 along the top and 2 on each side).
Page 36: Backing Plate Installation
installation 4E/6E BACKING PLATE INSTALLATION BACKING PLATE INSTALLATION 1. Remove Vignette faceplate from unit and lay on a soft surface. 3. Attach the backing plate to the outer faceplate from the front with 7 screws (3 along the top and 2 on each side). 4.
Page 37: Optional Mantel Deflector Installation
installation 4E/6E OPTIONAL MANTEL DEFLECTOR INSTALLATION MANTEL DEFLECTOR INSTALLATION NOTE: A mantel deﬂector may be installed to reduce the minimum 4. Install the mantel deﬂector in between the back of the outer face- mantel height. Refer to the instruction manual for minimum plate and the front of the backing plate.
Page 38: Optional Hearth Trim Installation - Vignette Faceplate With Spacer
LRI4E/HRI4E/LRI6E/HRI6E/E33 operating instructions OPTIONAL HEARTH TRIM INSTALLATION OPTIONAL HEARTH TRIM INSTALLATION - VIGNETTE FACEPLATE WITH SPACER VIGNETTE FACEPLATE WITH SPACER AND LOW PROFILE FACEPLATE Customizing the Hearth Trim: 5) Secure the hearth trim with a clip on its side to keep it steady as shown in the diagram below .
Page 39: Optional Hearth Trim Installation - Vignette Faceplate Without Spacer
operating instructions LRI4E/HRI4E/LRI6E/HRI6E/E33 OPERATING INSTRUCTIONS OPTIONAL HEARTH TRIM Before operating this appliance, proceed through the following check list. INSTALLATION - VIGNETTE FACEPLATE WITHOUT SPACER 1) Read and understand these Instructions before operating this appliance. Customizing the Hearth Trim 2) Check to see that all wiring is correct and enclosed to prevent possible shock. The Hearth Trim can be adjusted to custom ﬁt an installation by 3) Check to ensure there are no gas leaks.
Page 40: Lighting Procedure
operating instructions LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has several options for starting/operating the appliance using the power button 3. After approximately 4 seconds the spark ignition system will spark for 60 and ON/OFF key on the hand held transmitter. seconds to light the main burner.
Page 41: Copy Of Lighting Instruction Plate
Blower: l'information fournie avec cet appareil. Pour obtenir de l'aide ou des informations supplémen- Regency gas appliances use high tech blowers to push heated air farther into the room. It is not A) This appliance is equipped with an ignition device which automatically lights the pilot.
Page 42: Maintenance
GUARD REMOVED FOR SERVICING AN and louvers with a damp cloth. Never use an Regency dealer only, and follow our step-by-step APPLIANCE MUST BE REPLACED PRIOR abrasive cleaner. The gold louvers (and optional instructions for replacement.
Page 43: Pilot Adjustment
Pilot Ignitor Continuous condensation can cause corrosion of caps, pipe, and ﬁttings. It may be caused contact your Regency ® dealer for further by having excessive lateral runs, too many instructions. elbows, and exterior portions of the system being exposed to cold weather.
Page 44: Glass Crystal Burner Removal / Installation (Hri6E)
maintenance GLASS CRYSTAL BURNER REMOVAL / INSTALLATION (HRI6E) GLASS BURNER INSTALL Disconnect unit from gas supply and allow unit to cool before removing burner. GLASS BURNER REMOVAL 1) Lift the burner assembly with both hands. Point the mixing tube towards the rear of the ﬁrebox.
Page 45: Lri6E Ceramic Burner Removal / Installation
maintenance LRI6E CERAMIC BURNER REMOVAL / INSTALLATION INSTALLATION REMOVAL 1) Remove left and right side panels by sliding them forward - see below. Care must be taken when installing the burner into the ﬁrebox. Do not damage, knock or scrape the pilot assembly. The ﬂame sensor and ignition lead are fragile and can be damaged easily.
Page 46: Fan Maintenance - With Gtmf Remote Control
maintenance FAN MAINTENANCE - WITH GTMF REMOTE CONTROL Note: To access the side and rear access panels both the gas and venting 4) Remove 3 screws and remove the fan from the unit as shown below. will need to be disconnected(see vent/ﬂue installation in this manual) for proper removal.
Page 47: Valve Replacement
maintenance VALVE REPLACEMENT Before you begin: 5) Disconnect the Pilot Supply Line from the Gas Valve * Shut off the gas supply to the unit. Disconnect all electrical supply to the unit. Always let the appliance cool to room temperature before servicing. Remove unit ﬂue collars.
Page 48 maintenance 11) There is a provision in the Valve body casting that is designed to be 8) Remove the Gas Valve by lifting upwards and outwards. used as a gripping point for assembly with other components. This is the portion of the valve that can be placed in a machine vice. 9) Secure the Valve Assembly by the 90 Elbow Fitting in a sturdy table vice.
Page 49: Main Assembly
parts list MAIN ASSEMBLY Part # Description Part # Description 940-372/P Window Glass 396-031 Bracket Valve Mounting Lh/Rh 911-085 Valve LP 885 SIT IPI 0.885.002 936-159 Window Gasket (per ft. - 9ft. required) 911-084 Valve NG 885 SIT IPI 0.885.002 396-042f Slide / Door Tool 399-574/P...
Page 50: Parts List
parts list 50 | LRI6E / HRI6E Direct Vent Gas Insert...
Page 51 parts list Part # Description Not Shown 299-811 Vignette Door Inlay Tuscan Sunset 299-825 Backing Plate Vignette Small 299-812 Vignette Door Inlay Black Chrome 299-826 Backing Plate Vignette Regular 299-813 Vignette Door Inlay Metallic Black 299-827 Backing Plate Vignette Oversize 299-814 Vignette Craftsman Inlay Tuscan Sunset 299-818...
Page 52: Warranty
FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: December 2016 Regency Gas Products Warranty 52 | LRI6E / HRI6E Direct Vent Gas Insert...
Page 53 Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: December 2016 Regency Gas Products Warranty | 53 LRI6E / HRI6E Direct Vent Gas Insert...
Page 54 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
Page 55 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
Page 57 notes | 57 LRI6E / HRI6E Direct Vent Gas Insert...
Page 58 notes 58 | LRI6E / HRI6E Direct Vent Gas Insert...
Page 60 Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ HZI540 Product Video LRI6E Product Video Regency and Regency Horizon, are trademarks of FPI Fireplace Products International Ltd. ® Printed in Canada © Copyright 2017, FPI Fireplace Products International Ltd. All rights reserved.
