- Page 1 Instruction Manual Backup Camera System With Waterproof Monitor and Shutter Camera RVS-8106131N Reverse With Confidence ™...
-
Page 2: Table Of Contents
Camera Specifications ......15 Camera Dimensions......16 Rear View Safety... - Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
-
Page 4: Safety Information
Rear View Camera System. If you back up while looking only at the monitor, you may cause Rear View Safety... - Page 5 INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified.
- Page 6 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. Rear View Safety...
-
Page 7: Before Beginning Installation
Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot/moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly. - Page 8 Warning! 1. This monitor is high voltage. Only professionals should open the monitor's case. 2. Do not watch the video while driving unless you are monitoring the rear view camera display. Rear View Safety...
-
Page 9: Introduction
Monitor Introduction Monitor Dimensions (mm) Reverse With Confidence ™... - Page 10 Sunshade Installation U-Bracket Installation Rear View Safety...
-
Page 11: Wiring
Wiring 1. Camera 1 (white) 2. Camera cable 3. Camera 1 trigger wire (white) 4. Camera 2 trigger wire (blue) 5. Car power input: DC11-32V 6. Camera 2 (blue) 7. Camera cable (second camera/cable sold seperately) Reverse With Confidence ™... -
Page 12: Monitor Menu Operation
Menu Operation Press "Menu" and the monitor will display the following options: Bright/Contrast/Color/Delay Time/Language/Zoom/Mirror. Bright/Contrast/Color Press left/right to adjust brightness/color and contrast (1-100). Rear View Safety... - Page 13 Delay Time Press left/right to adjust trigger delay (1-30sec). This option can be set for two cameras (2nd camera sold seperately). Language Reverse With Confidence ™...
- Page 14 Zoom (Display Mode) Once in the Zoom option, press left/right to toggle display mode. Monitor Specifications Rear View Safety...
-
Page 15: Camera Specifications
Camera Specifications Camera 1/3" Sharp® CCD TV System PAL/NTSC Effective Pixels 512 x 582 pixels / 512 x 492 pixels Sensing Area 4.9 mm (H) x 3.7 mm (V) Viewing Angle 120° Scanning System 2:1 Interlace Sync. System Internal Resolution 600 TV Lines Horizontal Sync. -
Page 16: Camera Dimensions
Camera Dimensions • Motorized shutter: Automatically moves to protect lens • IP69K Rating: Completely waterproof • 120° Viewing Angle: Ultra wide, all encompassing view • Built-in high gain microphone Rear View Safety...
