R717 (NH )
3
Temperature range:
-60 – 50 °C / -76 – 122 °F
Temperature Temperature
[°C] [°F]
-60 – -42 -76 – -43
-41 – -18 42 – 0
-17 – -5 1 – 23
-4 – 4 24 – 39
5 – 12 40 – 54
13 – 18 55 – 64
19 – 24 65 – 75
25 – 28 76 – 82
29 – 33 83 – 91
34 – 37 92 – 99
38 – 40 100 – 104
41 – 44 105 – 111
45 – 47 112 – 117
48 – 50 118 – 122
R22
Temperature range:
-60 – 48 °C / -76 – 118 °F
Temperature Temperature
[°C] [°F]
-60 – -50 -76 – -58
-49 – -25 57 – -13
-24 – -10 -12 – 14
-9 – 0 15 – 32
1 – 8 33 – 46
9 – 15 47 – 59
16 – 21 60 – 70
22 – 26 71 – 79
27 – 31 80 – 88
32 – 35 89 – 95
36 – 39 96 – 102
40 – 42 103 – 108
43 – 45 109 – 113
46 – 48 114 – 118
R410A
Temperature range:
-65 – 15 °C / -85 – 59 °F
Temperature Temperature
[°C] [°F]
-65 – -47 -85 – -52
-46 – -35 -51 – -31
-34 – -26 -30 – -14
-25 – -19 -13 – -2
-18 – -13 -1 – 9
-12 – -8 10 – 18
-7 – -4 19 – 25
-3 – 0 26 – 32
1 – 4 33 – 40
5 – 7 41 – 45
8 – 10 46 – 50
11 – 12 51 – 54
13 – 15 55 – 59
R507
Temperature range:
-60 – 15 °C / -76 – 59 °F
Temperature Temperature
[°C] [°F]
-60 – -48 -76 – -54
-47 – -36 -53 – -32
-35 – -28 -31 – -18
-27 – -21 -17 – -6
-20 – -15 -17 – -5
-14 – -10 -4 – 14
-9 – -6 13 – 22
-5 – -2 23 – 29
-1 – 2 30 – 36
3 – 5 37 – 41
6 – 8 42 – 47
9 – 11 48 – 52
12 – 13 53 – 56
14 – 15 57 – 59
© Danfoss | DCS (MWA) | 2017.07
Saturated vapour dielectric constant (default value: 1.066)
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.00
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.00
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
1.14
R744 (CO )
2
Temperature range:
-56 – 15 °C / -69 – 59 °F
Temperature Temperature
[°C] [°F]
-56.0 – -42.0 -69 – -43
-41.0 – -28.0 -42 – -18
-27.0 – -17.0 -17 – 2
-16.0 – -9.0 3 – 16
-8.0 – -3.0 17 – 27
-2.0 – 2 28 – 36
3 – 7 37 – 45
8 – 11 46 – 52
12 – 14 53 – 58
15 59
R134a
Temperature range:
-60 – 50 °C / -76 – 122 °F
Temperature Temperature
[°C] [°F]
-60 – -42 -76 – -43
-41 – -18 -42 – -0
-17 – -4 1 – 25
-3 – 5 26 – 41
6 – 13 42 – 56
14 – 20 57 – 68
21 – 25 69 – 77
26 – 30 78 – 86
31 – 34 87 – 94
35 – 38 95 – 100
39 – 42 101 – 108
43 – 45 109 – 113
46 – 48 114 – 119
49 – 50 120 – 122
R404A
Temperature range:
-60 – 15 °C / -76 – 59 °F
Temperature Temperature
[°C] [°F]
-60 – -47 -76 – -52
-46 – -35 -51 – -31
-34 – -26 -30 – -14
-25 – -19 -13 – -2
-18 – -14 -1 – 7
-13 – -9 8 – 16
-8 – -4 17 – 25
-3 – 0 26 – 32
1 – 3 33 – 38
4 – 6 39 – 43
7 – 9 44 – 49
10 – 12 50 – 54
13 – 15 55 – 59
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.00
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
Dielectric constant
of refrigerant gas
Parameter 2.5.3
GAS EPS.R
1.01
1.02
1.03
1.04
1.05
1.06
1.07
1.08
1.09
1.10
1.11
1.12
1.13
