Danfoss AKS 4100U Installation Manual page 10

R410A
Temperature range:
-65 – 15 °C / -85 – 59 °F
Temperature Temperature
[°C] [°F]
-65 – -47 -85 – -52
-46 – -35 -51 – -31
-34 – -26 -30 – -14
-25 – -19 -13 – -2
-18 – -13 -1 – 9
-12 – -8 10 – 18
-7 – -4 19 – 25
-3 – 0 26 – 32
1 – 4 33 – 40
5 – 7 41 – 45
8 – 10 46 – 50
11 – 12 51 – 54
13 – 15 55 – 59
R507
Temperature range:
-60 – 15 °C / -76 – 59 °F
Temperature Temperature
[°C] [°F]
-60 – -48 -76 – -54
-47 – -36 -53 – -32
-35 – -28 -31 – -18
-27 – -21 -17 – -6
-20 – -15 -17 – -5
-14 – -10 -4 – 14
-9 – -6 13 – 22
-5 – -2 23 – 29
-1 – 2 30 – 36
3 – 5 37 – 41
6 – 8 42 – 47
9 – 11 48 – 52
12 – 13 53 – 56
14 – 15 57 – 59
Default screen
AKS 4100
DISTANCE
5000 mm
• Press
AKS 4100
1.0.0
QUICK SETUP
• Press
AKS 4100
2.0.0
SUPERVISOR
• Press
AKS 4100
2.0.0
___________
• Go to SUPERVISOR menu (see page 7).
• Go to parameter 2.9.4 Reset Factory.
• Select RESET FACTORY YES
• Press 3 times to return to default screen.
Factory reset completed.
© Danfoss | DCS (MWA) | 2017.07
Saturated vapour dielectric constant
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
1.14
How to change the language setting (Default: English)
Enter password:
AKS 4100
2.1.0
INFORMATION
• Press 6 times
AKS 4100
2.7.0
DISPLAY
• Press
AKS 4100
2.7.1
LANGUAGE
• Press
AKS 4100
LANGUAGE
ENGLISH
Reset to factory setting
R404A
Temperature range:
-60 – 15 °C / -76 – 59 °F
Temperature Temperature
[°C] [°F]
-60 – -47 -76 – -52
-46 – -35 -51 – -31
-34 – -26 -30 – -14
-25 – -19 -13 – -2
-18 – -14 -1 – 7
-13 – -9 8 – 16
-8 – -4 17 – 25
-3 – 0 26 – 32
1 – 3 33 – 38
4 – 6 39 – 43
7 – 9 44 – 49
10 – 12 50 – 54
13 – 15 55 – 59
• Press
possibilities
Press
• Press
• Press
STORE NO or STORE YES.
Select STORE YES by pressing
Default screen appears:
DISTANCE
Language setup completed
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
or to see the language
to confirm.
AKS 4100
2.7.1
LANGUAGE
3 times
AKS 4100
1.0.0
STORE NO
or to select between
AKS 4100
5000 mm
