Specifications

Maximum Input Levels
Output Level
Output Clipping Level
Frequency Response
THD+N
Dynamic Range
Gain
Plug-in Power
Level Indicators
External Power
Dimensions
Weight
This device complies with the FCC Rules, Part 15, Class B
LO gain -15dBu
HI gain -35dBu
+4dBu when level indicators change to red
+25dBu (XLR), +21dBu (3.5mm)
20Hz to 20kHz (+/- 0.5dB)
Lo Gain: 0.013% (+4dBu output, 1kHz)
Hi Gain: 0.08% (+4dBu output, 1kHz)
100dB
LO +40dB
HI +60dB
3.5 volts on all mini-jack mic inputs
Green: -40dBu to -16dBu
Yellow: -16dBu to +4dBu
Red: +4dBu
11-18 volt via 2-pin Lemo
Pin 1 = (-), Pin 2 = (+)
3.54" x 3" x 1.57" (L x W x H)
(90 mm x 76 mm x 40 mm)
10.2 oz. (0.29 kg)
8
(low)
(normal)
(over)
