- Page 1 Solutions for Demanding Applications VARTECH S Y S T E M S I N C. 10.4” Enclosed VESA Mount PC Model VT104V-VS User’s Guide Read these instructions completely before attempting to operate your new VESA Mount PC...
- Page 2 Revision History Date Rev No Summary Page 03/04/09 First Issue 10.4 Enclosed VESA Mount LCD Monitor 486-0020-00-00...
- Page 3 Safety Instructions Read the Safety Instructions carefully and keep it for use later. The chassis metalwork of the module must be installed properly to the main earthing termination for Class 1 equipment. Care must be exercised in the application of the system to prevent overheating. Ensure that the ambient temperature around the system does not exceed 50°C and provide adequate means of ventilation to achieve this.
- Page 4 Storage: 0 to 95% RH NC Installation of Your Enclosed VESA Mount PC Packaged with each carton will be: 1 - VT104V-VS 1 - AC Power Cable 1 – VGA Cable 1 – SERIAL Cable 1 - #8-32 Mounting Hardware 1 - Users Guide (Printed or on CD) 10.4 Enclosed VESA Mount LCD Monitor...
- Page 5 ATTENTION: Mounting hardware must be tightened to a torque of 15 inch-pounds to provide a proper panel mount and avoid potential damage. Vartech Systems assumes no responsibility for water or chemical damage to the monitor or other equipment within the enclosure due to improper installation.
- Page 6 Connections to the Enclosed LCD Monitor Bottom Rear View - Connector Panel - Power Connection (Power In) The Enclosed VESA Mount PC includes an AC line cord which is 6ft long. The power input receptacle is located on the bottom rear panel of the monitor. Serial Connection (Touch Screen) The Enclosed VESA LCD monitor is supplied with a 9-Pin serial cable to connect the monitor to an available serial connector on your PC.
- Page 7 Keep the area around the Enclosed VESA Mount LCD Monitor clear and free of excessive dirt or other contaminants. For Additional Assistance Contact Your VarTech Sales Representative Vartech Systems, Inc. 11529 Sun Belt Ct. Baton Rouge, LA 70809 800-223-8050 Fax: 225-297-2440 www.vartechsystems.com...
