Environmental conditions
Environment class 3K2, DIN IEC 721
Rated range of operation
Humidity
Limit range of operation
Humidity

VESA-DDC-compatible VGA interface

Your monitor is equipped with a VESA-DDC-compatible VGA interface. VESA-DDC (Video
Electronics Standard Association, Display Data Channel) is used as the communications
interface between the monitor and the computer. If the computer is equipped with a
VESA-DDC-compatible VGA interface, it can automatically read the data for ensuring
optimum operation from the monitor and select the appropriate settings.

Preset operating modes

The picture position and size have been set to optimum values at the factory for the
operating modes listed above. Depending on the display adapter used, it may be
necessary to adjust the picture position and size. In this case, you can change and
save the settings (see chapter
For ergonomic reasons, a screen resolution of 1920 x 1080 pixels is recommended.
Because of the technology used (active matrix), an LCD monitor provides a
totally flicker-free picture, even with a refresh rate of 60 Hz.

Most frequent operating modes

Screen resolution
640 x 480
720 x 400
800 x 600
1024 x 768
1280 x 720
1280 x 1024
1440 x 900
1600 x 900
1680 x 1050
1920 x 1080
Fujitsu
15 °C .... 35 °C
20 % .... 85 %
5 °C .... 35 °C
15 % .... 85 %
"Changing the monitor settings", Page
Refresh rate
60/75 Hz
70 Hz
60/75 Hz
60/75 Hz
60 Hz
60/75 Hz
60 Hz
60 Hz
60 Hz
60 Hz
Technical specification
22).
43
