Contec PT-E831H User Manual

Ipc series panel-pc e series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IPC Series
PANEL-PC E Series
PT-E831H, PT-E831HS
User's Manual
CONTEC CO.,LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT-E831H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Contec PT-E831H

Summary of Contents for Contec PT-E831H

  • Page 1 IPC Series PANEL-PC E Series PT-E831H, PT-E831HS User’s Manual CONTEC CO.,LTD.
  • Page 2 Royalty consent contract Recovery Media *1 Please confirm latest information on the CONTEC homepage though the user's manual is stored in Recovery Media. The installation method is described in this document as well as the UsersManual. [File storing place: \Manual]...

  • Page 3: Copyright

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 4: Table Of Contents

    System Configuration ..........................19 Component Function ..........................20 Operation State LED ........................20 AC Power Input Connector : AC-IN................... 21 ON/OFF Switch: POWER SW ...................... 23 CF Card Slot ........................... 24 Giga bit-Ethernet : LAN 1 – 2..................... 26 PT-E831H, PT-E831HS User’s manual...
  • Page 5 Onboard PATA Master/Onboard PATA Slave ................83 Onboard SATA-0/Onboard SATA-1....................85 Advanced BIOS Features Setup ......................86 Hard Disk Boot Priority .........................87 Advanced Chipset Features Setup ......................92 VGA Setting............................94 Integrated Peripherals ..........................96 OnChip IDE Device ..........................97 On Chip Serial ATA setting........................99 Onboard Device ...........................100 PT-E831H, PT-E831HS User’s manual...
  • Page 6 Super IO Device ..........................102 PnP/PCI Configuration Setup......................103 IRQ Resources ............................. 105 PC Health Status ..........................106 Defaults Menu ............................. 107 Supervisor/User Password Setting ...................... 108 Exit Selecting............................109 9. APPENDIX Battery Specification ........................... 111 10. LIST OF OPTIONS PT-E831H, PT-E831HS User’s manual...
  • Page 7 PT-E831H, PT-E831HS User’s manual...

  • Page 8: Introduction

    *: For the LCD resolution, there are about two dots upper and lower, right and left are masked by the protective sheet. Therefore, please set the screen size in consideration of the masked range when creating a screen. - Standard: Ethernet, USB, RS232C, WDT, RS485/RS422 - Special I/F: SSCNET + Standard I/F PT-E831H, PT-E831HS User’s manual...

  • Page 9: Features

    Compact size PT-E series’ fan less structure makes PT-E get a compact size. It is easy to build PT-E in the equipment. Supported OS Windows XP Professional / Windows XP Embedded PT-E831H, PT-E831HS User’s manual...

  • Page 10: Customer Support

    You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC products are warranted by CONTEC CO., LTD.

  • Page 11: Safety Precautions

    Before starting cleaning the PT-E and/or peripheral devices, always power off the PT-E and/or peripheral devices. Not doing so can cause a failure or electric shock. Do not allow dust and foreign matter to enter the PT-E and peripheral devices. Doing so can cause a fire or electric shock. PT-E831H, PT-E831HS User’s manual...
  • Page 12 To prevent corruption of files, always shutdown the OS before turning off this product. CONTEC reserves the right to refuse to service a product modified by the user. In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord immediately and contact your retailer.
  • Page 13 (4) LCD backlight--- Display brightness decreases over time with use. The operating lifetime of the backlight is 50,000 hours (the time until the brightness is lowered to 50% of the initial value at atemperature of 25°C). PT-E831H, PT-E831HS User’s manual...

  • Page 14: System Reference

    "Front display section is 0°C to 40°C, other than display section is 0°C to 45°C". (*5): The capacity of CF is a value when 1GB is calculated by 1 billion bytes. The capacity that can be recognized from OS PT-E831H, PT-E831HS User’s manual...
  • Page 15 DC output (only PT-E831HS) should be 5V/2A, 12V/1A or less. (*2): When using both 2CH Ethernets in 1000BASE-T, please use PT-E under the environment where the operating ambient temperature is "Front display section is 0°C to 40°C, other than display section is 0°C to 45°C". PT-E831H, PT-E831HS User’s manual...
  • Page 16 Figure 2.1 Definition of viewable range CAUTION The above optical specification data shows optical characteristics of the liquid crystal in the display; the data does not represent the actual view on the display or its viewing angles. PT-E831H, PT-E831HS User’s manual...

  • Page 17: Physical Dimensions

    2. System Reference Physical Dimensions PT-E831H / PT-E831HS Figure 2.2 Physical Dimensions PT-E831H, PT-E831HS User’s manual...

  • Page 18: Hardware Setup

    By referring to Chapter 8, set up BIOS. This setup requires a keyboard and a display. * Before using this product, be sure to execute “ LOAD SETUP DEFAULTS” to initialize the BIOS settings to their default values. (See Chapter 8, “Main Menu.”) PT-E831H, PT-E831HS User’s manual...

  • Page 19: Hardware Setup

    (1) The following panel cutting is needed to mount PT-E. The plate thickness of the mounting panel is maximum 5.0 mm (0.20 inch). (The plate thickness of the mounting panel is minimum 1.6 mm.) Figure 3.1 Dimensions of Panel Opening (PT-E831H / PT-E831HS) (2) Put PT-E into the mounting hole.
  • Page 20 (3) Place the mounting fittings in the holes of PT-E, make the latches catch theholes. Mount four mount fittings on the upside and downside holes of PT-E Figure 3.3 setting the mounting fittings (PT-E831H / PT-E831HS) (4) Tighten the screws of mounting fittings to fix PT-E.

  • Page 21: Installation Requirements

    Basically mount main body of PT-E in vertical direction. PT-E must be mounted with a tilt of +/- 30° or less from vertical when mounting it diagonally. Figure 3.5 Installed angle which is recommended CAUTION Do not mount the main body of PT-E upward or downward. PT-E831H, PT-E831HS User’s manual...
  • Page 22 Do not install this product into the fully-sealed space except the case in which the internal temperature is adjustable by equipment such as air conditioner. Troubles such as operational malfunctions could be occurred by the temperature increase caused by long-term usage. PT-E831H, PT-E831HS User’s manual...
  • Page 23 3. Hardware Setup PT-E831H, PT-E831HS User’s manual...

  • Page 24: Each Component Function

    4. Each Component Function 4. Each Component Function Parts Identification PT-E831H/PT-E831HS Figure 4.1 Parts Identification PT-E831H, PT-E831HS User’s manual...
  • Page 25 Do not need the battery pack if not use resume function. Switch COM3’s communication mode among RS232C, RS422 and RS485. (18) Setting switch (Switch No.1 to No.7) (19) ON/OFF switch Switch power on/off. Upside: ON; downside: OFF. PT-E831H, PT-E831HS User’s manual...

  • Page 26: System Configuration

    4. Each Component Function System Configuration PT-E831H/PT-E831HS Figure 4.2 System Configuration PT-E831H, PT-E831HS User’s manual...

  • Page 27: Component Function

    LED display color During starting or shutdown, or EPC System Monitor is not Red blinking started, or EPC System Monitor process error occurring. During EPC System Monitor running Red lihgting During resume function working Green blinking PT-E831H, PT-E831HS User’s manual...

  • Page 28: Ac Power Input Connector : Ac-In

    PT-E. Connect LG and FG terminals and directly earth them using an earth cable of φ2mm2 or more. PT-E831H / PT-E831HS can use power supply voltage of "100VAC to 240VAC". Do not connect PT-E with an improper power supply voltage. Doing so can cause a breakdown.
  • Page 29 Ground lightening surge absorber (EA) and PT-E’s power cable earth wire (EB) separately. Select the lightening surge absorber that not exceeds the maximum permissible circuit voltage of the sure absorber at the maximum power supply voltage. PT-E831H, PT-E831HS User’s manual...

  • Page 30: On/Off Switch: Power Sw

    Keep standby state for 30 minutes. Standby state is released when power restoring; and operation is restarted immediately from the state right before power failure. *Require the battery pack PT-E73BAT(Optional) if use resume function. ON/OFF Switch: POWER SW POWER SW is provided. PT-E831H, PT-E831HS User’s manual...

  • Page 31: Cf Card Slot

    Up to two pieces of disks can be mounted. Figure 4.11 Mounting a CF card CAUTION The drive near the backside of PT-E is the primary master drive; the drive near the LCD panel side is the primary slave drive. PT-E831H, PT-E831HS User’s manual...
  • Page 32 Figure 4.12 Eject button (2) Push in the eject button. Push in the eject button and push out the CF card halfway. Pull and remove the CF card gently with your hand. Figure 4.13 Removing a CF card PT-E831H, PT-E831HS User’s manual...

  • Page 33: Giga Bit-Ethernet : Lan 1 - 2

    : Operation LED 10M: Off, 100M: Green, 1000M: Red LAN drivers Install the appropriate LAN driver for your OS from the CONTEC’s Web site [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) CAUTION When using both 2 ch Ethernets in 1000 BASE -T, please use PT-E under the environment where the operating ambient temperature is "Front display section is 0°C to 40°C, other than display section is...

  • Page 34: Usb Port: Usb

    Serial Port Interface: COM2 – 3 Serial Port COM2 (RS232C) This product has a serial port that corresponds to RS232C, Table 4.5 Serial Port Connector (COM2) Connector used D-sub9 pin, male on the product Pin No. Function PT-E831H, PT-E831HS User’s manual...
  • Page 35 RS422 and RS485. Using the serial communication mode setting switches (No.1 to No.7), you can set communication mode for serial port COM3. The setting method is as follows. (1) Remove the two screws on the back of PT-E, and remove the cover. Figure 4.14 Remove the cover PT-E831H, PT-E831HS User’s manual...
  • Page 36 (1) Switch No.3, 8 and 9 are set by maker. They are unavailable for user. PT-E might not work normally if set them ON. Do not set them ON please. (2) Switch setting other than the patterns in Table 4.7 may lead to communication failure. Do not set switches to pattern other than Table 4.7. PT-E831H, PT-E831HS User’s manual...

  • Page 37: Wdt/Emg Connector

    Figure 4.16 Emergency Stop Wiring Example CAUTION (1) Need wiring above when releasing the emergency stop for servo amplifier. (2) When wiring for emergency stop, always connect or disconnect to EMG connector after turning off the power supplied to PT-E. PT-E831H, PT-E831HS User’s manual...

  • Page 38: Ide Connector

    This product is equipped with a Connector for IDE power supply cable (PT-71IDE-PWCBL). Table 4.9 DC Power Supply Connector DC Power Supply Connector PCI Bus Expansion Slot This product is equipped with a Slot for Connecting an add-on unit and use PCI-bus expansion board. PT-E831H, PT-E831HS User’s manual...

  • Page 39: Sscnet Connector

    4. Each Component Function SSCNET Connector PT-E831HS is equipped with 1 port for SSCNET. Table 4.10 SSCNET Connector Pin No. Function EMG1 RD2L RD1L EMG1L TD2L TD1L PT-E831H, PT-E831HS User’s manual...

  • Page 40: Startup And Termination

    For installing OS, commercially available CD-ROM for Windows setup and PT-E dedicated driver CD are necessary. The customer needs to purchase CD-ROM for Windows setup. Contact our agent or sales office if you need PT-E dedicated driver CD. PT-E831H, PT-E831HS User’s manual...

  • Page 41: Write-Protect

    Move the cursor to [All programs (P)] → [Accessories] and click [Command Prompt]. Click here Click here Figure 5.1 Command Prompt (2) The command prompt is started. Input command "ewfmgr C: -enable" and then press [Enter] key. Figure 5.2 Executing command PT-E831H, PT-E831HS User’s manual...
  • Page 42 Figure 5.3 The item of Boot Command (4) Quit command prompt and then restart PT-E. (5) Write-protect is executed after restarting PT-E. As for the method of confirming the state of write-protect, refer to next page. PT-E831H, PT-E831HS User’s manual...
  • Page 43 Move the cursor to [All programs (P)] → [Accessories] and click [Command Prompt]. Click here Click here Figure 5.4 Command Prompt (2) The command prompt is started. Input command "ewfmgr C: -disable" and then press [Enter] key. Figure 5.5 Releasing Command PT-E831H, PT-E831HS User’s manual...
  • Page 44 (3) Show as follows as soon as the releasing of write-protect is completed. Confirm that the item of "Boot Command" becomes "DISABLE". Confirm this item. Figure 5.6 The item of Boot Command (4) Quit command prompt and then restart PT-E. (5) Write-protect is released after restarting PT-E. PT-E831H, PT-E831HS User’s manual...
  • Page 45 *: When confirming the state of the CF card, the item of "Boot Command" shows as "NO_CMD", executing/releasing write-protect cannot be switched. Confirm this item. Figure 5.8 The item of State and the item of Boot Command (3) Quit command prompt. (Not require to restart PT-E). PT-E831H, PT-E831HS User’s manual...

  • Page 46: Power Off

    3) The window of [Turn off computer] is displayed. Choose Turn Off to switch off the power. Figure 5.10 The window of Turn off computer 4) After quitting the system, switch the power supplied to PT-E main body. PT-E831H, PT-E831HS User’s manual...
  • Page 47 Doing so can lose data or damage the CF card. (4) Do not operate the power ON/OFF switch near the CF card slot during operation state LED lighting on or blinking. Doing so can lose data or damage the CF card. PT-E831H, PT-E831HS User’s manual...

  • Page 48: Setting The Touch Panel Driver

    However, when exchange a start-up disk and if a touch position is shifted, do calibration setting again. (1) Click [Start] on taskbar. Move the cursor to [All programs (P)] → [UPDD] and click [Operation Setting]. Click here. Figure 6.1 [Settings] button PT-E831H, PT-E831HS User’s manual...
  • Page 49 Figure 6.2 Pointer Device Properties CAUTION When changed settings, always click [Apply (A)] button to make the changed settings available. Clicking [Apply (A)] button makes the controller initialization, which may make touch panel not react for several seconds PT-E831H, PT-E831HS User’s manual...
  • Page 50 Perform this operation for all numbers of points that have been set at “point number “in [Calibration Setting] window. If the screen is not touched for the time that has been set in the calibration settings, calibration window will be closed and calibration is aborted. Do calibration setting again. PT-E831H, PT-E831HS User’s manual...
  • Page 51 PT-E. Don’t need to do calibration again even though exchange start-up disk. (1) Click [Start] on taskbar. Move the cursor to [All Programs (P)] → [UPDD] and click [Operation Setting]. Click here. Figure 6.5 Settings button PT-E831H, PT-E831HS User’s manual...
  • Page 52 Click [Apply (A)] button when change the settings so that the changed settings are available. After completing all settings, click [Calibration (C)] button. Check here. Figure 6.6 Pointer Device Properties (3) The calibration window is displayed; make calibration following the procedures in p. 43-44. PT-E831H, PT-E831HS User’s manual...

  • Page 53: Test

    This section describes how to do an operation test for touch panel. (1) Click [Start] on taskbar. Move the cursor to [All Programs (P)] → [UPDD] and click [Test]. Click here. Figure 6.7 [Test]button PT-E831H, PT-E831HS User’s manual...
  • Page 54 Press [Close] button to back to the test window. Figure 6.9 Test window (Grid view) 2) Clear Press [Clear] button to clear the line and characters that are drawn or written when testing. 3) Close Press [Close] button to exit test window. PT-E831H, PT-E831HS User’s manual...

  • Page 55: Mouse Operation

    There is no left/right button on touch panel like a mouse, use [Event selector] enable the right-click operation by touch panel. Do this operation as follows. 1) Click [Start] on taskbar. Move the cursor to [All Programs (P)] → [UPDD] and click [Event selector]. Click here. Figure 6.10 [Event Selector] button PT-E831H, PT-E831HS User’s manual...

  • Page 56: Function Of Touch Panel Driver

    Make necessary settings for touch action. This section describes how to make these settings. (1) Click [Start] on taskbar. Move the cursor to [All Programs (P)] and click [Operation Setting]. Click here. Figure 6.12 [Settings] button PT-E831H, PT-E831HS User’s manual...
  • Page 57 About calibration setting, refer to p. 41. 3) [Test (T)] button Make a touch operation testing. About testing, refer to p. 46. 4) [OK] button Save the setting data, and exit "Touch Panel Driver Properties" window. PT-E831H, PT-E831HS User’s manual...
  • Page 58 Double-click the file to register the setting environment. (5) Dump settings Use this function to dump driver and system settings to a text file UPDDset.txt. Click [Dump setting (M)] button to create a file "UPDDset.txt". The file is in folder C: \Program Files\UPDD\UPDDset.txt. PT-E831H, PT-E831HS User’s manual...
  • Page 59 (3) Calibration points Specify the number of calibration points to be set. The default is "4" points. For revising a position difference correctly, increase the number of the calibration points. - The setting range 2 to 25 points PT-E831H, PT-E831HS User’s manual...
  • Page 60 - Save to EEPROM Refer to p. 44 (8) Calibration Pattern Show the calibration point pattern to be set in (3) and (5). Used to confirm the number of points and point position that have been set in (3) and (5). PT-E831H, PT-E831HS User’s manual...
  • Page 61 (1) Device list Show the information of the controller to be used. (2) [Add (D)] button Add a controller. (3) [Modify (M)] button Change name or operation object of controller. (4) [Remove (R)] button Delete a controller. PT-E831H, PT-E831HS User’s manual...
  • Page 62 Set serial port that is connected with controller. (3) Auto Detect If enabled, when windows start-up, the serial port connected the controller is detected automatically. (4) Information of communication port Show the information of the serial port connected with the controller. PT-E831H, PT-E831HS User’s manual...
  • Page 63 If enabled, when click the screen, it assumes separated immediately when separating a finger. When input characters, don’t check the checkbox. (7) [Default (U)] button Press the [Default (U)] button to return to the default setting. PT-E831H, PT-E831HS User’s manual...
  • Page 64 Check the checkbox to make touch operation available. When doing the touch operation, don’t remove the checking. 3) Initialize Indicates that the device’s initialization macro, if it exists, it will be executed. 4) Sound Enables or disables the Sound option that accompanies simulated button presses. PT-E831H, PT-E831HS User’s manual...
  • Page 65 48. Figure 6.21 Event tab (1) Primary Set mouse’s primary action setting. (2) Secondary Set mouse’s secondary action setting. (3) [Defaults] button Press [Defaults] button to return to the default setting. PT-E831H, PT-E831HS User’s manual...
  • Page 66 Used to test single and double click responses, which is set in section (1). You can click to test single or double click response. When touching is recognized as a single or double-click, the icon changes from PT-E831H, PT-E831HS User’s manual...
  • Page 67 Show the status information of the controller. (2) [Reset (X)] button Reset the default status. (3) [Refresh (R)] button Reset the count values shown for the "Com port error", "Overflow" and "Synchronize error". (4) [Re-initialise (Z)] button Re-initialise the controller. PT-E831H, PT-E831HS User’s manual...
  • Page 68 Figure 6.24 About tab (1) Touch Panel Driver Show the version information of the controller to be used. (2) [Support (P)] button Show the support information. (3) [License (L)] button Show Licence agreement information of touch panel driver. PT-E831H, PT-E831HS User’s manual...
  • Page 69 6. Setting the Touch panel Driver PT-E831H, PT-E831HS User’s manual...

  • Page 70: Resume Function/ Epc System Monitor

    UPS. If lithium ion battery is not full-charged, PT-E might go to shutdown operation even within the specified time. If lithium ion battery is in the state of discharge (under 6.7V), resume function will not work. PT-E831H, PT-E831HS User’s manual...

  • Page 71: Epc System Monitor

    (5) Event log Output hardware monitor state change or occurred alarm information to a history file. (6) State output PT-E main body hardware’s monitor state or alarm information can be used by other applications. PT-E831H, PT-E831HS User’s manual...
  • Page 72 USB fuse blown Green Give an alarm when detecting USB fuse blowout. Display forecast result of condenser longevity based on Condenser Longevity Operating Time and System Temperature. Give an alarm Green Forecast when forecast result is over 98%. PT-E831H, PT-E831HS User’s manual...
  • Page 73 Reset condenser longevity forecast result and the related Condenser Longevity alarm message (longevity warning). Forecast result will be (13) None Forecast Reset button added up from 0.00% after reset. Do this operation when only exchanging PT-E main body (Goes on using CF card.) PT-E831H, PT-E831HS User’s manual...
  • Page 74 *2: PT-E73BAT is a lithium ion battery pack for using resume function. *3: Dotted line region is masked if set [Not use] in the area of Resume function. *4: ENC BAT is encoder battery of servo amplifier that is connected to PT-E. PT-E831H, PT-E831HS User’s manual...
  • Page 75 Click button [Set UP] that is at the bottom of Start screen, EPC System Monitor’s Set UP Screen is displayed. There is [Power] setting and [Other] setting in Set UP screen. (1) [Power] setting Set necessary items for power management. The following shows power setting screen. Figure 7.2 [Power] Setting screen PT-E831H, PT-E831HS User’s manual...
  • Page 76 If choose this item, EPC System Monitor’s start screen will be monitor screen (refer minimized when minimized and put in task bar at the moment of starting. to p. 65) is displayed at starting Display the screen and operate when necessary. the moment of starting. PT-E831H, PT-E831HS User’s manual...
  • Page 77 Push OK button, close Set UP screen, and restart Windows. *1: Using EPC System Monitor’s start option set whether use resume function or not. (Refer to p. 73 for setting method.) *2: WDT is abbreviation of Watch Dog Timer. PT-E831H, PT-E831HS User’s manual...
  • Page 78 Set head number of b. Access CB/CW memory with application such as VC++ etc. and display them on Momery CB/CW user screen. Output data to Windows shared memory occupies 16-byte as bit data and 8-word as word data. PT-E831H, PT-E831HS User’s manual...
  • Page 79 0 - 10000 PT-A6BAT Exchange Forecast (*0.01%) 0 - 10000 Encoder battery Exchange Forecast (*0.01%) 0 - 10000 Operating Time (H) 0 - 65535 System Information (EPC System Monitor 1Sec counter) 0 - 65535 System information None PT-E831H, PT-E831HS User’s manual...
  • Page 80 Set operation state output memory (BIT). /B100 Windows Not set: Windows shared memory, or (16 points from CB100 Shared memory Set: Set head number of shared memory (CB)) are output.) If setting number is improper, works by CB0. PT-E831H, PT-E831HS User’s manual...
  • Page 81 (UPCUtl.inf), Event history file (EpcUtilLog.txt). Number of character: Max.240 characters(half-size character) Characters to be prohibited: \ / : ; , . * ? < > | *: Work based default setting if no option setting is done. PT-E831H, PT-E831HS User’s manual...
  • Page 82 (2) Please set optional settings in the setting range. (3) During EPC System Monitor working, do not remove the drive where has been specified by option setting as file save folder. Doing so may cause file writing error. PT-E831H, PT-E831HS User’s manual...
  • Page 83 7. Resume Function/ EPC System Monitor PT-E831H, PT-E831HS User’s manual...

  • Page 84: Bios Setup

    <Ctrl>, <Alt>, and <Delete> keys simultaneously. If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to continue, DEL to enter SETUP PT-E831H, PT-E831HS User’s manual...

  • Page 85: Using Setup

    Even a seemingly small change to the chipset setup has the potential for causing you to use the override. A Final Note About Setup The information in this chapter is subject to change without notice. PT-E831H, PT-E831HS User’s manual...

  • Page 86: Main Menu

    Use this menu to specify your settings for integrated peripherals. PnP / PCI Configuration This entry appears if your system supports PnP / PCI. Load Fail-Safe Defaults Use this menu to load the BIOS default values for the minimal/stable performance for your system to operate. PT-E831H, PT-E831HS User’s manual...
  • Page 87 Supervisor / User Password Use this menu to set User and Supervisor Passwords. Save & Exit Setup Save CMOS value changes to CMOS and exit setup. Exit Without Save Abandon all CMOS value changes and exit setup. PT-E831H, PT-E831HS User’s manual...

  • Page 88: Standard Cmos Setup

    The items in Standard CMOS Setup Menu are divided into 11 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. PT-E831H, PT-E831HS User’s manual...

  • Page 89: Main Menu Selections

    All, but Keyboard Displays the amount of conventional Base Memory memory detected during boot up Displays the amount of extended memory Extended Memory detected during boot up Displays the total memory available in the Total Memory system PT-E831H, PT-E831HS User’s manual...

  • Page 90: Onboard Pata Master/Onboard Pata Slave

    Max = 65535 Min = 0 Head Set the number of heads for this CF card. Max = 255 **** Warning: Min = 0 Precomp Setting a value of 65535 means no CF card Max = 65535 PT-E831H, PT-E831HS User’s manual...
  • Page 91 8. BIOS Setup Item Option Description Min = 0 Landing zone **** Max = 65535 Min = 0 Sector Number of sectors per track Max = 255 PT-E831H, PT-E831HS User’s manual...

  • Page 92: Onboard Sata-0/Onboard Sata-1

    Min = 0 **** Warning: Precomp Max = 65535 Setting a value of 65535 means no HDD Min = 0 Landing zone **** Max = 65535 Min = 0 Sector Number of sectors per track Max = 255 PT-E831H, PT-E831HS User’s manual...

  • Page 93: Advanced Bios Features Setup

    Typematic Rate (Chars/Sec) 6 x Typematic Delay (Msec) Security Option [Setup] Summary Screen Show [Disabled] ↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults Figure 8.5 Advanced BIOS Features Setup PT-E831H, PT-E831HS User’s manual...

  • Page 94: Hard Disk Boot Priority

    Details screen is displayed when selecting the item of [Hard Disk Boot Priority] on the screen of [Advanced BIOS Features] Table 8.5 Hard Disk Boot Priority Item Option CHO.M Set the connected HD. Bootable Add-in Cards Set start priority order of connecting HD. PT-E831H, PT-E831HS User’s manual...
  • Page 95 We recommend that you normally disable quick POST. Better to find a problem during POST than lose data during your work. First Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. PT-E831H, PT-E831HS User’s manual...
  • Page 96 Boot Up NumLock Status Toggle between On or Off to control the state of the NumLock key when the system boots. When toggled On, the numeric keypad generates numbers instead of controlling cursor operations. PT-E831H, PT-E831HS User’s manual...
  • Page 97 6, 8, 10, 12, 15, 20, 24 or 30 characters per second. Typematic Delay (Msec) When the speed setting for the key input is enabled, you can specify the interval of waiting time for the continuous key input. PT-E831H, PT-E831HS User’s manual...
  • Page 98 <Enter>, it will disable security. Once the security is disabled, the system will boot and you can enter Setup freely. Summary Screen Show Set whether or not to display configuration screen after BIOS starting. PT-E831H, PT-E831HS User’s manual...

  • Page 99: Advanced Chipset Features Setup

    The value in this field depends on performance parameters of the installed memory chips (DRAM). Do not change the value from the factory setting unlees you install new memory that has a different performance rating than the original DRAMs. PT-E831H, PT-E831HS User’s manual...
  • Page 100 Video BIOS Cacheable Selecting Enabled allows caching of the video BIOS ROM at C0000h - C7FFFh, resulting in better video performance. However, if any program writes to this memory area, a system error may result. PT-E831H, PT-E831HS User’s manual...

  • Page 101: Vga Setting

    Auto: Enable graphic controller automatically On-Chip Frame Buffer Size When Enabled, a fixed VGA frame buffer from A000h to BFFFh and a CPU-to-PCI write buffer are implemented. DVMT Mode Allows you to set the Dynamic Video Memory Technology (DVMT) mode. PT-E831H, PT-E831HS User’s manual...
  • Page 102 Choose an active display at the time of starting.. Panel Type Set panel type that the system supports. Do not change the setting. Boot After SWON Set whether or not to do system start setting. Do not change the setting. PT-E831H, PT-E831HS User’s manual...

  • Page 103: Integrated Peripherals

    This section sets configurations for your hard disk and other integrated peripherals. The first screen shows three main items for user to select. Once an item selected, a submenu appears. Details follow. Figure 8.8 Integrated Peripherals PT-E831H, PT-E831HS User’s manual...

  • Page 104: Onchip Ide Device

    On-Chip Primary PCI IDE The integrated peripheral controller contains an IDE interface with support for 2 IDE channels. Select Enabled to activate each channel separately. PT-E831H, PT-E831HS User’s manual...
  • Page 105 ATA commands and the ATA bus to allow DMA commands to transfer data at a maximum burst rate of 33 MB/s. When you select Auto in the two IDE UDMA fields, the system automatically determines the optimal data transfer rate for each IDE device. PT-E831H, PT-E831HS User’s manual...

  • Page 106: On Chip Serial Ata Setting

    8. BIOS Setup On Chip Serial ATA setting Table 8.10 On Chip Serial ATA setting Selection Description Choices On-Chip Serial ATA Disabled: Not use serial ATA. Enabled: Use serial ATA. External IDE Device is recognized as SATA1. PT-E831H, PT-E831HS User’s manual...

  • Page 107: Onboard Device

    Description Choices USB Controller Enable or disable the USB Over Current. In normal cases, set it as “Enabled”. USB 2.0 Controller Enable or disable the Onboard USB 2.0 function. In normal cases, use it while “Enable”. PT-E831H, PT-E831HS User’s manual...

  • Page 108: Pt-E831H, Pt-E831Hs User's Manual

    Select “Enabled” when a USB keyboard has to be used on the OS that does not support USB. Select “ Disabled ” for the OS that supports USB such as Windows XP. Azalia/AC97 Audio Select Set audio function. PT-E831H, PT-E831HS User’s manual...

  • Page 109: Super Io Device

    Figure 8.11 SuperIO Device Table 8.12 Super I/O device Selections Description Choices Onboard Serial Port 2 Set whether or not to use Serial Port 2. Onboard Serial Port 3 Set whether or not to use Serial Port 3. PT-E831H, PT-E831HS User’s manual...

  • Page 110: Pnp/Pci Configuration Setup

    Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot. PT-E831H, PT-E831HS User’s manual...
  • Page 111 The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play – compatible devices. If you select Auto, all the interrupt request (IRQ) and DMA assignment fields disappear, as the BIOS automatically assigns them. PT-E831H, PT-E831HS User’s manual...

  • Page 112: Irq Resources

    This item is designed to overcome some problems that can be caused by some non-standard VGA cards. This product includes a built-in VGA system that does not require palette snooping so you must leave this item disabled. Leave this field at Disabled. PT-E831H, PT-E831HS User’s manual...

  • Page 113: Pc Health Status

    Vcore / VMEM / +3.3V / 5V / 12V / 1.05V / 3.3VSB / 5VSB / Display current voltage values. Voltage Battery System1 Temp System1 Temp Display current system1 temperature. System2 Temp System1 Temp Display current system1 temperature. CPU Temp CPU Temp Display current CPU temperature PT-E831H, PT-E831HS User’s manual...

  • Page 114: Defaults Menu

    When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load setup Defaults (Y/N) ? N Pressing ‘Y’ loads the default values that are factory settings for optimal performance system operations. PT-E831H, PT-E831HS User’s manual...

  • Page 115: Supervisor/User Password Setting

    You determine when the password is required within the BIOS Features Setup Menu and its Security option. If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup. PT-E831H, PT-E831HS User’s manual...

  • Page 116: Exit Selecting

    Pressing <Enter> on this item asks for confirmation: Quit without saving (Y/N)? Y This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your computer. PT-E831H, PT-E831HS User’s manual...
  • Page 117 8. BIOS Setup PT-E831H, PT-E831HS User’s manual...

  • Page 118: Appendix

    (1) Switch off the power supplied to PT-E. In case of using a resume battery, remove it. (2) Remove two screws on the back of PT-E, and then remove the cover. Figure 9.1 Exchange the battery 1 PT-E831H, PT-E831HS User’s manual...
  • Page 119 Do not remove PT-A6BAT during turning on. Doing so may lead EPC System Monitor not be able todetect low voltage depending on the situation of the electric charge which is stored up on thecondenser that is connected with PT-A6BAT in parallel. PT-E831H, PT-E831HS User’s manual...

  • Page 120: List Of Options

    : CF card slot x1 / USBx1 (Use 2 USB ports on PT-E ) PT-E73FRUS : USBx1 (Use 1 USB port on PT-E) IDE Power Supply Cable PT-E71IDE-PWCBL : PT-E can supply 5V/12V DC power.The usable currents are 5V/2A, 12V/1A PT-E831H, PT-E831HS User’s manual...
  • Page 121 (3) If use PT-E in the environment of operating ambient temperature 55 degrees, currents supplied to the external devices should be under DC5V/2A and DC12V/0.5A DC12V load current limitation at the moment of using DC5V/2A * Check the CONTEC’s Web site for the latest information on these options. PT-E831H, PT-E831HS User’s manual...
  • Page 123 //www.contec.co.jp/ English http: //www.contec.com/ Chinese http: //www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [09272011] [09272011] Management No. NA01509 Parts No. LYNE751...
