VarTech Systems VTPC190VR User Manual

19.0” enclosed vesa mount pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Solutions for
Demanding Applications
V
T
AR
ECH
S Y S T E M S I N C.
19.0" Enclosed VESA Mount PC
Model VTPC190VR – VTPC190VSR
User's Guide
19.0" Enclosed VESA Mount PC User's Guide
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTPC190VR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VarTech Systems VTPC190VR

Summary of Contents for VarTech Systems VTPC190VR

  • Page 1 Solutions for Demanding Applications S Y S T E M S I N C. 19.0” Enclosed VESA Mount PC Model VTPC190VR – VTPC190VSR User’s Guide 19.0” Enclosed VESA Mount PC User’s Guide Page 1...
  • Page 2 Read these instructions completely before attempting to operate your new VESA Mount PC Revision History Date Rev No Summary Page 01/07/09 First Issue 07/10/09 Revised Product Drawing, Detail A 08/05/09 Added VDC & VSDC versions 5 & 6 02/23/2017 Update LCD Panel Specs 02/23/2017 Update Computers Specs 4 - 5...
  • Page 3 Safety Instructions  Read the Safety Instructions carefully and keep it for use later.  The chassis metalwork of the module must be installed properly to the main earthing termination for Class 1 equipment.  Care must be exercised in the application of the system to prevent overheating.
  • Page 4 Do not clean the panel with a Ketone type material (e.g. Acetone), or Ethyl alcohol, Toluene, Ethyl acid, Methyl chloride. These may permanently damage the polarizer due to chemical reaction. Do not apply pressure to the LCD panel. Standard Technical Specifications: LCD Monitor: 19.0”...
  • Page 5 Resistive Touch Screen Serial Touch Screen Interface Quad Core Computer System: Intel® Celeron® processor J1900 quad core Processor 2GB DDR3L-1333 SO-DIMM max. up to 8 GB System Memory AMI BIOS BIOS 500 GB SATA Fast Access Disk Drive Hard Drive Microsoft Windows 7 Professional Operating System 1 x Power On/Off...
  • Page 6 ATTENTION: Mounting hardware must be tightened to a torque of 15 inch-pounds to provide a proper panel mount and avoid potential damage. Vartech Systems assumes no responsibility for water or chemical damage to the monitor or other equipment within the enclosure due to improper installation.
  • Page 7 Product Drawing: Detail –A– 19.0” Enclosed VESA Mount PC User’s Guide Page 7...
  • Page 8 Power Connection (Power In) The Enclosed VESA Mount PC includes an AC line cord which is 10ft long. The power input receptacle is located on the bottom rear panel of the system. Serial Connections (COM 1-2) The Enclosed VESA PC is supplied with a serial connector configured for RS-232.
  • Page 9 LCD Monitor Warm-up Time All LCD monitors need time to become thermally stable the first time you turn them on. Therefore, to achieve more accurate adjustments for parameters, allow the LCD monitor to warm (be on) for at least 20 minutes before making any screen adjustments.

  • Page 10: Ami Bios Setup Utility

    AMI BIOS Setup Utility The AMI UEFI BIOS provides users with a built-in setup program to modify basic system configuration. All configured parameters are stored in a flash chip to save the setup information whenever the power is turned off. This chapter provides users with detailed description about how to set up basic system configuration through the AMI BIOS setup utility.
  • Page 11 Hot Keys Description  Left/Right The Left and Right <Arrow> keys allow you to select a setup screen. The Up and Down <Arrow> keys allow you to select a setup screen or sub  Up/Down screen. The <Enter> key allows you to display or change the setup option listed for a particular setup item.

  • Page 12: Main Menu

    Main Menu When you first enter the setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below. The Main BIOS setup screen is shown below. BIOS Information Display the BIOS information.

  • Page 13: Advanced Menu

    Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ► ACPI Settings ►...
  • Page 14  ACPI Settings You can use this screen to select options for the ACPI configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen. Enable ACPI Auto Configuration Enable or disable BIOS ACPI auto configuration.
  • Page 15  Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen. For items marked with “”, please press <Enter> for more options. COM1~6 Use these items to set parameters related to serial port 1~6.
  • Page 16  COM1 Serial Port Enable or disable serial port 1. The optimal setting for base I/O address is 3F8h and for interrupt request address is IRQ4. Change Settings Select an optimal setting for serial port. 19.0” Enclosed VESA Mount PC User’s Guide Page 16...
  • Page 17  Hardware Monitor This screen monitors hardware health status. This screen displays the temperature of system and CPU, cooling fans speed in RPM and system voltages (VCC_CPU, VCC_DDR, +12V, +5V, +3.3V and VBAT). 19.0” Enclosed VESA Mount PC User’s Guide Page 17...
  • Page 18  Smart Fan Function This screen allows you to select the fan mode. CPU_FAN1 Mode This item allows you to select the fan mode, which can be set to Full on Mode, Manual Mode, Auto PWM Mode or Auto RPM Mode. 19.0”...
  • Page 19  Display Configuration Primary IGFX Boot Display Select the video device which will be activated during POST (Power-On Self Test). The default is LVDS. Backlight Control Select panel backlight control mode. LVDS Panel Type Select LVDS panel resolution; see the selection options in image above. Brightness Select the brightness of LVDS panel ranging from 30% to 100%.

  • Page 20: Soft-Off By Pwr-Bttn

     Power Button Control Restore AC Power Loss This item decides the state of system when AC power is resupplied after a power failure. Mode options are Power Off, Power On and Last State. Soft-Off by PWR-BTTN - Instant-Off: The system will shut down instantly when the power button is pressed. - Delay 4 sec: The system will shut down only when the power button is pressed and held at least 4 seconds.
  • Page 21  S5 RTC Wake Settings Wake system from S5 Enable or disable system wake on alarm event. It allows you to wake up the system in a certain time. Select Fixed Time to set the system to wake on the specified time. Use <> <>...
  • Page 22  CPU Configuration This screen shows the CPU Configuration, and you can change the value of the selected option. Socket 0 CPU Information This item is for CPU information. Limit CPUID Maximum This item allows user to limit the maximum value of CPUID. In Windows XP environment, this item should be disabled.
  • Page 23  IDE Configuration In the IDE Configuration menu, you can see the currently installed hardware in the SATA ports. During system boot up, the BIOS automatically detects the presence of SATA devices. Serial-ATA (SATA) Enable or disable the SATA controller feature. SATA Speed Support Select SATA speed support.
  • Page 24  OS Configuration OS Selection This item allows user to select the proper Operating System. 19.0” Enclosed VESA Mount PC User’s Guide Page 24...
  • Page 25  CSM Configuration CSM Support Enable or disable CSM (Compatibility Support Module) support. Boot option filter Select UEFI or Legacy ROM priority. Default is UEFI and Legacy mode. PXE BootRom Enable or disable the Preboot eXecution Environment (PXE) boot ROM function of the onboard LAN chip during system boots up.
  • Page 26  USB Configuration USB Devices Display all detected USB devices. Legacy USB Support Use this item to enable or disable legacy support for USB devices. The default setting is Enabled. Auto option disables legacy support if no USB devices are connected. Disable option will keep USB devices available only for EFI applications.

  • Page 27: Chipset Menu

    Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: ► North Bridge ► South Bridge For items marked with “”, please press <Enter> for more options. 19.0”...
  • Page 28  North Bridge This screen shows system memory information.  South Bridge This screen allows users to configure parameters of South Bridge chipset. Audio Controller Control detection of the audio device. - Disabled: Audio device will be unconditionally disabled. - Enabled: Audio device will be unconditionally enabled. - Auto: If device is present, audio controller will be enabled, otherwise will be disabled.

  • Page 29: Security Menu

    Security Menu The Security menu allows users to change the security settings for the system.  Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled).  User Password This item indicates whether a user password has been set (installed or uninstalled). 19.0”...

  • Page 30: Boot Menu

    Boot Menu The Boot menu allows users to change boot options of the system.  Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.  Bootup NumLock State Use this item to select the power-on state for the keyboard NumLock. ...

  • Page 31: Save & Exit Menu

    Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values.  Save Changes and Reset When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect.
  • Page 32 For Additional Assistance Contact Your VarTech Sales Representative Vartech Systems, Inc. 11422 Industriplex Blvd. Baton Rouge, LA 70809 800-223-8050 Fax: 225-297-2440 www.vartechsystems.com 19.0” Enclosed VESA Mount PC User’s Guide Page 32...
