Keithley MSSR-32 Packing List

Channel solid state i/o module system for the metrabus

This product is not intended for use in circuits carrying voltages in excess of 30V RMS, 42.4V

peak, or 60VDC

Functional description

Keithley's MSSR-32 is a 32-channel digital I/O interface for the METRABUS industrial data acquisition and control family.

Up to 32 industry standard miniature solid state I/O modules can be mounted on a single board. The MSSR-32 rack uses 4 con-

secutive addresses in the 64-bit METRABUS address space. This allows up to 16 MSSR-32 boards (512 I/O points) to be con-

nected to a single METRABUS driver card.

The MSSR-32 is divided into four 8-bit ports. Modules can be installed in any combination of inputs and outputs (though pro-

gramming is simpliﬁed if only one type of module is used in any one MSSR-32 8-bit port).

The MSSR-32 uses 5 volt power only, and one or two MSSR-32s can be operated directly from the host computer's power sup-

ply. For larger systems, a MBUS-PWR power supply should be installed.

Speciﬁcations

Metrabus address space

4 consecutive addresses

Power requirements

+5V: 700 mA typ, 840 mA max

±15V: Not used

Module output current

Modules rated at 3 Amp max with 5 Amp overload protection fuses on MSSR-32.

Physical

Dimensions: 16 in × 4.75 in (40.63 cm × 12.06 cm)

Operating temp: 0 to +70°C

Storage temp: -20 to 100°C

Humidity: 0 to 90% non-condensing

Available miniature solid state I/O modules

SM-ODC5: Control 3 to 60 VDC at 3 Amps

SM-IDC5: Sense 3.3 to 32 VDC

MSSR-32 32-Channel Solid State I/O

Module System for the Metrabus

WARNING

Packing List

PA-641 Rev. A / 4-99
