- Page 1 PT-D2515 Touch Panel PC...
-
Page 2: Revision History
Preface Copyright Notice The material in this document is the intellectual property of copyright. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice. -
Page 3: Safety Instructions
Touch Panel PC Safety Instructions ￭ Always read the safety instructions carefully. ￭ Keep this User’s Manual for future reference. ￭ Keep this equipment away from humidity. ￭ Lay this equipment on a reliable flat surface before setting it up. ￭... -
Page 4: Chemical Substances Information
Preface Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), we provide the information of chemical substances in products. Battery Information European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. -
Page 5: Ce Conformity
Touch Panel PC CE Conformity Hereby, we declare that this device is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive. FCC-A Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 6: Table Of Contents
Preface Contents Copyright Notice .................... ii Trademarks ....................ii Revision History .................... ii Technical Support ..................ii Safety Instructions ..................iii Chemical Substances Information ............... iv Battery Information ..................iv CE Conformity ....................v FCC-A Radio Frequency Interference Statement ......... v WEEE Statement .................. -
Page 7: Overview
Thank you for choosing the PT-D2515, a high-performance industrial touch panel PC. The PT-D2515 is designed for panel mounting, VESA mounting or integration as open-frame chassis in machine and plant engineering. A highly integrated and easy-to-use platform, the PT-D2515 is perfect for... -
Page 8: System Overview
Overview System Overview System I/O & Controls 14 15 Touch Screen The user-friendly touch screen enables effective operation and control of the system on the user’s end. Ventilator The ventilator on the enclosure is used for air convection and to prevent the equipment from overheating. - Page 9 Touch Panel PC Antenna Connector (Optional) This connector allows you to connect an external antenna for wireless LAN. Users may find one antenna connector on the bottom I/O panel and two on the left and right sides of the system. Power Supply Switch Press the switch to turn the power supply on or off.
- Page 10 Overview RJ45 LAN Jack The standard RJ-45 LAN jack is provided for connection to the Local Area Network (LAN). You can connect a network cable to it. Yellow Green/ Orange Color LED State Condition Left Yellow LAN link is not established. On (steady state) LAN link is established.
- Page 11 Touch Panel PC RS-232 Serial Port: COM4 The serial port is a 16550A high speed communications port that sends/receives 16 bytes FIFOs. It supports barcode scanners, barcode printers, bill printers, credit card machine, etc. RS-232 Serial Port: COM2 The serial port is a 16550A high speed communications port that sends/receives 16 bytes FIFOs.
-
Page 12: System Specifications
Overview System Specifications Processor ■ Intel Atom D2550 processor Chipset ■ Intel NM10 chipset Memory ■ 2GB DDR3 1066MHz SO-DIMM ■ Realtek RTL8111E Gigabit Fast Ethernet controller Audio ■ Realtek ALC887 High Definition Audio codec Storage ■ 1 * 2.5” SATA HDD bay Display ■... -
Page 13: Power Supply
Touch Panel PC Certification ■ CE, FCC Class A, VCCI, C-Tick, CB, TUV, RoHS Power Supply ■ 84 Watt AC/DC Adapter ■ Input: 100-240V~, 1.3A, 50-60Hz ■ Output: 12V 7A MAX ■ Each COM port outputs 0.5A/Maximum OS Support ■ Windows XP 32-bit ■... -
Page 14: Me Overview
Overview ME Overview... -
Page 15: Getting Started
Getting Started This chapter provides you with the information on hardware setup procedures. While connecting peripheral devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. 1-2-1... -
Page 16: Installing Components
Getting Started Installing Components h Installing Memory 1. Locate the memory slot. 2. Align the notch on the memory with the key on the slot and insert the memory into the slot at a 45-degree angle. 3. Push the memory gently downwards until the slot clips click and lock the memory in place. - Page 17 Touch Panel PC h Installing Hard Disk Drive 1. Locate the HDD tray. The HDD tray is designed with yellow rubber grommets to cut down on vibrations. 2. To release the HDD tray, first disconnect the monitor cable. 3. And then disconnect the USB cable.
- Page 18 Getting Started 4. Unscrew the HDD tray to free it up for removal. 5. Gently remove the HDD tray from the system. 6. Fit the HDD into the tray. Be sure to put the HDD in the correct orientation.
- Page 19 Touch Panel PC 7. Fasten the HDD to the tray with screws. 8. The SATA cable comes with a large combined power and data connector for the HDD. Connect the large end of the SATA cable to the HDD. 9. Once the HDD has been securely installed onto the tray, place the tray back to the system.
- Page 20 Getting Started 10. After checking the screw holes for correct alignment, fasten the HDD tray to the system with screws. 11. Reconnect the monitor cable. 12. Reconnect the USB cable.
- Page 21 Touch Panel PC 13. To complete the installation, connect the small ends of the SATA cable to the SATA port and SATA power connector on the motherboard.
-
Page 22: Mounting The System
Getting Started Mounting the System h Panel Mounting... - Page 23 Touch Panel PC...
-
Page 24: Wall Mounting
Getting Started h Wall Mounting 2-10... -
Page 25: Connecting Power
Touch Panel PC Connecting Power Important For safety concerns, we suggest that you connect the AC/DC adapter to the system first and then connect the AC power cord to the electrical outlet. 1. Assemble the AC/DC adapter and the AC power cord. 2. -
Page 26: Powering On The System
Getting Started Powering on the System Press the power button to power on the system. 2-12... -
Page 27: Bios Setup
BIOS Setup This chapter provides information on the BIOS Setup program and allows users to configure the system for optimal use. Users may need to run the Setup program when: ■ An error message appears on the screen at system startup and re- quests users to run SETUP. -
Page 28: Entering Setup
BIOS Setup Entering Setup Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press <DEL> or <F2> key to enter Setup. Press <DEL> or <F2> to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On or pressing the RESET button. -
Page 29: Getting Help
Touch Panel PC Control Keys ← → Select Screen ↑ ↓ Select Item Enter Select Change Option General Help Previous Values Optimized Defaults Save & Exit Exit Getting Help After entering the Setup menu, the first menu you will see is the Main Menu. Main Menu The main menu lists the setup functions you can make changes to. -
Page 30: The Menu Bar
BIOS Setup The Menu Bar ▶ Main Use this menu for basic system configurations, such as time, date, etc. ▶ Advanced Use this menu to set up the items of special enhanced features. ▶ Boot Use this menu to specify the priority of boot devices. ▶... -
Page 31: Main
Touch Panel PC Main ▶ System Date This setting allows you to set the system date. The date format is <Day>, <Month> <Date> <Year>. ▶ System Time This setting allows you to set the system time. The time format is <Hour> <Min- ute>... -
Page 32: Advanced
BIOS Setup Advanced ▶ Quiet Boot This BIOS feature determines if the BIOS should hide the normal POST messages with the motherboard or system manufacturer’s full-screen logo. When it is enabled, the BIOS will display the full-screen logo during the boot-up sequence, hiding normal POST messages. - Page 33 Touch Panel PC ▶ CPU Configuration ▶ Hyper-Threading The processor uses Hyper-Threading technology to increase transaction rates and reduces end-user response times. The technology treats the two cores inside the processor as two logical processors that can execute instruc- tions simultaneously. In this way, the system performance is highly improved. If you disable the function, the processor will use only one core to execute the instructions.
- Page 34 BIOS Setup ▶ Super IO Configuration ▶ Serial Port 1/ 2/ 4/ 5/ 6 This setting enables/disables the specified serial port. ▶ Change Settings This setting is used to change the address & IRQ settings of the specified serial port. ▶...
- Page 35 Touch Panel PC ▶ Hardware Health Configuration These items display the current status of all monitored hardware devices/compo- nents such as voltages, temperatures and all fans’ speeds. ▶ Thermal Shutdown This setting controls the thermal shutdown function to prevent the system from overheating.
- Page 36 BIOS Setup ▶ USB Support This setting enables/disables the onboard USB controller. ▶ Legacy USB Support Set to [Enabled] if you need to use any USB 1.1/2.0 device in the operating system that does not support or have any USB 1.1/2.0 driver installed, such as DOS and SCO Unix.
-
Page 37: Boot
Touch Panel PC Boot ▶ Boot Option Priorities This setting allows users to set the sequence of boot devices where BIOS at- tempts to load the disk operating system. ▶ Hard Drive BBS Priorities This setting allows users to set the priority of the specified devices. First press <Enter>... -
Page 38: Security
BIOS Setup Security ▶ Administrator Password Administrator Password controls access to the BIOS Setup utility. ▶ User Password User Password controls access to the system at boot and to the BIOS Setup utility. ▶ Serial Port Console Redirection 3-12... - Page 39 Touch Panel PC ▶ Console Redirection Console Redirection operates in host systems that do not have a monitor and keyboard attached. This setting enables/disables the operation of console re- direction. When set to [Enabled], BIOS redirects and sends all contents that should be displayed on the screen to the serial COM port for display on the terminal screen.
-
Page 40: Chipset
BIOS Setup Chipset ▶ IGFX - Boot Type Use the field to select the type of device you want to use as the boot display of the system. ▶ Fixed Graphics Memory Size This setting specifies the size of system memory allocated for video memory. 3-14... -
Page 41: Power
Touch Panel PC Power ▶ ACPI Sleep State This item specifies the power saving modes for ACPI function. If your operating system supports ACPI, you can choose to enter the Standby mode in S1 (POS) or S3 (STR) fashion through the setting of this field. ▶... - Page 42 BIOS Setup ▶ Resume On Ring An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call on the modem) awakens the system from a soft off state. ▶ Resume On RTC When [Enabled], your can set the date and time at which the RTC (real-time clock) alarm awakens the system from suspend mode.
-
Page 43: Save & Exit
Touch Panel PC Save & Exit ▶ Save Changes and Exit Save changes to CMOS and exit the Setup Utility. ▶ Discard Changes and Exit Abandon all changes and exit the Setup Utility. ▶ Restore Defaults Restore the factory defaults. ▶... -
Page 45: Appendix Wdt & Gpio
Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output). 2-A-1... -
Page 46: Wdt Sample Code
WDT & GPIO WDT Sample Code SIO_INDEX_Port equ 04Eh SIO_DATA_Port equ 04Fh SIO_UnLock_Value equ 087h SIO_Lock_Value equ 0AAh WatchDog_LDN equ 007h WDT_UNIT equ 60h ;60h=second, 68h=minute, 40h=Disabled Watchdog timer WDT_Timer equ 30 ;ex. 30 seconds Sample code: ;Enable config mode dx, SIO_INDEX_Port al, SIO_UnLock_Value dx, al... -
Page 47: Gpio Sample Code
Touch Panel PC GPIO Sample Code GPI 0 ~ GPI 3 GPI 0 GPI 1 GPI 2 GPI 3 IO Address 50Ch 50Ch 50Ch 50Ch SIO GPIO Register Sample code GPO 0 ~ GPO 3 GPO 0 GPO 1 GPO 2 GPO 3 IO Address...
