Summary of Contents for IKEA VALFRI

  • Page 1 VALFRI...
  • Page 2 ENGLISH Please refer to the chapter IKEA GUARANTEE for contact details of the after sales customer service centre.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Before first use Energy efficiency Daily use ENVIRONMENTAL CONCERNS Clock functions IKEA GUARANTEE Using the accessories Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages.

  • Page 5: General Safety

    ENGLISH Children shall not carry out cleaning and user maintenance of • the appliance without supervision. Children aged 3 years and under must be kept away from • this appliance when it is in operation at all times. General Safety Only a qualified person must install this appliance and •...

  • Page 6: Conditions Of Use

    ENGLISH Conditions of Use • By clients in serviced apartments, holiday This appliance is intended to be used in apartments and other residential type household and similar applications such as: environments. • Farm houses Safety instructions • Make sure not to cause damage to the Installation mains plug and to the mains cable.
  • Page 7 ENGLISH • Make sure that the ventilation openings • This appliance is for cooking purposes are not blocked. only. It must not be used for other • Do not let the appliance stay unattended purposes, for example room heating. during operation. •...

  • Page 8: Installation

    ENGLISH Plastic parts are marked with Disposal international abbreviations such as PE, Warning! Risk of injury or PS, etc. Dispose of the packaging suffocation. material in the containers provided for this purpose at your local waste • Disconnect the appliance from the mains management facility.

  • Page 9: Product Description

    ENGLISH Product description General overview Control panel Knob for the top oven functions Temperature indicator for the top oven Knob for the top oven temperature Electronic programmer Knob for the main oven functions Knob for the main oven temperature Temperature indicator for the main oven Air vents for the cooling fan Rating plate Socket for the core temperature sensor...

  • Page 10: Daily Use

    ENGLISH Using the Mechanical child lock Refer to "Care and cleaning" chapter. The appliance has the child lock installed and activated. It is below the control panel Clean the appliance and the accessories on the right side. before first use. Put the accessories and the removable shelf To open the oven door with the child lock supports back to their initial position.
  • Page 11 ENGLISH Top oven functions Symbol Oven function Application Off position The appliance is off. Light To activate the lamp without a cooking function. It can be used with residual heat in final cooking phase to save energy. Conventional (Top To bake and roast food on one shelf position. and Bottom Heat) Fast Grilling To grill flat food in large quantities and to toast...
  • Page 12 ENGLISH Symbol Oven function Application Defrost This function can be used for defrosting frozen foods, such as vegetables and fruits. The defrosting time depends on the amount and size of the frozen food. The knob for the temperature must be in the off po- sition.

  • Page 13: Clock Functions

    ENGLISH Clock functions Clock functions table Clock function Application TIME OF DAY To set, change or check the time of day. DURATION To set how long the appliance operates. To set when the appliance deactivates. TIME DELAY To combine DURATION and END function. MINUTE MIND- To set countdown time.

  • Page 14: Using The Accessories

    ENGLISH Setting the TIME DELAY Setting the MINUTE MINDER 1. Set an oven function and temperature. 1. Press again and again until starts 2. Press again and again until starts to flash. to flash. 2. Press to set the necessary time. 3.
  • Page 15 ENGLISH Small indentation at the top increase safety. The indentations are also anti-tip devices. The high rim around the shelf prevents cookware from slipping of the shelf. Using the core temperature sensor The core temperature sensor measures the core temperature of the meat. There are two temperatures to be set: Baking tray / Deep pan •...

  • Page 16: Additional Functions

    ENGLISH 7. Remove the plug of the core Warning! Be careful when you temperature sensor from the socket. remove the tip and plug of the Remove the meat from the appliance. core temperature sensor. The If the meat is not cooked to your core temperature sensor is hot.
  • Page 17 ENGLISH cooking time, etc.) for your cookware, Cooking times recipes and quantities when you use this Cooking times depend on the type of food, appliance. its consistency, and volume. Initially, monitor the performance when you cook. Find the best settings (heat setting, Top oven Quantity Food...

  • Page 18: Care And Cleaning

    ENGLISH Quantity Food Function Shelf posi- Temperature Time (min) (kg) tion (°C) Rabbit 170 - 190 50 - 70 Pizza 200 - 230 20 - 30 Care and cleaning Cleaning the door gasket Warning! Refer to Safety chapters. • Regularly do a check of the door gasket. The door gasket is around the frame of Notes on cleaning the oven cavity.
  • Page 19 ENGLISH Cleaning the oven door The oven door has two glass panels. You can remove the oven door and the internal glass panel to clean it. The oven door can close if you try to remove the internal glass panel before you remove the oven door.

  • Page 20: Troubleshooting

    ENGLISH resistant oven light bulb (connection 6. Install the glass cover. type: E14). Troubleshooting Warning! Refer to Safety chapters. What to do if... Problem Possible cause Remedy The oven does not heat up. The oven is deactivated. Activate the oven. The oven does not heat up.

  • Page 21: Technical Data

    ENGLISH We recommend that you write the data here: Model (MOD.) ......... Product number (PNC) ......... Serial number (S.N.) ......... Technical data Technical data Width top: 440 mm / main: 435 Height top: 212 mm / main: 368 Dimensions (internal) Depth top: 448 mm / main: 409 Area of baking tray...

  • Page 22: Energy Efficiency

    Frequency 50 Hz Number of functions Energy efficiency Product information according to EU 66/2014 Model identification VALFRI 502.847.08 Top oven: 106.8 Energy Efficiency Index Main oven: 106.2 Energy consumption with a standard load, conven- Top oven: 0.78 kWh/cycle tional mode Main oven: 0.94 kWh/cycle...

  • Page 23: Environmental Concerns

    IKEA Pty Ltd, ABN 84006270757 or at Cebas Pty Ltd, ABN 15 If you encounter any trouble with the 009 156 003 (Both Trading as IKEA) unless appliance and wish to register a service call the appliance is named LAGAN in which or make a claim, please refer to case two (2) years of guarantee apply.
  • Page 24 Contact - IKEA Customer Service at Australia. www.IKEA.com.au What will IKEA do to correct the problem? For Western Australian and South IKEA appointed service provider will exam- Australian customers please contact: ine the product and decide, at its sole dis- cretion, if it is covered under this guarantee.
  • Page 25 • Transportation damages. If a customer transports the product to their home or To make a claim under the guarantee other address, IKEA is not liable for any contact IKEA after sales customer service damage that may occur during transport.
  • Page 26 ENGLISH The IKEA after sales customer service centre will assist you on the phone with basic trouble shooting for your appliance at the time of service call request. Please refer to the IKEA catalogue or www.ikea.com.au and select your local store for local store phone numbers and opening times.
  • Page 27 ENGLISH...
  • Page 28 21552 © Inter IKEA Systems B.V. 2017 AA-992208-4...
