Liberty ® LRI3E / Regency Horizon ® HRI3E
MODELS: LRI3E-NG Natural Gas
HRI3E-NG Natural Gas
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other lammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the ire department.
- Installation and service must be performed by a qualiied installer, service agency or the gas supplier.
Tested by:
919-699
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Gas Insert
LRI3E-LP Propane
HRI3E-LP Propane
Installer : Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
www.regency-ire.com
01.19.17
Advertisement
Table of Contents
Related Manuals for Regency liberty LRI3E
Summary of Contents for Regency liberty LRI3E
- Page 1 Liberty ® LRI3E / Regency Horizon ® HRI3E Owners & Installation Manual Gas Insert www.regency-ire.com MODELS: LRI3E-NG Natural Gas LRI3E-LP Propane HRI3E-NG Natural Gas HRI3E-LP Propane WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Page 2 Congratulations! You are the owner of a state-of-the-art Gas Insert by Regency. The Regency Gas Insert Series of hand crafted appliances has been designed to provide you with all the warmth and charm of a ireplace, at the lick of a switch. The models LRI3E / HRI3E of this series have been approved by Warnock Hersey/Intertek for both safety and eficiency.
-
Page 3: Table Of Contents
table of contents Dimensions LRI3E log set installation ...........24 Unit dimensions with vignette faceplate ......4 Brick panel installation ..........26 Unit dimensions with vignette faceplate + Painted black and enamel panel installation ....27 small backing plate ............4 Glass door removal / installation........28 Unit dimensions with 4 sided vignette faceplate + Vignette faceplate with Safety screen installation ..29 backing plate ..............5... -
Page 4: Unit Dimensions With Vignette Faceplate
dimensions UNIT DIMENSIONS WITH VIGNETTE FACEPLATE 28” (711mm) 21-5/16” (540mm) 10-3/8” 29-1/16” (738mm) (262mm) 26” (660mm) 22-3/4” (576mm) UNIT DIMENSIONS WITH VIGNETTE FACEPLATE + SMALL BACKING PLATE 28” 711mm 21-5/16” 540mm 31-1/4” 794mm 29-1/16” 738mm 22-11/16” 576mm Not Shown: Regular backing plate - 35-3/4" W x 25-5/8" H Oversize backing plate - 38-3/16"... -
Page 5: Unit Dimensions With 4 Sided Vignette Faceplate + Backing Plate
dimensions UNIT DIMENSIONS WITH 4 SIDED VIGNETTE FACEPLATE + BACKING PLATE 28” 711mm 21-5/16” 540mm 35-3/4” 908mm 29-1/4” 743mm 10-3/8” 262mm 3” 14” 76mm 355mm LRI3E / HRI3E Direct Vent Gas Insert... -
Page 6: Copy Of Safety Label Hri3E
COPY OF SAFETY LABEL HRI3E This is a copy of the labels that accompany each HRI3E Gas Insert. We NOTE: Regency units are constantly being improved. Check the label on have printed a copy of the contents here for your review. -
Page 7: Copy Of Safety Label Lri3E
COPY OF SAFETY LABEL LRI3E This is a copy of the labels that accompany each LRI3E Gas Insert. We NOTE: Regency units are constantly being improved. Check the label on have printed a copy of the contents here for your review. -
Page 8: Ma Code - Co Detector
requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 9: Important Message
IN THE SAME AREA AS THE APPLI- INSTRUCTIONS ANCE. TODDLERS, YOUNG CHILDREN The Regency Gas Insert must be installed in AND OTHERS MAY BE SUSCEPTIBLE The LRI3E / HRI3E Gas Inserts must be installed in accordance with these instructions. Carefully read TO ACCIDENTAL CONTACT BURNS. -
Page 10: Gas Pressure Testing
installation General Safety Information GAS PRESSURE FACTORY-BUILT (METAL) WOOD- BURNING FIREPLACE TESTING 1) The appliance installation must conform with REQUIREMENTS local codes or in the absence of local codes, The appliance must be isolated from the gas sup- with CAN/CGA B149 (in Canada) or the National ply piping system by closing its individual manual Fuel Gas Code ANSI Z223.1 in the U.S.A. -
Page 11: Installation Checklist
1) Check all clearances to combustibles, (Refer to MINIMUM FIREPLACE DIMENSIONS sections "Minimum Fireplace Dimensions and Clearances to Combustibles) The minimum ireplace clearances & dimensions for the Regency gas insert are shown in the following diagrams: 2) Make the gas connection. (Refer to section "Gas Connection") 3) Install the two liners (2"... -
Page 12: Minimum Clearances To Combustibles
installation MINIMUM CLEARANCES TO COMBUSTIBLES The clearances listed below are Minimum distances unless otherwise stated: A major cause of ires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this decorative gas appliance be installed only in accordance with these instructions. Clearance: Dimension Measured From:... -
Page 13: Gas Connection
Ensure that the Insert is level. 948-316 2" Flex - 35 ft. (intake) 946-582 Regency Co-linear DV Vertical Termination Cap, Flashing & 4) Do not cut any sheet-metal parts of the ire- 2" Collar place, in which the gas ireplace insert is to be installed. -
Page 14: Alternate Approved Cap/Adaptor
installation ALTERNATE APPROVED CAPS/ADAPTOR STANDING PILOT 46DVA-GK 3" Co-linear Adaptor with lashing The LRI3E / HRI3E use a heat exchanger and eficient combustion technol- ogy to provide extreme heating eficiencies. The more eficient an appliance 46DVA-VC Vertical Termination Cap becomes, the lower the lue gas temperatures becomes. 46DVA-VCH High Wind Cap On start-up, lue temperatures are required to initiate venting action. -
Page 15: Flue / Vent Installation
installation FLUE / VENT INSTALLATION NOTE: Flue Plate Connector Gasket must not be damaged or removed. Care must be taken to ensure that this 4. Use the Flue Connector Slide Tool to slowly pull the Flue Connector gasket remains intact to prevent lue Plate forward as you move the Insert rearward into the Fireplace Chase. -
Page 16: Air Shutter Adjustment
Note: any damage due to carboning resulting from improperly setting the aeration controls is NOT covered under warranty. burner burner cover Note: Aeration Adjustment should only be performed by an authorized HRI3E Regency Installer at the time of installation or service. First Fire & Aeration Screw to adjust aeration 16 | LRI3E / HRI3E Direct Vent Gas Insert... -
Page 17: High Elevation
5) Bottom Inlet Maximum Input 21,000 Btu/h 6) Bottom Outlet (6.15 kW) 7) Outlet Pressure Tap Note: If you have an incorrect lame pattern, 8) Inlet Pressure Tap contact your Regency dealer for further LRI3E-LP / HRI3E-LP ® 9) Side Outlet instructions. 10) Side Inlet SYSTEM DATA Max. Supply Pressure 14'' WC (3.45 kpa) -
Page 18: System With Fan (Lri3E / Hri3E)
installation SYSTEM WITH FAN (LRI3E / HRI3E) BLACK GREEN GREEN GOLD GREEN VALVE BLACK CONTROL MODULE BLACK RECEIVER BATTERY BLACK BLACK Caution: Ensure that the wires do not touch any CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause hot surfaces and are away from sharp edges. improper and dangerous operation. If any of the original wire as supplied with the appliance must be replaced, it must be replaced with type CPE wire or its equivalent. 18 | LRI3E / HRI3E Direct Vent Gas Insert... -
Page 19: Conversion From Ng To Lp
installation CONVERSION FROM NG TO LP LRI3E /HRI3E using GV60 Maxitrol Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! 3. Remove conversion plug (located between the control knobs) with a long WARNING fl... - Page 20 installation HRI3E - Remove the burner by removing 5 screws in locations shown below 7. Replace the NG pilot orifi ce with the supplied LP pilot orifi ce using the to remove burner cover and 2 screws to remove burner (shown below). supplied 5/32"...
-
Page 21: Media Installation
installation MEDIA INSTALLATION Spread the Media evenly over the burner. Ensure installed media does not overlap excessively as this will affect the lame pattern. IMPORTANT NOTE: Only the supplied approved Media is to be used with these ireplaces. Use of any other type of media can alter the unit's performance, any damage caused by the use of any unapproved media will not be covered under warranty. -
Page 22: Hri3E Optional Log Set Installation
installation HRI3E OPTIONAL LOG SET INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. - Page 23 installation 7. Place the supplied embers on the glass crystals as shown. Note: do not cover burner ports with embers. This will cause soothing on the logs. Ember install 8. Test fi re to ensure proper light off (make sure fl ame fl ows smoothly from one end of the burner to the other).
-
Page 24: Lri3E Log Set Installation
installation LRI3E LOG SET INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. *For Touch Ups: Dark Brown paint is included. - Page 25 installation 6. Install Log 6 in the indent of the burner as shown below. Log 6 install 7. Install Log 7 on a diagonal, one end will rest in an indent in the burner and the other end will rest at the "Y" on Log 3. Log 7 install 8.
-
Page 26: Brick Panel Installation
installation BRICK PANEL INSTALLATION Important: This appliance cannot be operated without brick (LRI3E) or enamel panels (HRI3E/LRI3E) installed. Brick panels are soft and fragile. Use caution when handling the panels, being careful not to jar them or scratch the painted surfaces. 1. Carefully unpack brick panels. 4. Loosen bracket screw in irebox in location shown below, slide right brick panel into position until it contacts the back panel. -
Page 27: Painted Black And Enamel Panel Installation
installation PAINTED BLACK AND ENAMEL PANEL INSTALLATION Important: This appliance cannot be operated without brick (LRI3E) or enamel panels (HRI3E/LRI3E) installed. tooltip 4. Loosen bracket screw in irebox in location shown below, slide right panel Before you Start: into position until it contacts the back panel. Slide the panel bracket on from the back of the unit and tighten the bracket screw. Black Enamel Panels Only •... -
Page 28: Glass Door Removal / Installation
installation GLASS DOOR REMOVAL / INSTALLATION 4. Release the side door latch until it reaches its resting point. WARNING: Do not operate the appliance with the glass panels removed, cracked or broken. Replacement of the 5. Support the top of door as it will fall forward after the 2nd door latch is re- glass panels should be done by a licensed or qualiied leased. The bottom of the door will be supported in the lower frame. service person. -
Page 29: Vignette Faceplate With Safety Screen Installation
installation VIGNETTE FACEPLATE WITH SAFETY SCREEN INSTALLATION VIGNETTE FACEPLATE INSTALLATION 1. Install the back faceplate and secure with 4 screws as shown. Final Install Back Faceplate Install 2. Install the outer (front) faceplate by hooking the flange over the hanger located on the back faceplate (installed in the previous step) as shown. -
Page 30: Inlay Installation
installation INLAY INSTALLATION OPTIONAL VIGNETTE INLAY INSTALLATION 1. Remove 5 screws from the backside of the Vignette frame cover 3. Place the Inlay on the Front Trim Assembly. and keep them aside (3 at bottom and 2 at top). Vignette Frame Vignette Frame Cover 2. - Page 31 installation 5. With the Inlay in position, place the mesh screen over the inlay. 6. Reverse step1. NOTE: The fl ush side of the mesh screen should face the inlay. 7. Install the Vignette frame with Inlay onto the 2 hooks provided on the unit.
-
Page 32: Backing Plate Installation
installation BACKING PLATE INSTALLATION 1. Remove Vignette (front) faceplate from unit and lay on a soft \ 3. Attach the backing plate to the back faceplate from the front with 6 surface. screws (4 along the top and 1 on each side). Backing Plate Install 4. -
Page 33: Optional Hearth Trim Installation
installation OPTIONAL HEARTH TRIM INSTALLATION OPTIONAL MANTEL DEFLECTOR INSTALLATION Customizing the Hearth Trim A mantel delector may be installed to reduce the minimum mantel height. Refer to the instruction manual for minimum mantel clearances. The Hearth Trim can be adjusted to custom it an installation by pulling apart the top piece from the bottom piece. -
Page 34: Operating Instructions Operating Instructions
operating instructions OPERATING FIRST FIRE INSTRUCTIONS The irst ire in your stove is part of the paint curing process. To ensure that the paint is properly cured, Before operating this appliance, proceed through it is recommended that you burn your ireplace for the following check list. -
Page 35: Lighting Procedure
operating instructions LIGHTING PROCEDURE 1. Place ON/OFF switch located on appliance in (I) ON position 2. Simultaneously press the off and large lame buttons on the remote hand held until a short beep conirms the start sequence has begun. Release both buttons. 3. -
Page 36: Normal Operating Sounds Of Gas Appliances
Une installation, un ajustement, une modiication, un service ou un entretien inadéquat peut Blower: provoquer des blessures ou des dommages matériels. Reportez-vous au manuel du proprié- Regency gas appliances use high tech blowers taire de l'information fournie avec cet appareil. Pour obtenir de l'aide ou des informations sup- plémentaires consulter un installateur qualiié, une agence de service ou fournisseur de gaz. to push heated air farther into the room. It is not A) This appliance is equipped with an ignition device which automatically lights the pilot. -
Page 37: Maintenance
GUARD REMOVED FOR SERVICING AN instructions for replacement. and should only be reinished with heat resis- APPLIANCE MUST BE REPLACED PRIOR tant paint (not with wall paint). Regency uses Warning: Do not operate appliance TO OPERATING THE APPLIANCE. StoveBrite Paint - Metallic Black #6309. with glass panels removed, cracked 3) Make a periodic check of burner for proper posi- or broken. Replacement of the glass... -
Page 38: Pilot Adjustment
3) Check for evidences of excessive condensation, such as water droplets forming in the inner liner, and subsequently dripping out the joints, Note: If you have an incorrect lame pattern, Continuous condensation can cause corrosion contact your Regency dealer for further ® of caps, pipe, and ittings. It may be caused instructions. -
Page 39: Fan Replacement - With Remote Control
maintenance FAN REPLACEMENT - WITH REMOTE CONTROL Note: To access the side and rear access panels both the gas and vent- 3. Remove fan from unit by lifting up off pins. ing will need to be disconnected (see vent/lue installation in this manual) for proper removal. -
Page 40: Valve Replacement
maintenance VALVE REPLACEMENT Before you begin: 6. Remove the burner. LRI3E- Remove the burner by removing 2 screws in locations shown below. * Shut off the gas supply to the unit. Disconnect all electrical supply to the unit. Always let the appliance cool to room temperature before servic- ing. - Page 41 maintenance 8. Remove the back delector by removing 4 top screws and loosening 2 bottom screws. 11. Replace with new valve assembly, ensuring to use a new gasket before securing new valve access plate to unit. 12. Reassemble unit by reversing Steps 8-1. 13.
-
Page 42: Lri3E Parts List
parts list LRI3E PARTS LIST Part # Description Part # Description Shown 716-574/P Valve Assembly - NG 904-529 Allen Key 5/32 Long 716-576/P Valve Assembly - LP 905-003 Minimum Rate Screw 0.95mm LP 911-194 Maxitrol Gas Valve Only - NG 911-198 Thermocouple Interrupter 911-217... -
Page 43: Lri3E Main Assembly
parts list LRI3E MAIN ASSEMBLY LRI3E / HRI3E Direct Vent Gas Insert... -
Page 44: Hri3E Parts List
maintenance HRI3E PARTS LIST Part # Part Description Part # Part Description Shown 716-578/P Valve Assembly - NG 904-529 Allen Key 5/32 Long 716-580/P Valve Assembly - LP 905-003 Minimum Rate Screw 0.95mm LP 911-194 Maxitrol Gas Valve Only - NG 911-198 Thermocouple Interrupter 911-217... -
Page 45: Hri3E Main Assembly
maintenance HRI3E MAIN ASSEMBLY LRI3E / HRI3E Direct Vent Gas Insert... -
Page 46: Accessories
parts list ACCESSORIES Part # Part Description 716-920 Mantel Delector 716-919 Hearth Trim Adjustable 716-921 Faceplate Vignette Tuscan Sunset 716-922 Faceplate Vignette Black Chrome 716-923 Faceplate Vignette Metallic Black 716-924 Faceplate Vignette Platinum 716-928 Backing Plate 4-Sided Vignette 716-925 Backing Plate Vignette Small 716-926 Backing Plate Vignette Regular 716-927... - Page 47 notes LRI3E / HRI3E Direct Vent Gas Insert...
-
Page 48: Warranty Warranty
warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below. - Page 49 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: December 2016 Regency Gas Products Warranty LRI3E / HRI3E Direct Vent Gas Insert...
