Side XLR Panel
LINE OUT
11
+4dBu balanced 5-pin XLR Output
PWR 11-18V
12
2-pin Lemo for external power in
Side Mini-Jack Panel
LINE OUT
13
+4dBu stereo 3.5mm unbalanced output
L
14
Left unbalanced 3.5mm mic input. Provides 3.5 volt plug-in power
R
15
Right unbalanced 3.5mm mic input. Provides 3.5 volt plug-in power
ST
16
Stereo unbalanced 3.5mm mic input. Provides 3.5 volt plug-in
power
14
14
15
16
13
Side XLR Panel
12
Side Mini-Jack Panel
5
11
