Summary of Contents for Rear view safety RVS-25W
- Page 1 Instruction Manual Wireless Backup Camera System 5" Dual Screen Display RVS-25W Please read this manual before using the product. The product may be different from how it is described in the manual depending on what software version you are using.
-
Page 2: Table Of Contents
Warranty....... . 17 Disclaimer....... 18 Rear View Safety... -
Page 3: Introduction
NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle. -
Page 4: Safety Information
Rear View Camera System. If you back up while looking only at the monitor, you may cause Rear View Safety... - Page 5 INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified.
- Page 6 If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
-
Page 7: Before Beginning Installation
Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot/moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly. -
Page 8: Precautions
Never try to repair this device yourself. If any problems occur, immediately turn the display off and notify our company or an authorized dealer. Any disassembly or modification may lead to damage and will also void the warranty. Rear View Safety... -
Page 9: Features
Features ABS monitor housing that can endure high temperatures. - 5" High resolution color TFT- LCD. - Power input:8V-32V DC. - Monitor circuit has protector for battery reverse (+/-). - LED backlight display with constant voltage and constant current circuit protection. It can solve LED working temperature problems (the limit of LED backlight’s current) and prolong life. -
Page 10: Technical Parameters
Shockproof R ating operating voltage range DC11~32V Dimension 106(W) x 75(H) x 70.4(D) mm WARNING: This system should only be repaired by professionals. Please do not open and repair the system yourself. This manual is for reference only. Rear View Safety... -
Page 11: Applications
Applications Reverse With Confidence ™... -
Page 12: Monitor Menu Operation
First establish a connection between the monitor and camera. Enter the menu, chose PAIR and press OK. The monitor will display PAIRING START 50. After 50 seconds, re-energize the camera and the monitor will show the camera image in 5~10s. Rear View Safety... - Page 13 2. Picture setting Enter the menu, chose the picture and press OK, Brightness: 0-10 (Press left/right to adjust) Contrast: 0-10 (Press left/right to adjust) Color: 0-10 (Press left/right to adjust) Reverse With Confidence ™...
-
Page 14: Monitor Osd Menu Operation
3. Mirror/Normal image setting: Set the CAM1 and CAM2 image in 4 modes. 4. Auto Scan setting: 1. Set CAM1 auto scan mode on/off; 2. Set CAM2 auto scan mode on/off; 3. Set the auto scan time. Rear View Safety... - Page 15 5. Other functions: 1. NTSC or PAL system switch. 2. LED screen ambient light sensor on/off. 3. Electronic Label setting: Turn on/off the electronic label on CAM1. Note: When the monitor is in SCAN mode, the CAM1 and CAM2 image will switch automatically according to the setting time.
-
Page 16: Troubleshooting
Verify camera cable is plugged into cable port labeled Backup Camera • Connect known working camera • Verify that the green positive and cable to monitor trigger on power harness is put to power 12v+ • Verify Green trigger is receiving power Rear View Safety... -
Page 17: Warranty
ONE YEAR WARRANTY RVS SYSTEMS, INC. WARRANTS THIS PRODUCT AGAINST MATERIAL DEFECTS FOR A PERIOD OF ONE YEAR FROM DATE OF PURCHASE. WE RESERVE THE RIGHT TO REPAIR OR REPLACE ANY SUCH DEFECTIVE UNIT AT OUR SOLE DISCRETION. RVS SYSTEMS, INC. IS NOT RESPON- SIBLE FOR A DEFECT IN THE SYSTEM AS A RESULT OF MISUSE, IMPROPER INSTALLATION, DAMAGE OR MISHANDLING OF THE ELECTRONIC COMPONENTS. -
Page 18: Disclaimer
LIFE. NEITHER SHALL RVS SYSTEMS AND/OR ITS AFFILIATES HAVE ANY RESPONSIBILITY FOR ANY DECISION, ACTION OR INACTION TAKEN BY ANY PERSON IN RELIANCE ON RVS SYSTEMS SYSTEMS, OR FOR ANY DELAYS, INACCURACIES AND/OR ER- RORS IN CONNECTION WITH OUR SYSTEMS FUNCTIONS. Rear View Safety... - Page 19 NOTES Reverse With Confidence ™...
- Page 20 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
