Resistance Measurements
CAUTION: Disconnect power to the circuit or device under test when making resistance
measurements
1.
Connect the black test lead into the COM terminal.
2.
Connect the red test lead into the '
3.
Power the meter using the power button
4.
Put the function switch to the '
5.
The display will show the 'AUTO' icon (Auto Range mode).
6.
Press the M (Mode) button to select resistance
7.
Press the test leads across the circuit under test and read the resistance on the display.
8.
In the Auto Range mode, the meter will automatically select the optimal range.
Ω
' terminal.
.
Ω
' position.
Ω
mode.
9
MA3110-en-GB_V1.0 12/16
