L540EB / HZI540EB Gas Insert
MODELS: L540EB-NG Natural Gas
HZI540EB-NG Natural Gas
WarninG:
improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. refer to
this manual. for assistance or additional information consult
an authorized installer, service agency or the gas supplier.
for Your safetY
do not store or use gasoline or other flammable vapours and
liquids in the vicinity of this or any other appliance.
installation and service must be performed by an authorized
installer, service agency or the gas supplier.
Tested by:
919-004b
L540EB-LP Propane
HZI540EB-LP Propane
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
fpi fireplace products international ltd. 6988 Venture st., delta, Bc canada, V4G 1H4
owners &
installation Manual
www.regency-fire.com
for Your safetY
What to do if you smell gas:
do not try to light any appliance
do not touch any electrical switch:
do not use any phone in your
building.
immediately call your gas supplier
from a neighbour's phone. follow
the gas supplier's instructions.
if you cannot reach your gas
supplier, call the fire department.
10/17/11
Advertisement
Table of Contents
Related Manuals for Regency L540EB
Summary of Contents for Regency L540EB
- Page 1 & L540EB / HZI540EB Gas Insert installation Manual www.regency-fire.com MODELS: L540EB-NG Natural Gas L540EB-LP Propane HZI540EB-NG Natural Gas HZI540EB-LP Propane WarninG: for Your safetY improper installation, adjustment, alteration, service or What to do if you smell gas: maintenance can cause injury or property damage. refer to do not try to light any appliance this manual.
- Page 2 Congratulations! You are the owner of a state-of-the-art Gas Insert by Regency. The Regency Gas Insert Series of hand crafted appliances has been designed to provide you with all the warmth and charm of a fireplace, at the flick of a switch. The models L540E / HZI540E of this series have been approved by Warnock Hersey for both safety and efficiency.
-
Page 3: Unit Dimensions
2 " 1155.45 8 " 1011.43 8 " 798.02 8 " 8 " 715.47 257.80 2 " 1155.70 45-1/2" 1155.45 2 " 495.30 4 " 349.25 Dimensions w/4 sided Faceplate Dimensions w/Full Screen Doors L540EB / HZI540EB Direct Vent Gas Insert... -
Page 4: Table Of Contents
Brick panel installation ..........28 Enamel panel installation..........29 Glass door removal / installation .........30 3 sided low profile faceplate installation ......31 4 sided low profile faceplate installation ......32 Optional screen installation .........33 Optional full screen door installation......34 L540EB / HZI540EB Direct Vent Gas Insert... -
Page 5: Copy Of The Safety Label
This is a copy of the labels that accompany each L540EB Gas Insert. We NOTE: regency units are constantly being improved. check the have printed a copy of the contents here for your review. label on the unit and if there is a difference, the label on the unit is the correct one. - Page 6 This is a copy of the labels that accompany each HZI540EB Gas Insert. NOTE: regency units are constantly being improved. check the We have printed a copy of the contents here for your review. label on the unit and if there is a difference, the label on the unit is the correct one.
-
Page 7: Requirements
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 8: Installation
INSTRuCTIONS ance. toddlers, YounG cHildren and otHers MaY Be susceptiBle The L540EB / HZI540EB Gas Inserts must be to accidental contact Burns. a installed in accordance with these instructions. pHYsical Barriers is recoMMend-... -
Page 9: Important Message
Ceramic fibre, 7 per set - L540EB placed on or near the appliance. BEFORE YOu START Glass crystals: 8 lbs of glass crystals -... -
Page 10: Installation Checklist
The minimum fireplace clearances & dimensions a) Clocking the appliance to ensure the correct plate is open and secure to prevent the damper plate for the Regency gas insert are shown in the firing rate. from falling down and crushing the liner. -
Page 11: Minimum Clearances To Combustibles
Do installed at a lower height if the framing not use the hearth as a seat or shelf. is made of metal studs covered with a noncombustible board. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 12: Gas Connection
Periodically check that the vent is unrestricted. Masonry chimneys may take various contours which the flexible liner will accommodate. However, keep the flexible liner as straight as possible, avoid unnecessary bending. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 13: Flue / Vent Installation
Flue Connector Plate Gasket WarninG: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 14: Leveling Leg Adjustment
LEVELING LEG AdjuSTmENT The L540EB / HZI540EB inserts are equipped with 4 levelling legs that are accessible while the appliance is in its final installation position. The unit can be adjusted up to 5/8" (16mm). The faceplate must not be installed to do this adjustment, if installed, remove faceplate. -
Page 15: Air Shutter Adjustment
Push to close - Pull to open Note: Aeration Adjustment should only be performed by an authorized Regency Installer at the time of installation or service. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 16: High Elevation
6) When finished reading manometer, turn off the gas valve, disconnect the hose and tighten the screw (clockwise) with a 1/8" flat screwdriver. Note: Screw should be snug, but do not over tighten. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 17: Conversion From Ng To Lp
CONVERSION FROm NG TO LP CONVERSION FROM NG TO LP L540EB/HZI540EB using SIT 885 NOVA Gas Valve L540E/HZI540E using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! WARNING This conversion kit shall be installed by a qualifi... - Page 18 Verify both the correct fl ame and pilot appearance. 13) See Gas Pipe Pressure Testing in this manual. 14) Adjust aerations settings - see Air Shutter Adjustment section in the manual. L540EB / HZI540EB Direct Vent Gas Insert 919-061a 07/20/11...
-
Page 19: Proflame Remote System Gtmf With Fan
PROFLAmE REmOTE SYSTEm GTmF WITH FAN (L540EB / HZI540EB) WIRING dIAGRAm Proflame System Configuration 886 GTMF Wire Diagram SureFire™ Switch 0.584.907 Thermostat See optional wall thermostat installation in this manual. (Optional) Ground Black Neutral Green Live Fan Thermodisc Ground... -
Page 20: Optional Wall Thermostat Installation
3) Connect one thermostat lead to female connector, using male spade con- nector - see pic below. When complete turn remote receiver to the ON position. Unit will now operate using the wall thermostat. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 21: Glass Crystal / Ceramic Spa Stone Installation
For units P33S, P33SE, L676S, U32S, U32SE, E33S only For units P33S,P33SE L676S, U32S, U32SE, E33S only Glass Crystals shown on Burner and Firebox Floor For Units HZI390E, HZI390EB, HZI540EB only 918-753k 10/11/11 L540EB / HZI540EB Direct Vent Gas Insert... -
Page 22: Spa Stone Caution
HZI540EB ADDENDUM installation CAUTION DO NOT place spa stones or volcanic stones over pilot and burner ports. No spa stones in this area. No volcanic stones in this area. 09/28/11 L540EB / HZI540EB Direct Vent Gas Insert... -
Page 23: Optional Pebbles / Glass Crystal Installation
Natural River Pebbles shown surrounding the a Horizon Burner River Pebbles shown surrounding a Sunrise Burner Glass Crystals shown surrounding the Burner L540EB / HZI540EB Direct Vent Gas Insert... -
Page 24: L540Eb Log Set Installation
4) Log 2 should lean against Log 1 - as shown below. 2) Place Log 1 so it is positioned perpendicular to the fl oor - see below. Log 1 in position Log 2 in position L540EB / HZI540EB Direct Vent Gas Insert 09/08/11 919-064a... -
Page 25: Log Installation
7) Ensure the contour of Log 4 matches up the burner contour and 9) Locate provisions in the bottom of Log 6 (see highlighted areas) and does not rock when seated. place provisions on Log 1 and Log 5 (see darkened areas). 919-064a 09/08/11 L540EB / HZI540EB Direct Vent Gas Insert... - Page 26 11) Locate provision on the bottom of Log 7 (see highlighted areas), place on provision on Log 1 and in provisions on Log 2 and Log 4 (see darkened areas). Final Install Log 7 provision position on Log 4 09/08/11 919-064a L540EB / HZI540EB Direct Vent Gas Insert...
-
Page 27: Standing Pilot And Heat Exchange Return
STANdING PILOT ANd HEAT ExCHANGE RETuRN The L540EB / HZI540EB use a heat exchanger and efficient combustion INSTALLING THE HEAT ExCHANGER RETuRN technology to provide extreme heating efficiencies. The more efficient an ap- pliance becomes, the lower the flue gas temperatures becomes. -
Page 28: Brick Panel Installation
Lower Right of Firebox off the burner bracket. (L540EB only) Lift the Burner slightly while pulling forward to clear the mixing tube (no screws to remove for the L540EB). 7) Once one Firebox Liner Side is installed, you can release the Firebox Liner Rear. -
Page 29: Enamel Panel Installation
Side, sits between the rear liner and the fi rebox side. When the side liner is properly installed, the front edge should sit just inside the front edge of the fi rebox. L540EB / HZI540EB Direct Vent Gas Insert 08/22/11 919-025... -
Page 30: Glass Door Removal / Installation
6) Pull the bottom of the door towards you until the door is angled away from the firebox by about 30°. Lift the door up and over the upper door hooks. 7) To install the glass door - reverse steps. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 31: Sided Low Profile Faceplate Installation
Note: Faceplate may be installed after the unit is in it's fi nal position. 3) Install Low Profi le faceplate backing plate and secure to the unit with 5 Trim screws in locations shown below. Final Install L540EB / HZI540EB Direct Vent Gas Insert 919-078a 09/27/11... -
Page 32: Sided Low Profile Faceplate Installation
Note: Faceplate may be installed after the unit is in it's fi nal position. Trim 3) Install Low Profi le faceplate backing plate and secure to the unit with 4 screws in locations shown below. Final Install L540EB / HZI540EB Direct Vent Gas Insert 09/26/11 919-023a... -
Page 33: Optional Screen Installation
Locations shown in the diagrams below. Tabs 2) Secure the screen by placing provided magnets between the back of the screen and the unit in locations shown below. 3) To remove - reverse steps. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 34: Optional Full Screen Door Installation
. The tabs should be fl ush with the underside of the top lip of the back plate. top of backing plate 1) Install the optional full screen to the unit by securing with 4 screws in Bracket Clip locations shown below. Final Install L540EB / HZI540EB Direct Vent Gas Insert 919-077a 09/26/11... -
Page 35: Operating Instructions
The fan will turn on as the stove comes up to operating temperature. After the unit has been to turn off the pilot. turned off and the unit cooled to below a useful heat output range the fan will shut off automatically. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 36: Normal Operating Sounds Of Gas Appliances
Appuyez sur le bouton ON / OFF Si le service est effectuée, vous devez débrancher l'appareil, du bloc-piles, voir le manuel d'instruction pour plus de détails. DO NOT REMOVE THIS INSTRUCTION PLATE 918-628c L540EB / HZI540EB Direct Vent Gas Insert... -
Page 37: Maintenance Instructions
1 flow- ing around the thermopile and 1 around the thermocouple, and 1 flowing across the rear of the burner (it does not have to be touching the burner). Window Glass Door Components L540EB / HZI540EB Direct Vent Gas Insert... -
Page 38: Pilot Adjustment
NOTE: Improper positioning of logs may create carbon build-up and will alter the unit’s performance which is not covered under warranty. GLASS GASkET If the glass gasket requires replacement use glass gasket for the Flush Front (Part # 936-159). L540EB / HZI540EB Direct Vent Gas Insert... -
Page 39: Glass Crystal Burner Removal / Installation
Screw locations Screw locations 3) Remove the rear burner screen and lift out the burner surround. 4) Remove 2 screws that fasten down the burner to the firebox floor. Screw locations Screw locations L540EB / HZI540EB Direct Vent Gas Insert... -
Page 40: L540Eb Ceramic Burner Removal / Installation
Left and Right. There will be a small gap between the Ceramic Burner and the firebox Bottom Flange. The Burner should be situated about ¼” (6mm) inside the front edge of the firebox. 3) To install - reverse Steps 2 and 1. L540EB / HZI540EB Direct Vent Gas Insert... -
Page 41: Fan Maintenance - With Gtmf Remote Control
Do not cut or remove the grounding prong from this plug. Strain Relief Power Cord Fan Controller Wire Retainer Fan Wire Harness Fan Terminals Ground Wire Fan Mounting Bracket Diagram 2 L540EB / HZI540EB Direct Vent Gas Insert... -
Page 42: Valve Replacement
3) Disconnect the Pressure Regulator cable. 7) Remove both Screws that secure the Gas Valve Mounting brackets, both sides. Pressure regulator cable 4) Disconnect the Gas Orifice supply line from the outlet of the Gas Valve. L540EB / HZI540EB Direct Vent Gas Insert... - Page 43 15) Reconnect the gas and electrical supply to the unit. Once the unit has be re-fired, use a soapy water mixture to check all fittings and gas sup- ply lines for gas leaks. L540EB / HZI540EB Direct Vent Gas Insert...
-
Page 44: Parts List
911-071/P Fan Motor Only 904-691 Clip 910-142 Fan Thermodisc 396-030F Bulk head clamp 911-030 Fan Control Module 396-029 Gasket Bulk Hd (Side Firebox Pilot Line) 910-572 Receiver GTM SIT W/ Batt &Cover 0.584.521 L540EB / HZI540EB Direct Vent Gas Insert... - Page 45 L540EB / HZI540EB Direct Vent Gas Insert...
-
Page 46: Low Profile Faceplate
3 Sided Faceplate Low Profile Sunset Bronze 296-102 3 Sided Faceplate Low Profile Black 296-130 3 Sided Faceplate Low Profile Iron Gray 296-129 3 Sided Faceplate Low Profile Custom 296-127 Faceplate 4-Sided Low Profile Custom 296-940 Full Screen Door L540EB / HZI540EB Direct Vent Gas Insert... -
Page 47: Warranty
It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufacturer defect. The authorized selling dealer is responsible for all in-fi eld service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers. - Page 48 Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency and Regency Horizon, are trademarks of FPI Fireplace Products International Ltd. ® Printed in Canada © Copyright 2011, FPI Fireplace Products International Ltd. All rights reserved.
