Overview

3.1 Battery Power
The Active 20 can be powered by a Lithium Polymer
rechargeable battery, or three AA batteries. The
rechargeable battery is optimized to last longer over
a wide range of temperatures/conditions and lasts
significantly longer than AA's. Since AA batteries
vary significantly in power and life from one type to
another, we recommend using Lithium Energizers
which are the most powerful on the market. It is not
advisable to use cheap batteries in the unit as they
will have a short life.
There are 4 ways to conserve power:
1. Select a 'Screen Turn Off'
option
Settings > Power Control > Automatic Screen Turn Off
> Select 'Off after 3 minutes'
2. Change the Power Saving Mode
,
Ultra so the GPS MAP screen updates every 4 / 8
seconds instead of every second.
Settings > Advanced Power Control > Power Saving
Mode > Advanced / Ultra
Note: The "Trail Up" facility is disabled when in
Advanced Powersaving Mode, and backlight is
limited to 80%.
3. Decrease the Backlight setting
Settings > Backlight (adjust slider accordingly)
4. Hibernate Mode
Use to set an ultra low power
state and rapid satellite acquisition.
Power Button > Hibernate for X hours
Note: Trip log data is not stored in this mode
3.2 Switching On, Off & Hibernate
When first installed, the software allows users to
select the operating language. Whatever language
is selected, the unit is then set for the appropriate
GPS position: i.e. selecting English sets up the GPS
default to Great Britain.
Software v3.0.11065
After switching on the unit, the GPS STATUS screen
will load up. The bars at the bottom of the screen
indicate how many satellites are in range of the
Active 20.
When the bars turn from blue to green this shows
that the unit has locked to that specific satellite. In
general, the unit needs a minimum of four satellites
to get a lock. Outdoors, the unit should get a lock
within three minutes or less. If it takes much longer,
please contact Satmap. Hibernate mode allows
rapid satellite lock as the unit remembers the
satellites' position. Generally, it is easier for GPS
devices to get a first lock whilst the unit is stationary.
To switch the unit off, press the
Power Off? screen is displayed in order to prevent
accidental switch-off; select
to Advanced or
will be saved before power off. If no selection is
made after 10 seconds the unit will revert to the
previous screen.
Hibernate mode
power state, but keeps the real-time clock alive. This
permits a very quick boot-up time & fast satellite lock
when the power button is re-pressed. However, in
theis mode, no Trip Stats are saved.
3.3 Keyboard Lock
The Power Off?
Lock) icon by the
Off
button to lock the keypad. A padlock icon is
displayed by the battery indicator.
.
To unlock the keypad press any button and the
Unlock screen will be displayed. Select
unlock the keypad. If no selection is made after 3
seconds the unit will revert to the previous screen.
On/Off
button and a
.
Power Off Your data
puts the unit into a very low
screen has a padlock (Keypad
On/Off button. Press the On/
Yes to
9
On / Off /
Lock
Button
Keyboard
Lock
Power Off screen for
Hibernate options
