- Page 1 Solutions for Demanding Applications VARTECH S Y S T E M S I N C. 15.0” Panel Mount PC Model VTPC150P User’s Guide Read these instructions completely before attempting to operate your new Panel Mount PC...
- Page 2 15.0 Panel Mount PC 486-0002-00...
- Page 3 Safety Instructions • Read the Safety Instructions carefully and keep it for use later. • The chassis metalwork of the module must be installed properly to the main earthing termination for Class 1 equipment. • Care must be exercised in the application of the system to prevent overheating. Ensure that the ambient temperature around the system does not exceed 60°C and provide adequate means of ventilation to achieve this.
- Page 4 Standard Technical Specifications: LCD Monitor: Size / Type 15.0” XGA TFT LCD Native Resolution 1024 x 768 Contrast Ratio 600:1 Horizontal: 130° Viewing Angles Vertical: 100° Pixel Pitch 0.297mm Brightness (typical) 250 cd/m² Response Time (typical) 12ms Colors Supported 16.2 million Computer System: Processor 1.73 GHz Intel Pentium Dual-Core Mobile Processor T2080...
- Page 5 Storage: 5 to 95% RH NC Installation of Your Panel PC Packaged with each carton will be: 1 - VTPC150P 1 - AC Power Cable 1 - #10-32 Mounting Hardware 1 - Users Guide (Printed or on CD) BEFORE MAKING ANY CONNECTIONS OR APPLYING POWER, FIRST READ THROUGH THE ENTIRE MANUAL 15.0 Panel Mount PC...
- Page 6 ATTENTION: Mounting nuts must be tightened to a torque of 24 inch-pounds to provide a proper panel seal and avoid potential damage. Vartech Systems assumes no responsibility for water or chemical damage to the monitor or other equipment within the enclosure due to improper installation.
- Page 7 Connections to the Panel Mount PC Bottom Rear View - Connector Panel - Rear Panel Connections 15.0 Panel Mount PC 486-0002-00...
- Page 8 Power Connection (Power In) The Panel Mount PC includes an AC line cord which is 6ft long. The power input receptacle is located on the bottom rear panel of the system. Serial Connections (COM 1) The Panel Mount PC is supplied with a serial connector configured for RS-232. The connector is a 9 pin female connectors and can be set up for any baud rate from 300 to 19.2 baud.
- Page 9 LCD Monitor Warm-up Time All LCD monitors need time to become thermally stable the first time you turn them on. Therefore, to achieve more accurate adjustments for parameters, allow the LCD monitor to warm (be on) for at least 20 minutes before making any screen adjustments. Main Board Connectors and Pin Definitions 15.0 Panel Mount PC 486-0002-00...
- Page 10 Panel Mount PC clear and free of excessive dirt or other contaminants. Do not use water or any liquids on the Panel Mount PC. For Additional Assistance Contact Your VarTech Sales Representative Vartech Systems, Inc. 11529 Sun Belt Ct. Baton Rouge, LA 70809 800-223-8050 Fax: 225-297-2440 www.vartechsystems.com...
