Output Set Test
3-16
6. In the Digital Input Panel under Channels, click on a channel to
select it and display the logical state of its input lines.
The output set test checks whether logic levels measured at all output pins
agree with output bit patterns set by software, using a DriverLINX
graphical interface (AIO Panel).
This test is performed without user circuits being connected to the
Note:
outputs.
Perform the output set test as follows:
1. Ready the following equipment:
A digital voltmeter (DVM) or a digital multimeter (DMM) set
to measure voltages, or a logic probe capable of reading TTL
logic levels.
A suitable accessory and cable for the board being tested.
2. Turn OFF the host computer.
3. Connect the cable and accessory to your board.
4. Turn ON the host computer and boot Windows 95/98/NT.
5. Click the Windows 95/98/NT Start tab.
Setup and Installation
