Adapter Connectors and Controls

Front Panel
POWER Switch
1
Main power switch for adapter
POWER LED
2
Green indicates power on and good battery condition
Red indicates low battery voltage
MONITOR Switch
3
OUT selects headphone monitoring from either the microphones
during recording, or RTN for playback audio from the camera
PHONE
4
Headphone jack to monitor the audio from microphones or camera
RTN Jack
5
Input jack for connecting the loopback audio from the camera
Vol Control
6
Adjusts the headphone volume level
OUTPUT Switch
7
Selects mono or stereo output mode
LEFT and RIGHT Controls
8
Individual trim controls to adjust output levels on each channel
