Solutions for Demanding Applications
VARTECH
S Y S T E M S I N C.
19.0" Panel Mount PC
Model VTPC190P / PSS
User's Guide
Read these instructions completely before attempting to operate your new Panel Mount PC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTPC190P and is the answer not in the manual?

Questions and answers

Related Manuals for VarTech Systems VTPC190P

Summary of Contents for VarTech Systems VTPC190P

  • Page 1 Solutions for Demanding Applications VARTECH S Y S T E M S I N C. 19.0” Panel Mount PC Model VTPC190P / PSS User’s Guide Read these instructions completely before attempting to operate your new Panel Mount PC...
  • Page 2 Revision History Date Rev No Summary Page 8/11/08 First Issue 10/13/08 Revised panel mounting drawing 7/10/09 Revised Detail A, connector view & system spec. 4, 6 & 7 19.0 Panel Mount PC 486-0010-01-02...
  • Page 3 Safety Instructions x Read the Safety Instructions carefully and keep it for use later. x The chassis metalwork of the module must be installed properly to the main earthing termination for Class 1 equipment. x Care must be exercised in the application of the system to prevent overheating. Ensure that the ambient temperature around the system does not exceed 60°C and provide adequate means of ventilation to achieve this.
  • Page 4 Standard Technical Specifications: Standard Monitor: Size / Type 19.0” SXGA TFT LCD Native Resolution 1280 x 1024 Contrast Ratio 800:1 Viewing Angles Horizontal: 178° Vertical: 178° Pixel Pitch 0.294mm Brightness (typical) 250 cd/m² Response Time (typical) Colors Supported 16.7 million Computer System: Processor 2.15GHz Intel T3400 Pentium Dual Core Processor...
  • Page 5 5 to 65°C, 28% RH NC Installation of Your Panel PC Packaged with each carton will be: 1 - VTPC190P / PSS 1 - AC Power Cable 1 - #10-32 Mounting Hardware 1 - Users Guide (Printed or on CD)
  • Page 6 ATTENTION: Mounting nuts must be tightened to a torque of 24 inch-pounds to provide a proper panel seal and avoid potential damage. Vartech Systems assumes no responsibility for water or chemical damage to the monitor or other equipment within the enclosure due to improper installation.
  • Page 7 Connections to the Panel Mount PC Bottom Rear View - Connector Panel - Power Connection (Power In) The Panel Mount PC includes an AC line cord which is 6ft long. The power input receptacle is located on the bottom rear panel of the system. Serial Connections (COM 1-3) The Panel Mount PC is supplied with three serial connectors configured for RS-232.
  • Page 8 Panel Mount PC clear and free of excessive dirt or other contaminants. Do not use water or any liquids on the Panel Mount PC. For Additional Assistance Contact Your VarTech Sales Representative Vartech Systems, Inc. 11529 Sun Belt Ct.
