FAQ

1. No image output, no display on LCD .
Check if the power is properly connected, and check if the power switch is set
to on.
2. LCD is showing, but no image output.
Check if the input signal is connected properly, and has switched to the
corresponding signal source, if the current source does not have signal, LED
video processor will not have the image output; to confirm if it supports
output resolution and refresh rate, check if brightness and contrast settings
are too low. Those parameters can be restored to the factory defaults value by
the 'Fac Reset' in the sub-menu of 'Function'.
3. Image display position is on left or right side
Enter the sub-menu of 'Adjust'; adjust the 'H Pos' and 'V Pos' option, until the
images display correctly.
4. VGA or DVI input, the image shows abnormal
For the VGA or DVI input, this device supports VESA standard input resolution.
Please switch VGA or DVI output resolution to the VESA standard resolution.
5. VGA image cannot be displayed in full screen
Press 'Auto' button, until the image displayed correctly.
6. Open PIP, the display is abnormal
Within the system default settings for the PIP resolution is 64X48, for some
input signal, requires a larger PIP resolution , so you can adjust the PIP
sub-menu 'H window' and 'V window 'until the signal is correct.
