- Page 1 Instruction Manual Backup Camera System with Waterproof Quad View Monitor and Heated Camera RVS-8129900Q Rear View Safety, Inc. © 2016 Reverse With Confidence ™...
-
Page 2: Table Of Contents
Troubleshooting......29 Warranty & Disclaimer......30-31 Rear View Safety... -
Page 3: Introduction
NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle. -
Page 4: Safety Information
Rear View Camera System. If you back up while looking only at the monitor, you may cause Rear View Safety... - Page 5 INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified.
- Page 6 If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
-
Page 7: Before Beginning Installation
Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly. -
Page 8: Installation Guide
BROWN wire is the REVERSE trigger wire. Connect this wire to the vehi- cle’s backup light circuit to activate the rear view image whenever the vehicle shifts into reverse. To attach a second camera, connect it to the CAM 1 input. Rear View Safety... - Page 9 Precautions For Use Of Monitor I. The monitor is made of glass and plastic. Do not subject it to a mechanical shock by dropping it from a high place, etc. II. Do not apply excessive force to the monitor surface or the adjoining areas since this may cause the color tone to vary.
- Page 10 Components Rear View Safety Waterproof Camera...
- Page 11 7” Waterproof Quad View Monitor with a TFT LCD digital color touch screen display. Monitor comes with a U-Bracket, swivel head mount, and a waterproof rating of IP69K. • 7” Quad View Display with multiple viewing options • Completely waterproof - IP69K •...
-
Page 12: Monitor
4 Video Inputs, 1 DVD Input Audio Inputs 4 Audio Inputs; 1 DVD input Video Outputs 1 Rec Video Output Audio Output 1 Live Audio Output Waterproof Rating IP69K Touch Screen Transmittance ≥80% Screen Operation Pressure 10~110g Screen Response Time <10ms Rear View Safety... - Page 13 Reverse With Confidence ™...
-
Page 14: Remote
1. Remote control signal sensor 2. Power button 3. Increase / decrease volume and switch sub-menu values 4. Menu selection and toggle display mode (SINGLE/DUAL/TRIPLE/ QUAD/PIP IMAGE) 5. Menu button 6. Jump Key - Immediately view predetermined display mode Rear View Safety... -
Page 15: Connections
Connections Reverse With Confidence ™... -
Page 16: Remote
Remote Operations 1. MUTE: MUTE / UNMUTE volume 2. POWER: Turn monitor ON / OFF 3. MENU: Toggle between menus 4. UP: Toggle selection UP Rear View Safety... - Page 17 5. DN: Toggle selection DOWN & toggle display mode (SINGLE/ DUAL/TRIPLE/QUAD/PIP IMAGE) 6. VOL: Decrease volume & toggle sub-menu values VOL: Increase volume & toggle sub-menu values 8. MODE: Toggle display mode (SINGLE/DUAL/TRIPLE/QUAD/PIP IMAGE) 9. SEL.: Toggle jump key 10. P/N: Toggle between PAL/NTSC 11.
-
Page 18: Osd Setup
• INPUT SCAN: Toggle camera input auto identification. When ON, monitor will display connected cameras and skip inputs not connected. • BOUNDARY: Toggle border color between camera inputs (WHITE/GRAY/ BLACK/UNCOLORED). • LANGUAGE: Toggle OSD language (ENGLISH/FRENCH/DUTCH/SPANISH/GER- MAN). • Software version appears under LANGUAGE. Rear View Safety... -
Page 19: Trigger Setting
Trigger Setting • TURN IMAGE: Display options when side cameras (CAM 1, CAM 2) are trig- gered. When on SINGLE, the corresponding camera will display when either camera is triggered. When on SPLIT, a split image of side and rear view camera will be displayed when either side camera is triggered. -
Page 20: Jump Key
Jump Key Setting Rear View Safety... -
Page 21: Jump Key
• REC-V OUT: Toggle which camera view will record when a DVR is attached (LEFT/RIGHT/FRONT/QUAD). • AUTOSCAN: When setting is ON, the monitor automatically switches be- tween connected camera inputs and quad view. • SCAN DELAY: Toggle AUTOSCAN delay (0-60 seconds). •... -
Page 22: Touch Screen Operations
When in quad view, press any channel to view full screen Rear View Safety... - Page 23 Touch screen menu Reverse With Confidence ™...
-
Page 24: Camera
Exchange picture locations of any two cameras displayed in multi-viewing mode Rear View Safety... - Page 25 Swap display position (dual/ triple view) Reverse With Confidence ™...
- Page 26 Switch to next display mode Switch to previous display mode Rear View Safety...
-
Page 27: Camera
Camera Dimensions Reverse With Confidence ™... - Page 28 Current Consumption Max. 300 ma Power Supply DC 12 V Anti-vibration Operating Temperature -45 °C ~ +70 °C, RH 95% max Storage Temperature -45 °C ~ +80 °C, RH 95% max Lens 3.6mm Optional Lens Angle 120° Rear View Safety...
-
Page 29: Troubleshooting
Troubleshooting Problem Possible Causes/Solutions Adaptor is connected incorrectly. Improper power supply. No picture/sound Unit is off. No picture Check cable connection. Audio cable improperly connected. Volume is off or set very No sound low. Dark picture Adjust brightness/contrast. Low environmental temperature. No color Adjust the color settings. -
Page 30: Warranty & Disclaimer
OTHERS OR THE UNAUTHORIZED USE OF NONCONFORMING PARTS; THE DAMAGE IS DUE TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE REAR VIEW SAFETY, INC. SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES. - Page 31 FOR ANY INJURY, LOSS OR DAMAGE, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INTENDED USE OF THE PRODUCT. IN NO EVENT SHALL REAR VIEW SAFETY AND/OR ITS AFFILIATES HAVE ANY LIABILITY FOR ANY LOSSES (WHETHER DIRECT OR INDIRECT, IN...
- Page 32 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
