WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
919-442
REGENCY FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4
L234 Gas Insert
MODELS:
L234-NG10 Natural Gas
Owners & Installation Manual
L234-LP10 Propane
12.01.14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency L234-NG10
Summary of Contents for Regency L234-NG10
- Page 1 Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 919-442 REGENCY FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4 12.01.14...
- Page 2 As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace.
-
Page 3: Table Of Contents
Gas Insert Aeration adjustment ........14 Valve Replacement ............32 Gas Pipe Pressure Testing ..........15 Main Assembly ............34 SIT 829 Valve Description ...........15 Warranty ..............39 Conversion from NG to LP...........16 Optional Brick Panel Installation .........17 Regency L234-10 Direct Vent Gas Insert ®... -
Page 4: Safety Decal
é Certified to: CAN/CGA-2.17-M91(R2009) Tested to: ANSI Z21.88-2014 & CSA 2.33-2014 Serial No. / No de serie 4001172 NOTE: Regency units are constantly being É QUIP A L'UISINE POUR GAZ NATURAL É NATURAL GAS FIREPLACE INSERT: MODEL L234-NG10 improved. Check the label on the unit and Factory Equipped For Altitude 0-4500ft. -
Page 5: Ma Code - Co Detector
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency L234-10 Direct Vent Gas Insert ®... - Page 6 Shown with Low Profile Faceplate Regency L234-10 Direct Vent Gas Insert ®...
-
Page 7: For Your Safety
ALERTED TO THE HAZARDS OF HIGH AN APPLIANCE MUST BE REPLACED SURFACE TEMPERATURES, ESPE- PRIOR TO OPERATING THE APPLIANCE. CIALLY THE FIREPLACE GLASS, AND SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION. Regency L234-10 Direct Vent Gas Insert ®... -
Page 8: Important Message
It is imperative that control compartments, removed. NOTE: Any alterations made to the burners and circulating air passageways of The Regency Direct Vent Gas Insert must be listed solid fuel burning factory built fireplace the appliance be kept clean. installed in accordance with these instructions. -
Page 9: Installation Checklist
Aeration System" section. the liner. Ensuring that the appliance is venting The Regency Gas Insert is installed as listed correctly. below. 1) Check all clearances to combustibles. Refer to the following sections where... -
Page 10: Minimum Clearances To Combustibles
Top of Top of Door Frame Door Frame Combustible Faceplate Hearth Faceplate Flooring 4” min Existing or Combustible Non-Combustible Hearth Hearth Flooring 12” Min. 4” min Existing or Non-Combustible Hearth 12” Min. 10 | Regency L234-10 Direct Vent Gas Insert ®... -
Page 11: Venting
Regency Co-linear DV Vertical Termination Cap, Flashing 948-305 3" Flex - 35 ft. (intake & exhaust) & 2" Collar 946-529 Regency Co-linear DV Vertical Termination Cap & Flashing Vent Restrictor Burner Aeration Vent Restrictor Burner Aeration Vent Run Vent Run... -
Page 12: Converting From 3" & 3" Venting To 3" & 2
5) Once the vent restrictor plate is in the required position, secure using the 4 screws removed from step 3. 6) Re-install brick panels if removed. 7) Re-install glass door. Top Plate with 2" Collar shown on Unit 12 | Regency L234-10 Direct Vent Gas Insert ®... -
Page 13: Flue Liner Installation
2) Mill-pac may be used instead of high tempture silicone and screws may be used instead of gear clamps at connections of liner to inlet and vent collars. Regency L234-10 Direct Vent Gas Insert ®... -
Page 14: Gas Insert Aeration Adjustment
Note: Any damage due to carboning resulting from improperly setting the aeration controls is NOT covered under warranty. Note: Aeration Adjustment should only be performed by an authorized Regency Installer at the time of installation or service. 4. Remove the logs. 1. Remove the outer faceplate. -
Page 15: Gas Pipe Pressure Testing
6) When finished reading manometer, turn off the gas valve, disconnect the hose and tighten the screw (clockwise) with a 1/8" flat screwdriver. Note: Screw should be snug, but do not over tighten. Regency L234-10 Direct Vent Gas Insert ®... -
Page 16: Conversion From Ng To Lp
NOTE: before re-installng burner, check the LP aeration settings. Burner Removed 17. Check operation of fl ame control. 18. Check for proper fl ame appearance and glow on logs. 16 | Regency L234-10 Direct Vent Gas Insert ® 919-465 11.25.14... -
Page 17: Optional Brick Panel Installation
2) Insert the back brick panel by carefully placing it against the back wall of the fi rebox and rest it on the rear log tray. Back Brick Panel Brick Clip Rear Log Tray Right Side Brick Panel Completed Brick Panel Installation Regency L234-10 Direct Vent Gas Insert ® 918-686 04/13/07... -
Page 18: Safety Screen Install
2. Install screen assembly and glass door together and secure with spring hooks on left and right side. To remove see "Glass Door Removal" instructions. Spring Hook 2. To reinstall–reverse steps. 18 | Regency L234-10 Direct Vent Gas Insert ®... -
Page 19: Log Set Installation
1) Carefully remove the logs from the box and unwrap them. The logs are fragile, handle with care - do not force into position. 2) Fit log 2-711 into the pins on the rear log tray. 2-712 2-711 Regency L234-10 Direct Vent Gas Insert ® 01/03/08 918-674a... - Page 20 5) Fit the left side of log 2-713 into the pin on log 2-714 and rest the right side of the log on the burner plate pushing it against the tab. 2-713 Notch 2-714 2-712 2-713 20 | Regency L234-10 Direct Vent Gas Insert ® 918-674a 01/03/08...
- Page 21 Right side of Burner Also place a few embers along the burner tube next to log 2-713. Separate platinum embers and place on and around the embers. Avoid stacking platinum embers. 2-713 Regency L234-10 Direct Vent Gas Insert ® 01/03/08 918-674a...
- Page 22 L234 Completed Log Set Installation 2-711 2-715 2-712 2-713 2-714 2-716 22 | Regency L234-10 Direct Vent Gas Insert ® 918-674a 01/03/08...
-
Page 23: Low Profile Faceplate Installation
12 pin connector marked "receiver" and fan wires from the fan wiring harness and tuck all wires into bracket. See wiring diagram for details. Fan wire through grommet Plug in receiver Regency L234-10 Direct Vent Gas Insert ® 11.03.14 919-475... -
Page 24: Hearth Trim Installation
1 screw through hearth trim bracket and lower leg of facepalte backing on each side as shown in Diagram 1. Completed Hearth Trim Installation: Diagram 1 Diagram 4 24 | Regency L234-10 Direct Vent Gas Insert ® 11.03.14 919-477... -
Page 25: Wiring Diagrams
Ground Live 120V AC #8 Ground Lug 60 Hz Power cord ground ground REMOTE wire Minimum Convection Air Temp. Switch Electrode Spark Box (+) (-) Electrode Black White Green TPTH Thermostat (Optional) (Millivolt) Regency L234-10 Direct Vent Gas Insert ®... -
Page 26: Optional Wall Thermostat
(noted on label) at 15 minutes. NOTE: The battery in the DC Sparker Box will length. Regency offers an optional programmable need to be replaced annually. thermostat but any 250-750 millivolt rated non-... -
Page 27: First Fire
8) The unit should never be turned off, and on Diagram 1 again without a minimum of a 60 second wait. 9) Hook up remote receiver to wire marked 'receiver' Regency L234-10 Direct Vent Gas Insert ®... -
Page 28: Copy Of Lighting Instruction Plate
Reportez-vous au manuel du propriétaire de l'information fournie avec cet appareil. Pour obtenir de l'aide ou des informations supplémen- Regency gas appliances use high tech blowers taires consulter un installateur qualifi é, une agence de service ou fournisseur de gaz. -
Page 29: Maintenance Instructions
Regency dealer for should only be refinished with heat resistant further instructions. paint (not with wall paint). Regency uses StoveBrite Paint - Metallic Black #6309. LOG REPLACEMENT 3) Make a periodic check of the burner for The unit should never be used with broken logs. -
Page 30: Fan Replacement
7) Remove the burner by undoing the 3 screws. Burner Tray Removed Spring Hook 9) Remove the rear log tray by undoing the 3 screws. Outside opening Burner Removed Rear Log Tray Removed 30 | Regency L234-10 Direct Vent Gas Insert ®... - Page 31 16) Reverse steps 14 - 1. Fan Cover Plate Removed 11) Unplug the fan connector wires. 14) Remove the ground screw which holds the ground wire. Ground Wire Regency L234-10 Direct Vent Gas Insert ®...
-
Page 32: Valve Replacement
4) Remove brick panels, if installed. 5) Remove the valve shield by undoing the 2 screws. Spring Hook Valve Shield 9) Unplug the 2 connectors from the valve. Outside Bracket opening 32 | Regency L234-10 Direct Vent Gas Insert ®... - Page 33 Rear Log Tray Removed Burner Removed 11) Remove the burner tray by undoing the 4 13) Remove the 12 screws that hold the valve screws. tray to the firebox and carefully pull out. Burner Tray Removed Regency L234-10 Direct Vent Gas Insert ®...
-
Page 34: Main Assembly
Complete Log Set 904-430 Orifice #42 - NG 537-969 Conversion Kit LP 537-940 Hearth Trim 904-163 Orifice #54 - LP 936-170 Orifice Gasket 919-442 Manual * Not available as a replacement part. 34 | Regency L234-10 Direct Vent Gas Insert ®... - Page 35 MAIN ASSEMBLY Regency L234-10 Direct Vent Gas Insert ®...
- Page 36 537-924 Low Profile Faceplate 36 | Regency L234-10 Direct Vent Gas Insert ®...
- Page 37 Regency L234-10 Direct Vent Gas Insert ®...
- Page 38 38 | Regency L234-10 Direct Vent Gas Insert ®...
-
Page 39: Warranty
Conditions: Any part or parts of this unit which in our judgement show evidence of such defects will be repaired or replaced at Regency's option, through an accredited distributor or agent provided that the defective part be returned to the distributor or agent Transportation Prepaid, if requested. - Page 40 Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Liberty L234 Product Video Regency and Liberty are trademarks of Regency Fireplace Products International Ltd. © Copyright 2014, Regency Fireplace Products International Ltd. All rights reserved. Printed in Canada...
