4.5 Screen 5: MAIN MENU
To access MAIN MENU screen
(GPS MAP → POSITION INFO → TRIP LOG →
MAIN MENU)
The MAIN MENU screen gives access to some of
the Active 20's main functions and settings.
The upper half of the MAIN MENU screen shows
the title of the Active Map, ie. the loaded
on the MapCard. The lower half of the
screen shows the name of the Active Route. Only
one at once Route can be Active.
Buttons:
OOI Menu.
Go to OOI Menu. These are Objects of
Interest, and include Points of Interest (POIs), Areas
(AOIs) and Lines (LOIs).
GoTo and Marker.
Set GoTo point /
by coordinates (or postcode: GB only).
A GoTo point is a single leg route with a single
waypoint.
A Marker allows the measurement of distance and
bearing between any two points.
Map Screens.
Return to GPS MAP / PLANNING
map screens
Software v3.0.11065
Routes Menu.
routes, View routes, Activate, Edit and Delete
routes functionaliy.
Settings.
Go
later in the user guide
MapPack
Primary Screens (Page Forward).
MAIN MENU
scroll through the primary screens. This can also
be achieved by using the Left-Right action on the
rocker pad.
Marker either
Go to ROUTES MENU. Create
to SETTINGS MENU. More detail
Press to
21
MAIN MENU
Map
Screens
