For all other refrigerants:
• Connect the device to the power supply
(see the section "Electrical installation/
connection").
• Press 3 times.
AKS 4100
QUICK SETUP?
YES NO
• Press
AKS 4100
PROBETYPE
SINGLECABLE
• Press or to select between SINGLE,
COAXIAL D14 and COAXIAL D22. Choose
COAXIAL D14 and press
AKS 4100
LIQUID CO ?
2
YES NO
• Press (NO) to confirm
AKS 4100
PROBE LENGTH
05000 mm
© Danfoss | DCS (MWA) | 2017.07
• Press to change the PROBE LENGTH.
Press to change the position of the
cursor.
Press to decrease the value or
increase the value.
Press to confirm.
SCALE 4mA
• Press to change of SCALE 4 mA.
Press to change the cursor position.
Press to decrease the value or
increase the value.
Press to confirm.
SCALE 20mA
to confirm.
• Press to change of SCALE 20 mA.
Press to change the cursor position.
Press to decrease the value or
increase the value.
Press to confirm.
to
AKS 4100
04946 mm
to
AKS 4100
00070 mm
to
AKS 4100
QUICK SETUP
COMPLETED IN 8
• Wait for QUICK SETUP to complete.
Count down from 8 sec.
AKS 4100
1.0.0
QUICK SETUP
• Press to confirm.
AKS 4100
1.0.0
STORE NO
• Press or to select between
STORE NO or STORE YES.
Press to confirm.
Default screen appears:
AKS 4100
DISTANCE
5000 mm
Quick Setup completed
