Technical Specifications - Techly IDATA EXTIP-383IR User Manual

HDMI SPLITTER/EXTENDER OVER
SINGLE CAT5E/6 WITH IR
FAQ
Q: TV display "Waiting for connection" on the right corner? AvPlease check if the power supply of TX
(Sender) and switcher (if used) is connected, and make sure connecting cable is firmly.
Q: TV display "Signal loss"?
A: 1) please check if there is a HDMI signal input of TX.
2) Try to connect the signal source directly to display device to see if there is signal output from
source device or change the signal source, HDMI wire and try again.
Q: Display not fluent, not stable?
A: 1) Please check the cable length between the TX to switch, the switch to the RX and the connection
between each level is within the required range.
2) Click the "reset" button on the TX/RX front panel, reset and reconnect.

TECHNICAL SPECIFICATIONS

HDMI Signal
Software protocol
Video encode
Bandwidth
Support resolutions
Network Cable
Transmission distance
IR signal
Working Temperature
Power Supply
Power Consumption
Dimensions
This product is marked with this symbol. It means that used electrical and electronic
products should not be mixed with general household waste.
There is a separate collections system for these products in compliance with EU
Directive WEEE
The product is compliance with EMC Directive 2004/108/EC
and ROHS Directive 2011/65/EU
Compatible with HDCP
HDbitT V1.0
H.264
18Mbps
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz,
1080p@50/60Hz
UTP/STP Cat5/5e/6
Up to 120 meters transmission distance for
1080p Full HD over single CAT6
Supports 20~60KHz IR devices
0°C~60C°
DC5V/1A
TX:3.5W; RX: 3W
130(W) x 84(D) x 23.2(H) mm*2PCS
